QCY AilyPods True Wireless Earbuds

Introduction

Download the QCY app before use.

Illustration: Two QCY AilyPods earbuds.

Product Description

Illustration: Earbuds, charging case, and Type-C cable with labels.

• LED Indicator: Indicates status lights.
• Touch Panel: Controls playback and calls.
• Ventilation Hole: Allows air circulation.
• Charging Contacts: Connects to the charging case.
• Microphone: Captures audio for calls.
• Charging Case: Stores and charges the earbuds.
• Type-C Cable: Used for charging the case.

The above images are for illustration purposes only. Accessories may vary.

Connecting to Your Device

First Connection:

1. Take out both earbuds and remove the protective cover. Place them back into the case and close the lid to activate them.
2. Open the case, take out the earbuds again, and activate them. On your phone, search for 'QCY AilyPods' and tap to connect.

Earbuds automatically turn on when removed. If they don't turn on, charge them and try again. Turn on the earbuds, and they will automatically connect to the last connected device if available. Before the first charge, check if the earbud charging contacts are sealed from the factory.

LED Indicators

During Pairing:

• The indicators flash white.

After Pairing:

• The indicator on the main earbud slowly flashes white, while the other indicator continuously flashes white.

Connected to Device:

• Both indicators turn off.

Factory Settings

Remove the earbuds, turn off Bluetooth on your phone, and tap the panels on both earbuds 5 times to restore factory settings (the LED indicator will flash white 5 times).

Illustration: Earbuds being placed in the charging case for reset.

Correct Way to Wear Earbuds

Illustration: Diagrams showing how to insert and adjust earbuds in the ear.

1. Insert the earbuds correctly and then adjust them to fit the shape of your ear.
2. Point the microphone towards your mouth.
3. Incorrect wearing of the earbuds may cause interference during conversations or listening.

Correct Way to Charge

LED Indicator on Charging Case:

• Low Battery: When earbuds are in the case, the indicator flashes white for 4 seconds.
• Charging: The indicator flashes white.
• Fully Charged: The indicator will continuously flash white.

LED Indicator on Earbuds:

• Charging: Indicators are solid red.
• Fully Charged: Indicators light up white for 30 seconds.

Illustration: Charging case with a cable connected.

Functions

Illustration: Earbuds with labels for LED Indicator, Touch Panel, Ventilation Hole, LED Indicator on Case.

• Power On: Remove earbuds.
• Power Off: Place earbuds into charging case.
• Answer/End Call: Double-tap the touchpad.
• Reject Call: Press and hold the touch panel for 1.5 seconds.
• Previous Track: Press and hold the left touch panel for 1.5 seconds.
• Next Track: Press and hold the right touch panel for 1.5 seconds.
• Volume Up: While listening to music, tap the right touchpad (feature is disabled by default and needs activation via the QCY app; not available during calls).
• Volume Down: While listening to music, tap the left touchpad (disabled by default and must be enabled via the QCY app; not available during calls).
• Voice Assistant: Triple-tap the left panel.
• Play/Pause: Double-tap the right panel to pause music, and double-tap the left panel to resume playback.
• Playback Mode: Triple-tap the right touch panel.

Hazardous Substances and Their Content in the Appliance

This form complies with SJ/T 11364. O: Indicates that the content of hazardous substances in the monolithic materials of this component is within the limits set by Regulation (EU) 2015/863. X: Indicates that the content of hazardous substances in at least one monolithic material of this component is beyond the limits set by Regulation (EU) 2015/863. The component is still in compliance with the EU RoHS Directive.

Note: Plan your usage time appropriately, as prolonged use may cause hearing damage.

Advice

1. Before using the earbuds, carefully read the user manual and keep it for future reference.
2. The earbuds must be fully charged before first use.
3. If the earbuds are not used for more than two weeks, they must be recharged.
4. Use chargers from a qualified manufacturer.
5. If your phone does not recognize the earbuds, check if they are in pairing mode. If the earbuds are not connected for a long time, the pairing mode will end. In this case, pair the earbuds with the device again. If a procedural error occurs, restart your phone. If an error occurs with the earbuds, reset them.

