stando Universal CPU Mount with Mounting Brackets
Specifications
- Product Name: Universal CPU Mount
- Mounting Positions: 2 (Option A: Outside desk frame, Option B: Inside desk frame)
- Compatibility: Fits computers of various widths
- Mounting Method: Self-tapping timber screws and short machine screws
- Strap Material: Durable and adjustable straps
Installation
-
- This mount gives you the option to mount in 2 positions.
- Option A: Mount on the outside of your desk frame. May require you to move the leg inwards before install.
- Option B: Mount on the inside of your desk frame.
- This mount gives you the option to mount in 2 positions.
- Before you begin, measure the width of your computer. Then mount the brackets on your desk 5mm wider than your computer using self tapping timber screws.
- Once the brackets are screwed into position, its time to install the mount. Use the short machine screws to complete this step.
- Loop the straps through the brackets ensuring the buckle opens outwards (see next steps).
- Loop the straps through the buckles as shown in these 4 steps. When tightening to your computer, have straps tight then push buckle closed which will tighten slightly further for a snug fit.
- sales@stando.com.au
- Phone: 07 3520 7273
- www.stando.com.au
Frequently Asked Questions
Q: Can this mount be used for laptops?
A: This mount is specifically designed for CPUs and may not be suitable for laptops due to size and weight differences.
Q: How do I adjust the straps for different computer sizes?
A: The adjustable straps can accommodate various computer sizes. Simply tighten or loosen the straps accordingly for a secure fit.
