Rossmax TG100 Digital Thermometer User Manual

1. Introduction

Thank you for purchasing the Rossmax TG100 Digital Thermometer. This device is designed for accurate and reliable body temperature measurement. Please read this instruction manual thoroughly before using the thermometer to ensure proper operation, safety, and to achieve the most accurate results. Keep this manual for future reference.

2. Product Overview

The Rossmax TG100 is a compact and easy-to-use digital thermometer featuring a clear LCD display. It is suitable for oral and underarm temperature measurements.

Figure 1: The Rossmax TG100 Digital Thermometer, showing its sleek design and digital display.

Key Features:

• Fast Measurement: Provides temperature readings in approximately 60 seconds.
• Fever Alarm: An audible alert indicates a detected fever.
• Unit Switch: Easily switch between Celsius (°C) and Fahrenheit (°F).
• Low Battery Indicator: Notifies when the battery needs replacement.
• Auto Shut-off: Conserves battery life by automatically turning off after a period of inactivity.
• Self-diagnosis: The device performs a self-check to ensure proper function.

Components:

• Digital Thermometer Unit
• Protective Storage Case
• LR44 Battery (pre-installed)
• Instruction Manual

Figure 2: The Rossmax TG100 Digital Thermometer stored within its protective case.

3. Setup

Battery Installation:

The Rossmax TG100 Thermometer comes with a pre-installed LR44 battery. Before first use, ensure the battery compartment is securely closed. If the display does not turn on or shows a low battery indicator, replace the battery as described in the "Maintenance and Care" section.

Initial Power-On:

1. Press the power button (usually located near the display) to turn on the thermometer.
2. A short beep will sound, and the display will briefly show all segments, followed by the last measured temperature.
3. The device will then display "Lo" and a flashing "°C" or "°F", indicating it is ready for measurement.

4. Operating Instructions

Taking a Temperature Measurement:

1. Clean the Probe: Before and after each use, clean the thermometer probe with alcohol or soap and water.
2. Power On: Press the power button. The thermometer will display the last reading and then "Lo" with a flashing unit symbol.
3. Positioning:
   • Oral Use: Place the probe tip under the tongue, as close to the heat pocket as possible. Keep the mouth closed.
   • Underarm (Axillary) Use: Place the probe tip in the center of the armpit. Hold the arm firmly against the body.
4. Measurement: Keep the thermometer in position until a series of beeps indicates the measurement is complete (approximately 60 seconds). The display will show the peak temperature.
5. Read the Result: Read the temperature displayed on the LCD screen.
6. Power Off: Press the power button to turn off the thermometer, or it will automatically shut off after approximately 10 minutes of inactivity.

Switching Temperature Units (°C/°F):

To switch between Celsius and Fahrenheit, ensure the thermometer is off. Press and hold the power button for approximately 3 seconds until the unit changes on the display. Release the button, and the new unit will be set for future measurements.

Figure 3: Visual indicators for power, temperature unit selection, and low battery status.

5. Maintenance and Care

Cleaning the Thermometer:

• Wipe the probe tip with a soft cloth moistened with 70% isopropyl alcohol or wash with cold soapy water.
• Do not immerse the entire thermometer in water or any cleaning solution.
• Allow the thermometer to air dry completely before storing.

Battery Replacement:

When the low battery symbol appears on the display, the battery needs to be replaced. The thermometer uses one LR44 (or equivalent) button cell battery.

1. Gently slide off the battery cover located at the end of the thermometer.
2. Carefully remove the old battery using a non-metallic tool.
3. Insert a new LR44 battery with the positive (+) side facing up.
4. Replace the battery cover securely.
5. Dispose of the old battery according to local regulations.

Storage:

• Store the thermometer in its protective case when not in use.
• Keep it in a cool, dry place, away from direct sunlight and extreme temperatures.
• Avoid dropping the thermometer or subjecting it to strong impacts.

6. Troubleshooting

7. Specifications

• Model: TG100
• Measurement Range: 32.0°C to 42.9°C (89.6°F to 109.2°F)
• Accuracy: ±0.1°C (±0.2°F) between 35.5°C and 42.0°C (95.9°F and 107.6°F)
• Display: Liquid Crystal Display (LCD)
• Battery: 1.5V button cell (LR44 or equivalent)
• Battery Life: Approximately 200 hours of continuous operation
• Dimensions: Approximately 128 x 19 x 10 mm
• Weight: Approximately 10 grams (with battery)
• Operating Environment: 10°C to 40°C (50°F to 104°F), 15% to 95% RH non-condensing
• Storage Environment: -20°C to 60°C (-4°F to 140°F), 15% to 95% RH non-condensing

8. Warranty and Support

The Rossmax TG100 Digital Thermometer comes with a 2-year warranty from the date of purchase. This warranty covers manufacturing defects under normal use. It does not cover damage resulting from misuse, accidents, unauthorized repairs, or normal wear and tear.

For warranty claims or technical support, please contact your local Rossmax distributor or refer to the contact information provided with your purchase documentation.

9. Safety Information

• Do not use the thermometer for purposes other than measuring human body temperature.
• Keep the thermometer out of reach of children. Swallowing small parts like the battery can be dangerous.
• Do not bite the thermometer.
• Avoid exposing the thermometer to direct sunlight, high temperatures, or extreme humidity.
• Do not attempt to disassemble or repair the thermometer yourself.
• If the thermometer has been stored in a cold environment, allow it to warm up to room temperature before use for accurate readings.
• Consult a physician if you have concerns about your temperature reading or health condition.
