Numatic Henry Quick Series Vacuum Cleaners - Original Instructions

Product Overview

This document provides original instructions for the Numatic Henry Quick series of vacuum cleaners, including models such as Henry Quick (HEN.100), Hetty Quick (HET.100), Henry Quick Pet (HEN.100), and Henry Quick PRO (HEN.100).

CAUTION: Read instructions before using the machine. KEEP FOR FUTURE REFERENCE.

For assistance, download the 'Nu-Assist' app from the App Store or Google Play.

Visit myhenry.com for more information.

Index

Note: The Mini Motorised Floor Tool is not included as standard and is available as an optional accessory.

Diagram Description: The index is accompanied by diagrams illustrating the main vacuum cleaner unit with numbered parts (1-13), the floor tool with numbered parts (5-7, 12, 14-15), and the mini motorised floor tool with numbered parts (16-17).

Box Contents & Main Assembly

Box Contents: The box contains various components for the vacuum cleaner, including the main unit, wand sections, floor tools, charging accessories, and specific kits like the 'Quick PRO Kit' for Henry Quick PRO models. Henry Quick Pet and PRO models include specific accessories.

Main Assembly: Illustrations show the step-by-step process of assembling the vacuum cleaner, connecting the wand sections, handle, and floor tool.

Accessory Fitting

Detailed diagrams illustrate how to correctly attach various accessories, such as crevice tools, upholstery tools, and brush tools, to the main unit and wand. Correct fittings are indicated with a checkmark (✔️), and incorrect fittings with a cross mark (❌).

Battery Fitting & Removal

Illustrations guide the user through the process of fitting and removing the battery pack from the vacuum cleaner.

Control Panel

The control panel features five buttons:

• 1. Power on/off: Turns the vacuum cleaner on and off.
• 2. Battery life / Charge status: Indicates the remaining battery life or charging status.
• 3. Boost mode on/off: Activates or deactivates the boost mode for increased suction power.
• 4. Brush roll on/off: Controls the operation of the brush roll.
• 5. Filter POD full / System blockage: Indicates when the filter pod is full or if there is a system blockage.

Scent Capsule Fitting & Floor Tool Air Bleed Control

Scent Capsule Fitting: Step-by-step diagrams show how to insert a scent capsule into the designated area.

Floor Tool Air Bleed Control: Diagrams illustrate how adjusting the air bleed control on the floor tool affects airflow and suction, particularly for different carpet types.

Charger Wall Mounting & Accessory Storage

Charger Wall Mounting: Instructions and diagrams are provided for securely mounting the charging unit to a wall, including advice on selecting appropriate fixings for the machine's weight (3.2kg) and routing the charging cable.

Accessory Storage: Diagrams show how to store various accessories with the vacuum cleaner.

Disposable Pod Emptying & Fitting

Disposable Pod Emptying: Illustrations guide the user on how to safely empty the disposable dust pod.

Disposable Pod Fitting: Diagrams demonstrate the correct procedure for fitting a new disposable dust pod.

Extension Handle Fitting / Removal

Step-by-step illustrations (1-4) clearly show how to attach and detach the extension handle to the vacuum cleaner.

Machine Charging

Diagrams illustrate the process of charging the vacuum cleaner's battery. This includes connecting the charger and shows battery status indicators (e.g., multiple bars representing charge level) and an estimated recharge time of 150 minutes for a full charge (100%).

Floortool Hose Cleaning / Blockage Removal

Step-by-step illustrations (1-7) provide instructions on how to clean the floortool hose and remove any blockages that may occur.

Brush Roller Removal & Cleaning

Brush Roller Removal & Cleaning: Diagrams (1-4) detail the process for removing and cleaning the brush roller on the standard floor tool.

Mini Motorised Floor Tool Brush Roller Removal & Cleaning: Diagrams (1-5) show the specific procedure for removing and cleaning the brush roller on the mini motorised floor tool.

Machine Data & Troubleshooting

Machine Data

*Run and Recharge times may vary dependent on ambient temperature and expected battery ageing.

Trouble Shooting

About Your Machine Labels

Rating Label: Details include Model, Serial Number, Weight, Approval Marks, Voltage/Current/Rated Power, Company Name & Address, Battery Type, WEEE Logo, and Manufacturer. A warning advises users to read the instruction manual.

Floor Tool Label: Contains Model, Weight, Voltage/Current/Rated Power, Approval Marks, and Manufacturer information.

