Vicks V900F/V901F Digital Thermometer Instruction Manual

Vicks V900F

INSTRUCTION MANUAL

Vicks Digital Thermometer

Vicks Digital Thermometer
Model : V900F/V901F

READ AND SAVE THESE INSTRUCTIONS

Thank you for purchasing the VICKS® Digital Thermometer, a professionally accurate instrument for faster and easier temperature taking. Please read these instructions carefully to ensure accurate temperatures and safe operation. When used properly, this high quality product will give you years of accurate, dependable service.

IMPORTANT SAFETY INFORMATION

  • High, prolonged fever requires medical attention especially for young children. Please contact your physician.
  • Do not allow children to take their temperatures unattended.
  • Do not allow children to walk or run during temperature taking.

If you have any questions or comments about the VICKS® Digital Thermometer, call our toll-free Consumer Service Line: 1-800-477-0457.

TEMPERATURE READINGS

Temperature readings vary from person to person. Although there is no one “normal” temperature reading, a temperature, taken orally, ranging between 97°F and 100°F is considered normal. A rectal temperature is generally 1° higher and an underarm (axillary) temperature will be 1° lower.

The best method to determine your own normal temperature is to use the thermometer when you are feeling well. Record your reading twice a day (early morning and late afternoon). Take the average of the two temperatures. This is considered your normal body temperature. Any variation from it may indicate some sort of illness and you should consult your physician.

BEFORE USE

Your VICKS® Digital Thermometer is a 3-in-1 thermometer for oral, rectal, or underarm use. Whichever method is used, it is recommended that for 15 minutes prior to use, avoid eating or drinking any liquids, exercising, taking showers or baths, or smoking.

PROBE COVERS

PROBE COVERS

Disposable probe covers are provided with your VICKS® Digital Thermometer. Place a cover on the probe tip each time the thermometer is used to help prevent contamination. Additional probe covers can be purchased at most drug stores or pharmacy departments.

OPERATING YOUR VICKS® DIGITAL THERMOMETER

TURNING UNIT ON

TURNING NE UNIT ON

1.Turn unit on by pressing the on/off button (figure 1).

2. Wait for unit to get ready

  • A beep will sound and the [display will show a test (Fig. 2) for about 2 seconds.
  • When me thermometer starts to measure. The display shows” – – – ” if temperature is lower than 90ºF (Fig. 3).

ORAL USE

ORAL USE
  1. It is suggested to use a probe cover for Oral Use. Discard the probe cover after taking a temperature
  2. it is important to place the tip of the thermometer well under the tongue to get a good, accurate reading. (Hp. 4) Plane Sensor lip in areas marked with ‘a’ Keep mouth cooed and sit still to help ensure an accurate measurement
  3. When the peak temperature is reached (usually 60 seconds), 10 beep signal will sound and the “°F” sign will stop flashing. The temperature is now ready to read and will not change when the thermometer is removed.
  4. Turn the thermometer off by pressing the On/Off button. If you forget to turn it off, the thermometer will automatically turn off after approximately 10 minutes.
  5. Dispose of used probe cover and wash the thermometer as recommended.

UNDER-THE-ARM (AXILLARY) USE

This method is used for babies and young children but more difficult to get an accurate reading.

UNDER-THE-ARM
  1. Wipe the underarm with a towel.
  2. Place the probe tip under the arm so the tip is touching the skin and position your arm next to your body (Fig. 5). With a young child, it is sometimes helpful to hug the child to keep their arm next to their body. This ensures that the room air does not affect the reading.
  3. When the peak temperature is reached (usually 25-30 seconds but sometimes longer for this method), 10 beep signal will sound and the “°F” sign will stop flashing. The temperature is now ready to read and will not change when the thermometer is removed.
    Remember that this method produces a temperature 1° lower than a temperature taken orally.
  4. Turn the thermometer off by pressing the On/Off button. If you forget to turn it off, the thermometer will automatically turn off after approximately 10 minutes.
  5. wash the thermometer as recommended.

RECTAL USE

Commonly used for babies, young children, or when it is difficult to take an oral or underarm temperature.

  1. Cover the thermometer’s tip with a probe cover and lubricate with a water-soluble jelly for easier insertion. Do not use a petroleum jelly. Read the label of the lubricant to be sure you are using the right kind.
  2. Lay the patient on his/her side. If the patient is an infant, the proper position for a baby is to lay on its stomach with legs hanging down, either across your knees or at the edge of a bed or changing table. This positions the infant’s rectum for safe and easy insertion of the thermometer.
  3. Gently insert the tip of the thermometer NO MORE THAN 1/2 inch into the rectum. If you detect resistance, stop. Hold the thermometer in place during measurement.
  4. When the peak temperature is reached (usually 60 seconds) a beep signal will sound and the “°F” sign will stop flashing. The temperature is now ready to read and will not change when the thermometer is removed. Note: this method produces a temperature 1° higher than a temperature taken orally.
  5. Turn the thermometer off by pressing the On/Off button. If you forget to turn it off, the thermometer will automatically turn off after approximately 10 minutes.
  6. Dispose of used probe cover and wash the thermometer as recommended.

