Xinfeite CCRF01 Ceiling Fan Remote Control
Specifications
- Input voltage:120V 60Hz
- Remote control communication frequency: 433 MHz
- Effective Remote control distance: >18 meters
- Adaptive motor parameters: Capacitance speed regulation (3 gears: high speed, medium speed, low speed)
- Battery specifications: AAA
- Safety protection: Receiver housing fire rating UL 94-VO, Temperature protection device
FOR YOUR SAFETY
- Install the receiver in the ceiling fan canopy to ensure proper protection.
- This unit is to be used for the control of the ceiling fan only, and to be connected to a 120V 60Hz power supply only, not exceeding the rated power input specification.
- Do not install an in conjunction with a solid-state dimmer.
- Do not install in damp locations. Never immerse in water or allow either component to become wet.
- This unit is for indoor use only.
- Do not modify this in any manner.
- Do not pull or cut the lead on the receiver.
- Take care of your unit and take care, to drop the remote or receiver.
- The battery within this unit should be replaced at least every year to avoid leakage and subsequent damage.
- IMPORTANT DO NOT DISPOSE OF BATTERY IN FIRE.
- WARNING THE REMOTE CONTROL RECEIVER MUST BE INSTALLED INTO THE CEILING FAN HOUSING
RECEIVER WIRING CONNECTION
Connect the remote control to the following wiring diagram through hardwiring.
RECEIVER INSTALLATION
IMPORTANT
WHEN INSTALLING THE CEILING FAN REMOTE CONTROL ANY EXISTING CONTROLLER MUST BE BYPASSED OR REMOVED. REMOTE CONTROL RECEIVER IS INTENDED FOR USE ONLY WITH CEILING FANS WITH ALLOWANCE FOR INSTALLATION OF REMOTE RECEIVER INTO FAN CANOPY
- Disconnect the power supply before installation.
- Connect the power input wires marked “AC power input L” (brown) and “ACpowerinputN” (blue) on the remote control receiver to the live and neutral connections of the power supply.
- Connect the blue wire of the remote control receiver to the neutral wire of the ceiling fan, the brown wire to the motor wire, and the orange wire to the light wire.
- After the fan receiver is powered on, the receiver and remote control will be automatically paired, and the remote control function can be used normally. If the remote control can not be used properly, please follow the following steps:
- Keep pressing the “fan on/off”button on the remote control for more than 3secondstopairthe remote control with the receiver. After successful pairing, the fan light will be twice e a reminder signal twice after repair, and the functionality of the original remote control will be disabled.
- Insert the receiver into the suspension bracket. Then you can lift the fan cover to hide the receiver and bracket.
Note The receiver must be installed in the fan cover as shown in the figure. The receiver is not designed to operate in any other way.
Parameters and Function Descriptions
The following are the parameters and function descriptions of the fan controller
FCC Statment
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions
- this device may not cause harmful interference, and
- This device must accept any interference received, including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
NOTE This equipment has been tested and found to comply with the limits for a Class B digital device, under Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used by the instructions, may cause harmful interference to radiocommunications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to avoid interference by one or more of the following measures.
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and the receiver.
- Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirements. The device can be used in portable exposure conditions without restriction.
FAQs
Q: Can this remote control be used in damp locations?
A: No, this unit is not suitable for damp locations. It is for indoor use only.
Q: How often should I replace the battery in the unit?
A: The battery within this unit should be replaced at least every year to avoid leakage and subsequent damage.
Q: What should I do if the total power exceeds 900AV?
A: When the total power exceeds 900AV, the non-recoverable fuse will be disconnected for safety reasons.