Battery Label: Includes Company Name & Address, Voltage/Current/Battery Capacity, Model, Approval Marks, WEEE Logo, Caution/Attention notices, and Manufacturer details.

Maintenance

Daily: Keep the machine and parts clean, ensure the filter pod is fitted, and examine the charger regularly. Check the filter pod frequently.

Weekly: Perform daily checks and also check for any worn or damaged parts, replacing them immediately.

Batteries: Always recharge batteries after use.

WEEE (Waste, Electrical and Electronic Equipment): Accessories and packaging should be sorted for environmentally-friendly recycling. This applies to UK/EU countries. Do not dispose of in household waste. Items no longer suitable for use must be collected and sent for recovery.

PPE (Personal Protective Equipment): The following PPE may be required for certain operations: [Ear Protection Icon], [Safety Footwear Icon], [Head Protection Icon], [Safety Gloves Icon], [Dust / Allergens Protection Icon], [Eye Protection Icon], [Protective Clothing Icon], [Hi-Vis Jacket Icon], [Caution Wet Floor Sign Icon]. A risk assessment should be conducted to determine appropriate PPE.

For assistance with problems or breakdowns, contact your Numatic dealer or the Numatic Technical helpline at +44 (0)1460 269268.

Information for Dry Use Battery Vacuum Cleaners

Warning: Read the instruction manual before use. Operators must be adequately instructed. Care and attention are required during use. Routine and preventative maintenance is essential for safe operation. Failure to maintain the equipment correctly could render it unsafe.

This machine is for DRY USE only.

Ensure the charging lead is secure and the jack is properly inserted when charging.

Keep body parts away from openings and moving parts.

Remove the battery BEFORE cleaning, maintenance, or converting the machine.

This appliance is intended for assembly, cleaning, and maintenance by an adult.

Not suitable for collecting biological hazards, hazardous, or explosive dusts. Contact your distributor for machines capable of such tasks.

Not intended for use by persons with reduced physical, sensory, or mental capabilities, or lack of experience/knowledge (including children).

Keep scent capsules away from children (harmful if swallowed).

Exercise extra care when cleaning on stairs.

Children should be supervised to ensure they do not play with the appliance. This machine is not a toy.

Caution: Store indoors only. For indoor use only. Ensure suitability for the material being collected.

Note: Primarily for domestic and commercial settings (homes, hotels, schools, hospitals, factories, shops, offices). Fitted with thermal protection. If a blockage occurs, remove the battery, inspect the floor tool, tubes, and hose for debris. If clear, replace the filter pod. Inspect for damage after use. Consider machine weight when moving.

Do: Keep machine clean, change filter pod frequently, keep hoses and tubes clear, replace worn/damaged parts immediately, use only OEM specified Numatic Scent Capsules.

Don't: Suck up hot ashes or lighted cigarette ends. Use steam cleaners or pressure washers. Immerse in water. Attempt maintenance with battery connected. Place foreign objects (air fresheners, capsules, beads) into the machine, as this can be dangerous and invalidate the warranty.

Battery and Charger Information

Note: It is recommended that the battery is fully charged before first use.

Important Warnings – Charger

CAUTION! Charge only Numatic Lithium-Ion batteries. Use only the provided supply unit (100-240V ~ 0.8A). Do not charge damaged or wet batteries. Protect the charger from moisture. Ensure mains voltage matches the charger rating plate. Use only Numatic International battery charger (915242). Do not operate in explosive environments. Do not carry by the cord. Do not unplug by pulling the cord. Do not cover the charger while charging. Do not open the charger; repairs must be done by authorised personnel.

Warning: Only use the supplied Numatic Charger. Using non-Numatic chargers risks severe damage and fire. Only use genuine Numatic parts.

Instructions for Use – Charging Batteries

The charger operates at different mains voltages and frequencies. Ensure the charger jack plug is fully inserted into the battery (see page 11). If the charger is damaged, contact your supplier. Ensure replacements are genuine Numatic parts.

Health Hazards (Acute & Chronic)

Battery chemicals are in a sealed container. Risk of exposure only occurs if the battery is abused or damaged. Avoid contact of electrolyte and lithium with skin and eyes. Signs of exposure include chemical burns from damaged/leaking batteries.