TO RECALL THE LAST TEMPERATURE

When the thermometer is turned on, continue to hold the button down approximately 2 seconds. The last measured temperature will be shown in the LCD display with the letter “M” shown under the degree sign for approximately 3 seconds.

CLEANING INSTRUCTIONS

  • Clean the thermometer by washing with soap and warm water or rubbing alcohol (70% isopropyl alcohol).
  • Wipe dry with soft cloth.
  • DO NOT BOIL OR CLEAN IN DISHWASHER. This will cause the thermometer to no longer function and will void the warranty.
  • Do not wash the unit with any thinner or chemical solvent.

CHANGING THE BATTERIES

The VICKS® Digital Thermometer features a long life, mercury free battery. When the “\/” appears in the lower right of the display, the battery is exhausted and needs replacing.

  1. Slide the battery cap away from the unit and carefully remove the battery with a non-metallic pointed instrument.
  2. Replace the battery with a 1.55V, L41 alkaline or SR41 silver oxide type or equivalent. Insert the new battery with the positive (+) side facing the display side of the unit.
  3. Carefully slide the battery cap back into place, making sure that the cap is secure to protect the battery compartment from moisture.
  4. Properly discard the old battery. Keep out of reach of young children, elderly and pets.

SPECIFICATIONS:

Battery Life: more than 200 hours of continuous operation.
Accuracy in waterbath: +/-0.2°F between 96.0-107.0°F at room temperature of 71°F.
Temperature Range: 89.6-109.2°F. If less than 89.6°F an “Lo” is displayed.
Beeper: Unit will beep for approximately 8 seconds when peak temperature is reached.

LIFETIME WARRANTY
Your VICKS® ComfortFlex™ Digital Thermometer is durable and manufactured for a lifetime of normal, household use. Following directions carefully will ensure years of dependable operation. If for any reason (other than misuse or normal battery replacement) you are dissatisfied with your VICKS® ComfortFlex™ Digital Thermometer, we will repair or replace it, at our option, free during your lifetime.

If the thermometer does not function properly, first check the battery. Replace if necessary. If repair is necessary call our Consumer Relations Department

Questions about your Manual ? Post in the comments!

Vicks Digital Thermometer V900/V901 Instruction Manual

Vicks Digital Thermometer V900

INSTRUCTION MANUAL

VICKS Digital Thermometer

VICKS Digital Thermometer
Model: V900 & V901

READ AND SAVE THESE INSTRUCTIONS

Thank you for purchasing the VICKS® Digital Thermometer, a professionally accurate instrument for faster and easier temperature taking. Please read these instructions carefully to ensure accurate temperatures and safe operation. When used properly, this high quality product will give you years of accurate, dependable service.

IMPORTANT SAFETY INFORMATION

  • High, prolonged fever requires medical attention especially for young children. Please contact your physician.
  • Do not allow children to take their temperatures unattended.
  • Do not allow children to walk or run during temperature taking.

If you have any questions or comments about the VICKS® Digital Thermometer, call our toll-free Consumer Service Line: 1-800-477-0457.

TEMPERATURE READINGS

Temperature readings vary from person to person. Although there is no one “normal” temperature reading, a temperature, taken orally, ranging between 97°F and 100°F is considered normal. A rectal temperature is generally 1° higher and an underarm (axillary) temperature will be 1° lower.

The best method to determine your own normal temperature is to use the thermometer when you are feeling well. Record your reading twice a day (early morning and late afternoon). Take the average of the two temperatures. This is considered your normal body temperature. Any variation from it may indicate some sort of illness and you should consult your physician.

BEFORE USE

Your VICKS® Digital Thermometer is a 3-in-1 thermometer for oral, rectal, or underarm use. Whichever method is used, it is recommended that for 15 minutes prior to use, avoid eating or drinking any liquids, exercising, taking showers or baths, or smoking.

PROBE COVERS

Disposable probe covers are provided with your VICKS® Digital Thermometer. Place a cover on the probe tip each time the thermometer is used to help prevent contamination. Additional probe covers can be purchased at most drug stores or pharmacy departments.

OPERATING YOUR VICKS® DIGITAL THERMOMETER

Press the On/Off button to activate the thermometer. A beep will sound and the display will first show the LCD display test (Fig. 1). To show the last recorded temperature, continue to hold the button down approximately 2 seconds. After 5 seconds, the display will be in the ready mode (Fig. 2).

