Hyundai RAC 201 PLL / RAC 201 PLL BR Clock Radio with Projector

Introduction

Thank you for purchasing the Hyundai RAC 201 PLL / RAC 201 PLL BR clock radio with projector.

This manual provides instructions on how to operate your equipment properly. Please read through these instructions and keep them in a safe place for future reference.

Important Safety Information & Warnings

• This appliance is intended for domestic household use only.
• Do not cover ventilation openings.
• Keep away from open flames (e.g., candles).
• Do not expose to water or liquids.
• Ensure at least 10 cm clearance around the unit for proper ventilation.
• Avoid strong magnetic fields.
• Do not place on unstable surfaces or near table edges.
• Never look directly into the projector lens, as it can cause permanent eye damage.
• Ensure the power plug is easily accessible.
• Handle batteries with care; replace only with the same type.
• Do not expose batteries to excessive heat.
• Keep plastic bags away from children to prevent suffocation.

Product Overview & Controls

The unit features a digital display, radio tuner, alarm functions, and a projector.

Key Controls:

• POWER ON-OFF: Turns the unit on/off and switches to radio mode.
• SET: Used for setting the clock, alarms, and saving radio presets.
• HR / MIN: Adjusts hours and minutes for clock and alarm settings.
• VOLUME +/-: Adjusts the sound volume.
• TUNING ▲/▼: Tunes radio stations. Press and hold for auto-search.
• BAND: Switches between AM and FM radio bands.
• SLEEP: Sets the sleep timer for automatic radio shut-off.
• SNOOZE/DIMMER: Activates snooze function or adjusts display brightness.
• AL1 / AL2: Sets and controls Alarm 1 and Alarm 2.
• PROJECTION ON/FLIP/OFF: Controls the projector function, including flipping the display 180°.
• MEM: Selects stored radio stations.

Refer to the diagrams in the original document for specific button locations.

Getting Started

Standby Mode

Place the unit on a flat, stable surface and plug it into a power outlet. The unit will enter standby mode, and "0:00" will flash on the display.

Setting the Clock

1. In standby mode, press and hold the SET button until the display flashes.
2. Use the HR button to set the hours.
3. Use the MIN button to set the minutes.
4. Press SET again to confirm. The digits will stop flashing.

Radio Operation

Turning On the Radio

Press the POWER ON-OFF button. The radio frequency will briefly appear, then the clock time will be displayed.

Tuning and Listening

• Press POWER ON-OFF to turn on the radio. The default FM frequency (87.5 MHz) or the last tuned frequency will be shown.
• Press BAND to switch between FM and AM bands. The default AM frequency is 522 kHz.
• Use the TUNING ▲/▼ buttons to select a station. Press and hold for automatic station search.
• Adjust volume using the VOLUME +/- buttons.
• For best FM reception, extend the FM antenna fully. For best AM reception, rotate the unit.

Presetting Radio Stations

You can store up to 10 FM and 10 AM stations:

1. Tune to the desired station.
2. Press and hold SET for about 2 seconds until "P01" flashes.
3. Press SET again to save the station.
4. Repeat for other stations.
5. Use the MEM button to recall preset stations.

Alarms

Setting Alarm 1 or Alarm 2

1. In standby mode, press and hold AL1 or AL2 for 2 seconds. Hour and minute digits will flash.
2. Use HR and MIN buttons to set the alarm time.
3. Press AL1 or AL2 again to select the alarm sound (OFF > BUZZER > RADIO).

Checking Alarm Time

Press and hold AL1 or AL2 for 2 seconds to view the set alarm time.

Turning Off/Canceling Alarm

• To turn off the alarm for the day, press POWER ON-OFF. It will reactivate the next day.
• To cancel an alarm completely, repeatedly press AL1 or AL2 until the alarm indicator disappears.

Snooze Function

When the alarm sounds, press the SNOOZE button to temporarily silence it for approximately 9 minutes.

Sleep Timer

This function automatically turns off the radio after a set period.

Setting the Sleep Timer

1. Press SLEEP. "90" will appear on the display.
2. Repeatedly press SLEEP to select the desired duration (90, 80, 70, 60, 50, 40, 30, 20, or 10 minutes).
3. The radio will turn off automatically after the selected time.

To check remaining time, press SLEEP. To cancel, select "OFF" using SLEEP. To turn off immediately, press POWER ON-OFF.

Projector

Press the PROJECTION ON/FLIP/OFF button to turn on the projector. Press and hold for 2 seconds to flip the projected image 180°. Press again to turn off. The projector can be moved manually.

Display Brightness

Use the DIMMER button to adjust display brightness or turn it off.

Care and Maintenance

Wipe external surfaces with a soft, dry cloth. For stubborn dirt, unplug the unit and use a slightly damp cloth with a mild detergent solution. Allow to dry completely before use.

Technical Specifications

• Power Source: AC 230 V~ 50 Hz
• Frequency Range: AM 522 – 1620 kHz; FM 87.5 – 108 MHz
• Power Consumption: 5 W
• Power Consumption (Clock Only): < 1 W
• Clock Backup: 2 x 1.5V AAA batteries (not included)

Disposal Information

Electrical and Electronic Equipment Disposal: This symbol indicates the product should not be treated as household waste. It must be handed over to an appropriate collection point for recycling. Proper disposal helps prevent negative environmental and health consequences.

Battery Disposal: Dispose of batteries according to local regulations.

Declaration of Conformity

ETA a.s. declares that the RAC201PLL complies with Directive 2014/53/EU. The full EU Declaration of Conformity can be found at: www.hyundai-electronics.cz/declaration_of_conformity