Important Warnings – Batteries

Dispose of used Numatic Lithium-Ion batteries safely according to local regulations. Do not dismantle, open, shred, expose to heat/fire, or store in direct sunlight. Avoid short-circuiting batteries or storing them haphazardly. Be aware of the risk of short-circuiting terminals by metal objects. Do not subject batteries to mechanical shock. In case of battery leaking, avoid contact with skin/eyes and inhaling fumes; seek medical advice. Use only the provided charger and batteries designed for the appliance. Keep batteries clean and dry. Do not leave batteries on prolonged charge when not in use. After long storage, multiple charge/discharge cycles may be needed for maximum performance. Remove batteries when not in use or when scrapping the appliance. Do not immerse in liquid. Do not charge damaged batteries. If batteries leak, return them to a disposal plant.

Temperature and Humidity Range Table:

If the battery is subject to conditions outside these parameters, allow at least 3 hours for acclimatisation at room temperature before operation. For faulty batteries, contact Numatic International or the helpline.

Care and Disposal of Lithium-Ion Batteries

DEFECTIVE BATTERIES

ATTENTION: Follow all safety guidelines. Defective batteries must not be stored inside buildings. If returning a battery, collection must be arranged by the supplier; faulty batteries must not be returned via post or courier. Suspected defective batteries showing signs of damage (impact, distortion, blistering, loose parts, leakage) must be considered defective and handled accordingly. Batteries found operational after a single recharge cycle under observation are considered good. If a battery fails to recharge correctly, it is defective and no further recharge attempts should be made. Defective discharged batteries should be stored in a locked battery waste container away from buildings. Dispose of batteries safely according to local regulations.

First Aid Measures

Skin Exposure: If internal materials contact skin, remove contaminated clothing and flush skin with plenty of water for at least 20 minutes. Seek medical attention.

Eye Exposure: If internal materials contact eyes, lift eyelids and rinse with running water for more than 20 minutes. Seek medical attention.

Inhalation Exposure: If internal materials are inhaled, seek fresh air. If breathing is difficult, seek medical attention immediately.

Oral Exposure: Do not induce vomiting if internal materials are swallowed. Seek medical attention immediately.

Note: Inhalation, skin contact, and eye contact are possible if the battery is damaged. Corrosive fumes can irritate skin, eyes, and mucous membranes.

Schematic Diagram & Spares/Accessories

Schematic Diagram: A block diagram illustrates the electrical components of the vacuum cleaner, including Floor Tool LEDs, Floor Tool PCB, Battery Connect PCB, VAC Motor, Floor Motor, Control Panel, and Micro Switch.

Spares and Accessories

For spares and accessories, visit myhenry.com.

Numatic International WARRANTY

Numatic International Limited grants a warranty to the original purchaser for domestic residential use for 2 years. This warranty excludes consumable parts. Using non-Numatic pods or incorrect chargers may invalidate the warranty.

Warranty Terms:

• Warranty period commences from the date of purchase.
• Claims must be processed through the dealer.
• Contact Numatic International Limited if the original dealer cannot fulfil obligations.
• Claims relate only to specific faulty parts; replacements cannot extend to the whole machine.
• Numatic International supplies dealers with warranty parts, subject to claim validation and return of faulty items.
• Claims are not accepted for fair wear and tear, misuse, abuse, or failure to operate according to the manual.
• Replacement requires valid proof of claim.
• Numatic International reserves the right to charge for unnecessary work on invalid claims.
• Warranty variations must be in writing and authorised by the Company.

Numatic International Limited, Chard, Somerset TA20 2GB. Telephone: 01460 68600.

Declarations of Conformity

UKCA Declaration of Conformity: Numatic International Limited declares that the product (HEN, HTY, NQ Vacuum Cleaner - Commercial - Dry) is in conformity with relevant UK directives and standards, including Supply of Machinery Regulations, EMC Regulations, and RoHS Regulations, referencing specific EN standards.

EU Declaration of Conformity: Similar declarations are made in multiple languages (French, German, Danish, Spanish, Estonian, Italian, Dutch, Portuguese, Polish, Romanian, Russian, Swedish, Slovenian, Finnish) confirming conformity with EU directives such as the Machinery Directive, EMC Directive, and RoHS Directive.

Authorised Signatory: Mr. Matthew Coles, Head of Technology. Signed: M Coles, Date: 5th February 2024.

Numatic International Contact Information

Numatic International Limited (Head Office): Chard, Somerset TA20 2GB, UNITED KINGDOM. Tel: 01460 68600. Website: numatic.com.

Contact details for Numatic International offices in Germany, Denmark, France, Netherlands, Switzerland, South Africa, Portugal, Spain, and Italy are provided, including addresses and telephone numbers.