OPERATING YOUR VICKS

ORAL USE

ORAL USE
  1. Cover the thermometer’s tip with a probe cover.
  2. Place the probe tip well under the tongue. (Fig. 3) Place sensor tip in areas marked with “TIK MARK”. The mouth should remain closed during the measurement to ensure an accurate reading. Be careful not to bite the thermometer.
  3. When the peak temperature is reached (usually 60 seconds), a beep signal will sound and the “°F” sign will stop flashing. The temperature is now ready to read and will not change when the thermometer is removed.
  4. Turn the thermometer off by pressing the On/Off button. If you forget to turn it off, the thermometer will automatically turn off after approximately 10 minutes.
  5. Dispose of used probe cover and wash the thermometer as recommended.

UNDER-THE-ARM (AXILLARY) USE

This method is used for babies and young children but less accurate and takes longer.

UNDER-THE-ARM
  1. Wipe the underarm with a towel.
  2. Cover the thermometer’s tip with a probe cover.
  3. Place the probe tip under the arm so the tip is touching the skin and position
    your arm next to your body (Fig. 4). With a young child, it is sometimes helpful
    to hug the child to keep their arm next to their body. This ensures that the room
    air does not affect the probe.
  4. When the peak temperature is reached (usually 60 seconds but sometimes
    longer for this method), a beep signal will sound and the “°F” sign will stop
    flashing. The temperature is now ready to read and will not change when the thermometer is removed. Remember that this method produces a temperature 1° lower than a temperature taken orally.
  5. Turn the thermometer off by pressing the On/Off button. If you forget to turn it off, the thermometer will automatically turn off after approximately 10 minutes.
  6. Dispose of used probe cover and wash the thermometer as recommended.

RECTAL USE

Commonly used for babies, young children, or when it is difficult to take an oral or underarm temperature.

  1. Cover the thermometer’s tip with a probe cover and lubricate with a water-soluble jelly for easier insertion. Do not use a petroleum jelly. Read the label of the lubricant to be sure you are using the right kind.
  2. Lay the patient on his/her side. If the patient is an infant, the proper position for a baby is to lay on its stomach with legs hanging down, either across your knees or at the edge of a bed or changing table. This positions the infant’s rectum for safe and easy insertion of the thermometer.
  3. Gently insert the tip of the thermometer NO MORE THAN 1/2 inch into the rectum. If you detect resistance, stop. Hold the thermometer in place during measurement.
  4. When the peak temperature is reached (usually 60 seconds) a beep signal will sound and the “°F” sign will stop flashing. The temperature is now ready to read and will not change when the thermometer is removed. Remember that this method produces a temperature 1° higher than a temperature taken orally.
  5. Turn the thermometer off by pressing the On/Off button. If you forget to turn it off, the thermometer will automatically turn off after approximately 10 minutes.
  6. Dispose of used probe cover and wash the thermometer as recommended.

TO RECALL THE LAST TEMPERATURE

When the thermometer is turned on, continue to hold the button down approximately 2 seconds. The last measured temperature will be shown in the LCD display with the letter “M” shown under the degree sign for approximately 3 seconds.

CLEANING INSTRUCTIONS

  • Clean the thermometer by washing with soap and warm water or rubbing alcohol (70% isopropyl alcohol).
  • Wipe dry with soft cloth.
  • DO NOT BOIL OR CLEAN IN DISHWASHER. This will cause the thermometer to no longer function and will void the warranty.
  • Do not wash the unit with any thinner or chemical solvent.

CHANGING THE BATTERIES

The VICKS® Digital Thermometer features a long life, mercury free battery. When the “\/” appears in the lower right of the display, the battery is exhausted and needs replacing.

  1. Slide the battery cap away from the unit and carefully remove the battery with a non-metallic pointed instrument.
  2. Replace the battery with a 1.55V, L41 alkaline or SR41 silver oxide type or equivalent. Insert the new battery with the positive (+) side facing the display side of the unit.
  3. Carefully slide the battery cap back into place, making sure that the cap is secure to protect the battery compartment from moisture.
  4. Properly discard the old battery. Keep out of reach of young children, elderly and pets.

LIFETIME WARRANTY

Your VICKS® Digital Thermometer is durable and manufactured for a lifetime of normal, household use. Following directions carefully will ensure years of dependable operation. If for any reason (other than misuse or normal battery replacement) you are dissatisfied with your VICKS® Digital Thermometer, we will repair or replace it, at our option, free during your lifetime.

If the thermometer does not function properly, first check the battery. Replace if necessary. If repair is necessary call our Consumer Service Department at 1-800-477-0457, email us at [email protected], or write to KAZ Thermometer Service Department, P.O. Box 698, Hudson, NY 12534, explaining just how the thermometer is improperly working. Our consumer service representative will provide further instruction on how to correct the trouble yourself or will ask you to return the thermometer for repair or replacement.

Questions about your Manual ? Post in the comments!