Precautions

1. Never disassemble or modify the earbuds for any reason to avoid damage and hazards.
2. Do not store the earbuds at extreme temperatures (below 0°C or above 45°C).
3. Do not use LED indicators near the eyes of children or animals.
4. Do not use the earbuds during thunderstorms to prevent malfunctions and reduce the risk of electric shock.
5. Do not use harsh chemicals or strong cleaning agents to clean the earbuds.

Note: Do not use the earbuds for prolonged periods, as they may damage your hearing.

Simplified Declaration of Conformity

Manufacturer: Dongguan Hele Electronics Co.,Ltd

Address: No.325 Yuehui Rd. Daojiao Town Dongguan City Guangdong Province China

Product: TWS Bluetooth earphones

Model: BH22QT20A

Radio Frequency: 2402~2480 MHz

Max. Radio Frequency Power: <4dbm

The product complies with Directive 2014/53/EU of the European Parliament and of the Council of 16 April 2014 on the approximation of the laws of the Member States relating to the making available on the market of radio equipment and repealing Directive 1999/5/EC.

The Declaration of Conformity is available at: https://files.innpro.pl/QCY

Safety Precautions

1. Before charging, check if the device contacts are clean.
2. Never leave the device unattended during use and charging.
3. Ensure that you can quickly disconnect the device from the power source in case of emergency.
4. Never expose the device to high temperatures.
5. Charge the device in a dry and well-ventilated place away from flammable materials, maintaining a distance of at least 1 meter from other objects.
6. Never cover the device during charging.
7. Never use power adapters, charging stations, cables, etc., without the manufacturer's recommendation and approval.
8. Take care of your property; the device is equipped with cells that are difficult to extinguish; be prepared with extinguishing material.

Environmental Protection

[WEEE symbol] Electronic waste marked in accordance with the European Union directive must not be mixed with other municipal waste. It must be collected separately and recycled at designated collection points. Proper disposal will prevent possible negative consequences for the environment and human health. The collection system for used equipment complies with local environmental protection regulations. For more detailed information, contact your local authority, cleaning station, or the store where you purchased the product. The product meets the requirements of the so-called new approach directives of the European Union (EU) in the field of safety, health, and the environment, which specify hazards to be identified and eliminated.

CE mark

This document is a translation of the original user manual from the manufacturer.

The device is equipped with a rechargeable battery which, due to its final and chemical structure, ages over time and with use. The manufacturer states the maximum operating time under laboratory conditions, where the operating conditions for the device and the battery itself are optimal, and the battery is new and fully charged. The actual operating time may differ from the time declared in the offer, and this is not a device defect but a product characteristic.

The product must be regularly maintained (cleaned) by the user or specialized service centers at the user's expense. If the user manual does not provide information on necessary cyclical maintenance or service operations, the physical condition of the product must be assessed weekly for deviations from its new state. If any deviation is detected or found, maintenance (cleaning) or service measures must be taken immediately. Failure to perform proper maintenance (cleaning) and failure to respond to detected deviations may lead to permanent damage to the product. The guarantor is not liable for damages resulting from negligence.

Battery LI-ION

The device is equipped with a LI ION (lithium-ion) battery, which ages over time and with use due to its physical and chemical structure. The manufacturer states the maximum operating time under laboratory conditions, where the operating conditions for the device and the battery itself are optimal, and the battery is new and fully charged. The actual operating time may differ from the time declared in the offer, and this is not a device defect but a product characteristic. To maintain maximum battery life, it is not recommended to discharge the battery below 3.18V or 15% of its total capacity. Lower values, such as 2.5V per cell, will permanently damage it and are not covered by warranty. If the battery or the entire device is not used for more than one month, charge the battery to 50% and check its charge level every two months. Store the battery and device in a dry place, away from sunlight and sub-zero temperatures.

Battery LIPO

The device is equipped with a LI PO (lithium polymer) battery, which ages over time and with use due to its physical and chemical structure. The manufacturer states the maximum operating time under laboratory conditions, where the operating conditions for the device and the battery itself are optimal, and the battery is new and fully charged. The actual operating time may differ from the time declared in the offer, and this is not a device defect but a product characteristic. To maintain maximum battery life, it is not recommended to discharge the battery below 3.5V or 5% of its total capacity. Lower values, such as 3.2V per cell, will permanently damage it and are not covered by warranty. If the battery or the entire device is not used for more than one month, charge the battery to 50% and check its charge level every two months. Store the battery and device in a dry place, away from sunlight and sub-zero temperatures.
