Kichler Bretta Flush Mount Ceiling Light

Safety Precautions

[!] CAUTION – RISK OF SHOCK:

Disconnect power at the main circuit breaker panel or main fuse box before starting and during installation.

[⚠️ WARNING]:

This fixture is intended for installation in accordance with the National Electrical Code (NEC) and all local code specifications. If you are not familiar with code requirements, installation by a certified electrician is recommended. Failure to adhere to these codes and instructions may result in serious injury and/or property damage and will void the warranty.

Cleaning:

• Always ensure electric current is turned off before cleaning.
• Use only a soft damp cloth. Harsh cleaning products may damage the finish.

Parts List

• [A] Canopy
• [B] Lockup Knob
• [C] Hex Nut
• [D] Mounting Strap
• [E] Outlet Box (not supplied)
• [F] Strap Mounting Screw
• [G] Threaded Pipe
• [H] Glass

Diagram Description

The fixture diagram illustrates the assembly of the lighting fixture. Key components include the Canopy [A], Lockup Knob [B], Hex Nuts [C] (labeled #1, #2, #3), Mounting Strap [D], Outlet Box [E] (not supplied), Strap Mounting Screws [F], Threaded Pipe [G], and Glass [H]. The diagram shows how the threaded pipe [G] attaches to the mounting strap [D] using hex nuts [C].

Grounding instructions are depicted in two scenarios: (a) for mounting straps with raised dimples, where the ground wire is wrapped around the green ground screw; and (b) for straps with a cupped washer, where the ground wire is secured under the washer and screw.

Installation Instructions

1. Take the threaded pipe [G] from the parts bag and screw one hex nut [C] onto it.
2. Screw the threaded pipe into the mounting strap [D] until the hex nut stops it. Ensure the extruded thread of the mounting strap faces the outlet box [E].
3. Screw a second hex nut [C] onto the end of the threaded pipe protruding from the back of the mounting strap. Adjust the first hex nut if necessary to ensure the second hex nut fully engages the pipe.
4. Screw a third hex nut [C] onto the threaded pipe, approximately 1/2 inch (12.7 mm) from the end.
5. Attach the mounting strap [D] to the outlet box [E] using the strap mounting screws [F]. The strap can be adjusted for fixture position.
6. Grounding Instructions (for USA):
   • If the mounting strap has a hole and two raised dimples: Wrap the outlet box ground wire around the green ground screw and thread it into the hole.
   • If a cupped washer is provided: Attach the outlet box ground wire under the cupped washer and the green ground screw, then thread it into the mounting strap.
   If the fixture has a ground wire, connect it to the outlet box ground wire using a wire connector after completing the above steps. Never connect the ground wire to the black or white power supply wires.
7. Make Wire Connections:

   Connect Black or Red Supply Wire to:	Connect White Supply Wire to:
   Black	White
   *Parallel cord (round & smooth)	*Parallel cord (square & ridged)
   Clear, Brown, Gold or Black without Tracer	Clear, Brown, Gold or Black with Tracer
   Insulated wire (other than green) with copper conductor	Insulated wire (other than green) with silver conductor

   *Note: When using parallel wire (SPT 1 & SPT 2), the neutral wire is square-shaped or ridged, and the other wire will be round or smooth.

   Connect the fixture's ground wire to the outlet box's ground wire using a wire connector. This is the "Neutral Wire" connection.

8. Raise the canopy [A] to the ceiling, passing the threaded pipe through the center hole. Adjust the third hex nut [C] so it meets the bottom of the canopy.
9. While holding the canopy in place, screw the lockup knob [B] onto the threads protruding through the canopy's center hole. Tighten to secure.
10. Install recommended bulbs (not supplied).
11. Carefully lift the glass [H] up to the installed canopy. Gently push the glass against the canopy and rotate it clockwise until it locks into place.

Warranty Information

For warranty information, please visit: kichler.com/warranty