Vicks SmartTemp VDT985US Thermometer Instruction Manual

Vicks SmartTemp VDT985US

INSTRUCTION MANUAL

Vicks SmartTemp Thermometer

Vicks SmartTemp Thermometer
Model VDT985US

READ AND SAVE THESE INSTRUCTIONS

Thank you for purchasing the Vicks SmartTemp Digital Thermometer, a professionally accurate instrument for fast and easy temperature taking. Using Bluetooth® technology, the thermometer wirelessly connects to your Smartphone device to display temperature readings. Please read these instructions carefully to ensure accurate temperatures and safe operation. When used properly, this high quality product will give you years of accurate, dependable service.

This thermometer is intended for the intermittent measurement and monitoring of human body temperature orally, rectally, or under-the-arm. It can be used on people of all ages except pre-term babies or very small (for gestational age) babies. It is intended for household use only. This thermometer is intended to be used with Apple and Android mobile devices. Please see www.vicksthermometers.com/smarttemp for the full list of supported devices. If you have any questions or comments about the Vicks SmartTemp Digital Thermometer, call our toll-free Consumer Relations line: 1-800-477-0457 or email [email protected]

WARNINGS AND PRECAUTIONS

  • This product is not intended to diagnose any disease. Use of this thermometer is not intended as a substitute for consultation with your physician
  • High, prolonged fever requires medical attention. Please consult your physician immediately.
  • Do not allow children to take their temperatures unattended. Keep the thermometer and all parts out of reach of children under 12 years.
  • Do not allow children to run or walk during temperature taking.
  • Never immerse the thermometer into water or other liquids.
  • Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

BEFORE USE

Your Vicks SmartTemp Digital Thermometer is a 3-in-1 thermometer for oral, rectal or underarm use. Whichever method is used, it is recommended that for 15 minutes prior to use, avoid eating or drinking any liquids, exercising, smoking, or taking showers or baths.

OPERATING YOUR Vicks SmartTemp DIGITAL THERMOMETER

SETTING UP YOUR THERMOMETER AND SMARTPHONE FOR TEMPERATURE TAKING
Note: This setup is only required once per Smartphone device. You do not need to perform this setup every time you take a temperature.

  1. Download the Vicks SmartTemp App from the iTunes App Store or Google Play Store. The App can also be downloaded by going to www.vicksthermometers.com/smarttemp.
  2. To pair the thermometer to your Smartphone, enable the Bluetooth® setting on your phone and open the Vicks SmartTemp App.
  3. Following the prompts on your phone, PRESS AND HOLD the On/Off button on the thermometer until you see the STEADY RED LIGHT (approximately 5 seconds). When the STEADY RED LIGHT appears, press “Confirm” on the App to complete the setup.

Note: If the setup prompt does not automatically appear, go to the “More” (menu in the SmartTemp App and select “Add new device”. Follow the prompts.

SETTING UP A PROFILE (OPTIONAL)

  1. Open the Vicks SmartTemp App on your mobile device.
  2. Select “Create Profile” and fill in the patient’s name, birthdate and photo (optional). Select “Save” when complete.

TAKING A TEMPERATURE

  1. Open the Vicks SmartTemp App on your mobile device and make sure the thermometer is On (Press On/Off button).
  2. If you have completed the initial setup, and the Bluetooth® setting is enabled on your phone, the Smartphone and thermometer will connect automatically within 5 seconds.
  3. On the App, select the patient’s profile or select “Take a temperature without profile”.
  4. Select the location where you intend to take a temperature (oral, rectal, underarm).
  5. Insert the thermometer. The display on your Smartphone will change to show the temperature rising, indicating that the thermometer is working.
  6. When the measurement completes, a beep will sound on the thermometer and your mobile device screen will display the temperature value. On this screen, you can click “+” to add details such as symptoms, medications, and notes.
  7. To retake, press “Retake temp” on your mobile device.

CLEANING INSTRUCTIONS

  • Probe covers can be purchased and used on this thermometer to prevent the spread of germs.
  • Clean the probe tip after each use by washing the tip with soap and warm water or by disinfecting with rubbing alcohol (70% isopropyl).
  • Wipe dry with a soft cloth.
  • Do not submerge the thermometer in water. It is not waterproof. DO NOT BOIL OR CLEAN IN DISHWASHER. This will cause the thermometer to no longer function and will void the warranty. Do not wash the unit with any thinner or chemical solvent.

CHANGING THE BATTERIES

The Vicks SmartTemp thermometer includes a long lasting battery. When the battery needs replacing, a message will appear on your mobile device indicating that the battery needs replacing.

  1. Using a coin, unlock the battery cover and carefully remove the battery with a non-metallic instrument
  2. Replace the battery with a CR2032. Insert the new battery with the positive side (+) facing the battery cover. Replace cover and close.

ERRORS AND TROUBLESHOOTING
For errors & troubleshooting, see the MORE menu on the Vicks SmartTemp App.

