Ecler ARQISSB12i: Architectural Loudspeaker Cabinet

Product Overview

The Ecler ARQISSB12i is a wooden subwoofer reinforcement cabinet featuring a compact design, stylish aesthetics, excellent sound quality, and long-term reliability. It is equipped with a 300 WRMS @ 8Ω power handling and a 12" LF driver. This loudspeaker is specifically designed for permanent installations where a balance between sound performance and architectural/interior design matching is crucial. It includes 12 x M8 rigging points.

Key Features

• Subwoofer, 1-way architectural loudspeaker
• 300 WRMS @ 8Ω
• 1 x 12" low frequency woofer
• Double INPUT/STACK connector, Speakon type
• 12 x M8 cabinet flying points
• Available in black (RAL 9005) colour
• EASE files available

Applications

• Commercial
• Corporate
• Hotels and restaurants
• Education
• Sports and wellness
• Leisure

Technical Specifications

System

• Effective frequency range: 44Hz-4kHz
• Power handling: 300W RMS / 1200W peak
• Sensitivity: 95dB (1W/1m)
• Maximum SPL: 120dB RMS / 126dB peak
• Recommended amplifier: 600W

Transducers

• Ways: 1 way
• Driver: 12" woofer
• Nominal impedance: 8Ω

Filters

• Crossover filter: No
• Recommended High-Pass protection filter: 45 Hz with minimum 12 dB / octave filter

Physical

• Connection type: 2x Speakon (+1, -1)
• Installation options: Surface, wall, desktop
• Environmental: IP31
• Enclosure material: Plywooden
• Grille material: Steel
• Grille fixing system: Screw fixation
• Flying points: 12 x M8
• Operating temperature: Min: -20°C; -4°F, Max: 70°C; 158°F
• Operating humidity: Max: <85% HR
• Storage temperature: Min: -20°C; -4°F, Max: 70°C; 158°F
• Storage humidity: Max: <90% HR
• Included accessories: 4x Rubber feet / 4x Screws
• Finished color: Black (RAL9005)
• Dimensions (WxHxD): 440 x 375 x 440 mm / 17.32 x 14.76 x 17.32 in
• Weight: 19.4 Kg / 42.76 lbs
• Pieces per box: 1 unit
• Shipping dimensions (WxHxD): 535 x 470 x 535 mm / 21.06 x 18.50 x 21.06 in
• Shipping weight: 21.7 kg / 47.84 lb

Frequency Response On-Axis

A graph displays the frequency response of the Ecler ARQISSB12i. The Y-axis represents SPL (dB@1W/1m) ranging from 60 to 120 dB. The X-axis represents Frequency (Hz) ranging from 20 Hz to 20 kHz. The curve shows a peak around 100-125 Hz, gradually decreasing as frequency increases, with a notable dip around 4-8 kHz before rising again towards 20 kHz.

Mechanical Diagrams

Diagrams illustrating the mechanical dimensions of the Ecler ARQISSB12i loudspeaker cabinet. The diagrams show front, side, and rear views with measurements in millimeters. Key dimensions include width, height, and depth, as well as the placement of rigging points and connectors.

A&E Specifications

The Ecler ARQISSB12i is a 1-way wooden subwoofer cabinet featuring a high-efficiency 12" low woofer. It offers an RMS power handling of 300 W and a peak power handling of 1200 Watt, with an effective frequency range (±10 dB) from 44Hz to 4kHz. The sensitivity is 95 dB (at 1 Watt, 1 meter), and the maximum continuous sound pressure level is 120 dB. The loudspeaker has a nominal impedance of 8 Ω. The enclosure is constructed from medium density plywood with a textured, scratch-resistant paintwork finish. The front features an overlapping grill with a rotatable logo for a slim and elegant appearance. It includes 1 Speakon© connector. The overall dimensions are 445 mm wide, 445 mm high, and 375 mm deep, with a maximum weight of 23 Kg.

All product characteristics are subject to variation due to production tolerances. NEEC AUDIO BARCELONA S.L. reserves the right to make changes or improvements in the design or manufacturing that may affect these product specifications.

For technical queries, contact your supplier, distributor, or complete the contact form on the Ecler website under Support/Technical requests.
