ICY DOCK ToughArmor MB991SK-B
2.5" SATA Removable HDD Mobile Rack
Product Overview
The ICY DOCK ToughArmor MB991SK-B is a heavy-duty, full-metal 2.5-inch SATA HDD/SSD mobile rack designed to fit into a standard 3.5-inch floppy drive bay. It is engineered for demanding applications in imaging, medical, military systems, media servers, and IPCs, and is approved by Tier 1 companies.
This mobile rack supports SATA 6Gbps transfer speeds and hot-swap functionality, providing flexibility and convenience for storage management.
[Image Description: A black, heavy-duty metal enclosure for a 2.5-inch SATA HDD or SSD, labeled 'ToughArmor MB991SK-B'. It features a front security key lock, a drive tray ejection button, and a ventilation grille. The text 'SUPPORT SATA 6Gbps' is visible.]
Key Features
- Heavy duty full metal construction suitable for demanding environments.
- Fits one 7mm to 15mm height 2.5" SATA drives/SSDs into a 3.5" floppy drive bay.
- Multi-Flow Technology provides excellent passive cooling.
- Anti-Vibration Technology creates a safe environment for hard drives or SSDs.
- Active Power Technology (APT): Individual LED powers up only when a drive is installed.
- EMI Grounding protects hard drives from electrical damage.
- Eagle-hook lock system and 2-segment safeguard key lock keep drives secure.
- Anti-Dust Flap prevents dust from entering the device when not in use.
- Removable EZ Slide Mini Tray system for easy maintenance.
- Supports SATA 6Gbps and hot swap.
- Single SATA 15 Pin power connector powers the entire device.
Design and Technology
Anti-Vibration Design
[Diagram Description: Illustrates the internal mounting mechanism designed to reduce vibrations, ensuring the stability and longevity of the installed 2.5-inch SATA HDD or SSD.]
EZ-Slide Mini Tray System
The EZ-Slide Mini Tray System simplifies the installation and removal of 2.5-inch SATA HDDs and SSDs. The tray slides smoothly into the 3.5-inch device bay.
[Diagram Description: Shows a 2.5-inch SATA HDD and a 2.5-inch SATA SSD. Arrows indicate they are placed into a slide-out tray. The tray is then shown sliding into a 3.5-inch device bay, highlighting the EZ-Slide mechanism.]
Front Panel Features
The front panel of the MB991SK-B includes a security key lock for drive protection, a drive tray ejection button for easy access, and an LED indicator.
[Diagram Description: A close-up of the front panel. Features include a 'Security Key Lock' with a keyhole, a 'Drive Tray Ejection Button', and an 'LED Indicator'. The LED indicator's function is detailed: 'Green: Device Power' and 'Amber: Drive Activity'.]
Rear Panel Connectivity
The rear of the unit provides the necessary connections for data and power.
[Diagram Description: A view of the rear of the mobile rack, clearly showing the '15 Pin SATA Power Port' for power supply and the 'SATA Port' for data transfer.]
Technical Specifications
| Feature | Specification |
|---|---|
| Item Number | MB991SK-B |
| Host Interface | Single 7pin SATA |
| Drive Fit | Single 2.5" SATA I/II/III HDD/SSD (7-15mm Height HDD) |
| Device Bay | 3.5" floppy drive bay |
| Transfer Rate | Up to 6 Gb/sec. (depending on hard drive speed) |
| Power Input | Single 15pin SATA power port |
| Insert & Extract Connection Via | Direct SATA hard drive connection |
| Structure | Full Metal |
| Drive Cooling | Metal heat dispersion |
| LED Indication | Device Power & Drive Activity |
| LED Display Color | Green: Device Power; Amber: Drive Activity |
| Dimension (L x W x H) | 5.32" x 4.00" x 1.01" |
| Weight | 399g |
Compatibility
The drive tray is compatible with the MB994 Series.
[Image Description: Shows multiple stacked ICY DOCK mobile racks, indicating a multi-bay configuration, likely for the MB994 Series.]
Warranty
This product comes with a 3-year warranty.
[Badge Description: A blue and white badge displaying '3 YEARS WARRANTY'.]