SPECIFICATIONS

Battery Life: More than 100 measurements or approximately 2 years if used every week.
Temperature Range: 89.6°F-109.2°F (32.0°C-42.9°C)
Operating Ambient Range: 50-104°F (10-40°C)
Storage Temperature Range: -13°F to 131°F(-25°C to +55°C)
Operating and Storage relative humidity: 15-95% RH±5%
Accuracy for displayed temperature range: ±0.2°F (±0.1°C) within measurement range 95.9-107.6°F (35.5-42°C), and ±0.4°F (±0.2°C) outside of this range
Compatibility: For use with Apple and Andriod devices. See ww.vicksthermometers.com/ smarttemp for the full list of supported devices.

TEST PROTOCOL (Laboratory Use Only

  1. Once thermometer is paired with Smartphone, launch the Vicks app.
  2. Go to the “More” tab and tap “Settings.” Then, tap “Measurement Mode” and select “Monitor Mode.”
  3. Go to the “Take Temp” tab and follow the prompts to check for device accuracy.

This thermometer is specified to operate at 1 atmospheric pressure (700-1060hPA) or at altitudes with an atmospheric pressure up to 1 atmospheric pressure (700-1060hPA). This appliance conforms to ASTM E 1112 (Kaz USA, Inc., Southborough, MA). This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. For a complete list of standards visit the SmartTemp App or www.vicksthermometers.com. Internally powered ME equipment.

This device is calibrated at the time or manufacturing. No recalibration is required. Contact Customer Service for any accuracy issues.

PERFORMANCE

  • ASTM E1112
  • EN 12470-3
  • ISO 80601-2-56

SAFETY

  • SO 14971:2012
  • IEC 60601-1:2005

EMC

  • FCC Part 15 for Intentional Radiators
  • Category 1 Radio Equipment RSS-210 Bluetooth SIG Qualification
  • IEC 60601-1-2-2007 Electromagnetic compatibility series of standards

SOFTWARE

  • EC 62304:2006
  • FDA Guidance document: Radio Frequency Wireless Technology in Medical Devices

DESIGN

  • MEDDEV 2.1/6 (2012) – Guidelines for the qualification and classification of standalone SW used within healthcare within the regulatory framework of medical devices
  • IEC/TR 80002-1:2009 – Medical device SW – Part 1: Guidance on the application of ISO 14971 to medical device SW
  • FDA Mobile Medical Applications
  • NB-MED/2.2/Rec4 – SW and Medical Devices (2001)
  • FCC part 18
  • Category 1 Radio Equipment RSS-210 and Industry CA Requirements for Intentional Radiators

ONE YEAR WARRANTY

Your Vicks SmartTemp Thermometer is durable and manufactured for normal, household use. Following directions carefully will ensure years of dependable operation. If for any reason (other than misuse or normal battery replacement) you are dissatisfied with your Vicks SmartTemp Thermometer, we will repair or replace it, at our option, free during the one year warranty period. Modification to the product by the consumer is not authorized and voids the warranty.

If the thermometer does not function properly, first check the battery. Replace it if necessary. If repair is necessary call our Consumer Relations Department at 1-800-477-0457 or write to Kaz USA, Inc. Consumer Relations Department, 250 Turnpike Road, Southborough, MA 01772 USA, or e-mail onsumer[email protected], explaining just how the thermometer is improperly working. Our consumer service representative will provide further instruction on how to correct the trouble yourself or will ask you to return the thermometer for repair or replacement.

Questions about your Manual ? Post in the comments!

Vics ComfortFlex V965F/V966F Thermometer Instruction Manual

VICKS ComfortFlex Digital Thermometer

INSTRUCTION MANUAL

Digital Thermometer

VICKS ComfortFlex
Digital Thermometer

Model : V965F/V966F

READ AND SAVE THESE INSTRUCTIONS
Thank you for purchasing the VICKS® ComfortFlex™ Digital Thermometer with SpeedRead technology, large screen display, and Fever InSight™ feature, a professionally accurate instrument for comfortably measuring body temperature. Please read these instructions carefully to ensure accurate temperatures and safe operation. When used properly, this high quality product will give you years of accurate, dependable service.

IMPORTANT SAFETY INFORMATION

  • High, prolonged fever requires medical attention especially for young children. Please contact your physician.
  • Do not allow children to take their temperatures unattended.
  • Do not allow children to walk or run during temperature taking.

If you have any questions or comments about the VICKS® ComfortFlex™ Digital Thermometer, call our toll-free Consumer
Service Line: 1-800-477-0457.

TEMPERATURE READINGS

Temperature readings vary from person to person. Although there is no one “normal” temperature reading, a temperature, taken orally, ranging between 97°F and 100°F is considered normal. A rectal temperature is generally 1° higher and an underarm (axillary) temperature will be 1° lower.

The best method to determine your own normal temperature is to use the thermometer when you are feeling well. Record your reading twice a day (early morning and late afternoon). Take the average of the two temperatures. This is considered your normal body temperature. Any variation from it may indicate some sort of illness and you should consult your physician.

BEFORE USE
Your VICKS® ComfortFlex™ Digital Thermometer is a 3-in-1 thermometer for oral, rectal, or underarm use. Whichever method is used, it is recommended that for 15 minutes prior to use, avoid eating or drinking any liquids, exercising, taking showers or baths, or smoking.

IMPORTANT: Before first use, remove label from the display

PROBE COVERS
Disposable probe covers are provided with your VICKS® ComfortFlex™ Digital Thermometer. Place a cover on the probe tip each time the thermometer is used to help prevent spread of germs. Additional probe covers can be purchased at most drug stores or pharmacy departments.

OPERATING YOUR VICKS® ComfortFlex™ DIGITAL THERMOMETER

OPERATING YOUR VICKS
  1. TURNING THE UNIT ON
  2. Turn unit on by pressing the On/Off button (Fig. 1).
  3. Wait for unit to get ready
    – A beep will sound and the display will show a test (Fig. 2).
    – The display will show last measurement for 2 seconds (Fig. 3).
    – After about 5 seconds, the display will show it’s ready (Fig. 4).
  1. SELECTING A TEMPERATURE LOCATION

Oral Use

Oral Use
  • It is suggested to use a probe cover for Oral Use. Discard the probe cover after taking a temperature.
  • It is important to place the tip of the thermometer well under the tongue to get a good, accurate reading. (Fig. 5) Place sensor tip in areas marked with “3”. Keep mouth closed and sit still to help ensure an accurate measurement.
  • When the peak temperature is reached (usually 12 seconds), 2 beep signals will sound and the “°F” sign will stop flashing. The temperature is now ready to read and will not change when the thermometer is removed.
  • Dispose of used probe cover and wash the thermometer as recommended

Under-the-arm (Axillary) Use
This method is used for babies and young children.

Under-the-arm
  1. Wipe the underarm with a towel.
  2. Place the probe tip under the arm so the tip is touching the skin and position your arm next to your body (Fig. 6). With a young child, it is sometimes helpful to hug the child to keep their arm next to their body. This ensures that the room air does not affect the reading.
  3. When the peak temperature is reached (usually 11 seconds but sometimes longer for this method), 2 beep signals will sound and the “°F” sign will stop flashing. The temperature is now ready to read and will not change when the thermometer is removed. Note: This method produces a temperature 1° lower than a temperature taken orally.
  4. Wash the thermometer as recommended.

Rectal Use
Commonly used for babies, young children, or when it is difficult to take an oral or underarm temperature.

  1. Cover the thermometer’s tip with a probe cover and lubricate with a water-soluble jelly for easier insertion. Do not use petroleum jelly. Read the label of the lubricant to be sure you are using the right kind.
  2. Lay the patient on his/her side. If the patient is an infant, the proper position for a baby is to lay on its stomach with legs hanging down, either across your knees or at the edge of a bed or changing table. This positions the infant’s rectum for safe and easy insertion of the thermometer.
  3. Gently insert the tip of the thermometer NO MORE THAN 1/2 inch into the rectum. If you detect resistance, stop. Hold the thermometer in place
    during measurement.
  4. When the peak temperature is reached (usually 10 seconds) 2 beep signals will sound and the “°F” sign will stop flashing. The temperature is now ready to read and will not change when the thermometer is removed.
    NOTE: This method produces a temperature 1° higher than a temperature taken orally.
  5. Dispose of used probe cover and wash the thermometer as recommended.

3. READING THE MEASUREMENT
The Vicks® ComfortFlex Digital Thermometer comes with the patented “Fever InSight” feature offers a color indicator with the temperature readout to better understand the temperature measurement.

  • For readings between 97.0-98.9°F, the LCD will display green as the backlight color indicating the measurement is within an acceptable range.
  • For readings between 99.0-100.9°F, the LCD will display yellow as the backlight color indicating a slight elevation in temperature measurement.
  • For readings 101.0°F and above, the LCD will display red as the backlight color indicating possible fever.

The Fever InSight feature continues for about 7 seconds.

TURNING THE UNIT OFF
Turn the thermometer off by pressing the On/Off button. If you forget to turn it off, the thermometer will automatically turn off after approximately 3.5 minutes.

CLEANING INSTRUCTIONS

  • Clean the thermometer by washing with soap and warm water or rubbing alcohol (70% isopropyl alcohol).
  • Wipe dry with soft cloth.
  • DO NOT BOIL OR CLEAN IN DISHWASHER. This will cause the thermometer to no longer function and will void the warranty.
  • Do not wash the unit with any thinner or chemical solvent.

SPECIFICATIONS:

Battery Life: more than 200 hours of continuous operation. (approx. 2 years if used 10 minutes per day, every day).
Accuracy in waterbath: +/-0.2°F between 96.0-107.0°F at room temperature of 71°F.
Temperature Range: 89.6-109.2°F. If less than 89.6°F an “Lo” is displayed. If more than 109.2°F and “Hi” is displayed.
Beeper: Unit will beep for approximately 8 seconds when peak temperature is reached.
Fever alert: A series of 5 short beeps indicate temperatures +101.0°F.
Error messages: The display will read “Err” when a malfunction occurs and the unit will power off after 1 minute.

CHANGING THE BATTERIES
The VICKS® ComfortFlex™ Digital Thermometer features a long life, mercury free battery. When the “\/” appears and flashes in the center top of the display, the battery is exhausted and needs replacing.

  1. Using a coin, unlock the battery cover and carefully remove the battery with a non-metallic instrument.
  2. Replace the battery with a 1.55V, L41 alkaline or CR1225 silver oxide type or equivalent. Insert the new battery with the positive (+) side facing the battery cover.
  3. Carefully replace the battery cover and, using a coin, tighten the cover.
  4. Properly discard the old battery. Keep out of reach of young children, elderly and pets.

LIFETIME WARRANTY
Your VICKS® ComfortFlex™ Digital Thermometer is durable and manufactured for a lifetime of normal, household use. Following directions carefully will ensure years of dependable operation. If for any reason (other than misuse or normal battery replacement) you are dissatisfied with your VICKS® ComfortFlex™ Digital Thermometer, we will repair or replace it, at our option, free during your lifetime.

If the thermometer does not function properly, first check the battery. Replace if necessary. If repair is necessary call our Consumer Relations Department
at 1-800-477-0457 or write to Kaz, Inc., Consumer Relations Department, 250 Turnpike Rd., Southborough, MA 01772, explaining just how the thermometer is improperly working. Our consumer service representative will provide further instruction on how to correct the trouble yourself or will ask you to return the thermometer for repair or replacement.

Questions about your Manual ? Post in the comments!

Vicks Speed-Read V911/V912 Thermometer Instruction Manual

INSTRUCTION MANUAL

VICKS Speed-ReadTM Digital Thermometer

VICKS Speed-ReadTM Digital Thermometer
Model V911 & V912

READ AND SAVE THESE INSTRUCTIONS
Thank you for purchasing the VICKS® Speed-ReadTM Digital Thermometer, a professionally accurate instrument for faster and easier temperature taking. Please read these instructions carefully to ensure accurate temperatures and safe operation. When used properly, this high quality product will give you years of accurate, dependable service.

IMPORTANT SAFETY INFORMATION

  • High, prolonged fever requires medical attention especially for young children. Please contact your physician.
  • Do not allow children to take their temperatures unattended.
  • Do not allow children to walk or run during temperature taking.

If you have any questions or comments about the VICKS® Speed-ReadTM Digital Thermometer, call our toll-free Consumer Service Line: 1-800-477-0457.

TEMPERATURE READINGS

Temperature readings vary from person to person. Although there is no one “normal” temperature reading, a temperature, taken orally, ranging between 97°F and 100°F is considered normal. A rectal temperature is generally 1° higher and an underarm (axillary) temperature will be 1° lower.

The best method to determine your own normal temperature is to use the thermometer when you are feeling well. Record your reading twice a day (early morning and late afternoon). Take the average of the two temperatures. This is considered your normal body temperature. Any variation from it may indicate some sort of illness and you should consult your physician.

BEFORE USE

Your VICKS® Speed-ReadTM Digital Thermometer is a 3-in-1 thermometer for oral, rectal, or underarm use. Whichever method is used, it is recommended that for 15 minutes prior to use, avoid eating or drinking any liquids, exercising, taking showers or baths, or smoking.

PROBE COVERS
Disposable probe covers are provided with your VICKS® Speed-ReadTM Digital Thermometer. Place a cover on the probe tip each time the thermometer is used to help prevent contamination. Additional probe covers can be purchased at most drug stores or pharmacy departments.

OPERATING YOUR VICKS® SPEED-READTM DIGITAL THERMOMETER
Press the On/Off button to activate the thermometer. A beep will sound and the display will first show the LCD display test (Fig. 1). After 5 seconds, the display will be in the ready mode (Fig. 2).

OPERATING YOUR VICKS

ORAL USE

ORAL USE
  1. Cover the thermometer’s tip with a probe cover.
  2. Place the probe tip well under the tongue. (Fig. 3) Place sensor tip in areas marked with “”. The mouth should remain closed during the measurement to ensure an accurate reading. Be careful not to bite the thermometer.
  3. When the peak temperature is reached (usually 10-20 seconds), 10 beep signals will sound and the “°F” sign will stop flashing. The temperature is now ready to read and will not change when the thermometer is removed.
  4. Turn the thermometer off by pressing the On/Off button. If you forget to turn it off, the thermometer will automatically turn off after approximately 10 minutes.
  5. Dispose of used probe cover and wash the thermometer as recommended.

UNDER-THE-ARM (AXILLARY) USE
This method is used for babies and young children but less accurate and takes longer.

UNDER-THE-ARM
  1. Wipe the underarm with a towel.
  2. Cover the thermometer’s tip with a probe cover.
  3. Place the probe tip under the arm so the tip is touching the skin and position your arm next to your body (Fig. 4). With a young child, it is sometimes helpful to hug the child to keep their arm next to their body. This ensures that the room air does not affect the probe.
  4. When the peak temperature is reached (usually 20-30 seconds but sometimes longer for this method), 10 beep signals will sound and the “°F” sign will stop flashing. The temperature is now ready to read and will not change when the thermometer is removed. Remember that this method produces a temperature 1° lower than a temperature taken orally.
  5. Turn the thermometer off by pressing the On/Off button. If you forget to turn it off, the thermometer will automatically turn off after approximately 10 minutes.
  6. Dispose of used probe cover and wash the thermometer as recommended.

RECTAL USE
Commonly used for babies, young children, or when it is difficult to take an oral or underarm temperature.

  1. Cover the thermometer’s tip with a probe cover and lubricate with a water-soluble jelly for easier insertion. Do not use a petroleum jelly. Read the label of the lubricant to be sure you are using the right kind.
  2. Lay the patient on his/her side. If the patient is an infant, the proper position for a baby is to lay on its stomach with legs hanging down, either across your knees or at the edge of a bed or changing table. This positions the infant’s rectum for safe and easy insertion of the thermometer.
  3. Gently insert the tip of the thermometer NO MORE THAN 1/2 inch into the rectum. If you detect resistance, stop. Hold the thermometer in place during measurement.
  4. When the peak temperature is reached (usually 10 seconds) 10 beep signals will sound and the “°F” sign will stop flashing. The temperature is now ready to read and will not change when the thermometer is removed.Remember that this method produces a temperature 1° higher than a temperature taken orally.
  5. Turn the thermometer off by pressing the On/Off button. If you forget to turn it off, the thermometer will automatically turn off after approximately 10 minutes.
  6. Dispose of used probe cover and wash the thermometer as recommended.

TO RECALL THE LAST TEMPERATURE
When the thermometer is turned on, continue to hold the button down approximately 2 seconds. The last measured temperature will be shown in the LCD display with the letter “M” shown under the degree sign for approximately 3 seconds, then unit will shut off.

CLEANING INSTRUCTIONS

  • Clean the thermometer by washing with soap and warm water or rubbing alcohol (70% isopropyl alcohol).
  • Wipe dry with soft cloth.
  • DO NOT BOIL OR CLEAN IN DISHWASHER. This will cause the thermometer to no longer function and will void the warranty.
  • Do not wash the unit with any thinner or chemical solvent.

CHANGING THE BATTERIES
The VICKS® Speed-ReadTM Digital Thermometer features a long life, mercury free battery. When the “” appears in the lower right of the display, the battery is exhausted and needs replacing.

  1. Slide the battery cap away from the unit and carefully remove the battery with a non-metallic pointed instrument.
  2. Replace the battery with a 1.55V, L41 alkaline or SR41 silver oxide type or equivalent. Insert the new battery with the positive (+) side facing the display side of the unit.
  3. Carefully slide the battery cap back into place, making sure that the cap is secure to protect the battery compartment from moisture.
  4. Properly discard the old battery. Keep out of reach of young children, elderly and pets.

LIFETIME WARRANTY
Your VICKS® Speed-ReadTM Digital Thermometer is durable and manufactured for a lifetime of normal, household use. Following directions carefully will ensure years of dependable operation. If for any reason (other than misuse or normal battery replacement) you are dissatisfied with your VICKS® Speed-ReadTM Digital Thermometer, we will repair or replace it, at our option, free during your lifetime.

If the thermometer does not function properly, first check the battery. Replace if necessary. If repair is necessary call our Consumer Service Department at 1-800-477-0457, email us at [email protected], or write to KAZ Thermometer Service Department, P.O. Box 698, Hudson, NY 12534, explaining just how the thermometer is improperly working. Our consumer service representative will provide further instruction on how to correct the trouble yourself or will ask you to return the thermometer for repair or replacement.

KAZ Manufacturing Quality Healthcare Products for Over 75 Years
Kaz, Incorporated • Thermometer Service Dept. • P.O. Box 698 • Hudson, NY 12534 • www.kaz.com Distributed by Kaz, Inc. under license from The Procter & Gamble Company, Cincinnati, Ohio USA. Vicks is a registered trademark of The Procter & Gamble Company.

©2001 KAZ, Incorporated
Made and printed in China

Questions about your Manual ? Post in the comments!
