EcoFlow RIVER 600 MAX User Guide

Safety Warnings

• Keep RIVER 600 MAX and accessories dry and away from high heat.
• Never disassemble, puncture, shock, crash, or incinerate the product.
• Recycle and dispose of RIVER 600 MAX according to local regulations.
• Pay attention to safety when handling the RIVER 600 MAX.
• People with disabilities or children should use the product under supervision.

Glossary

The following terms are used in this document to indicate various levels of potential harm that may be caused by improper operation.

ℹ️ NOTICE

The instructions, if not properly followed, may result in property damage and minor physical damage.

⚠️ CAUTION

The instructions, if not properly followed, may result in property damage and serious physical damage.

⚠️ WARNING

The instructions, if not properly followed, may result in property damage, major accident and serious injury.

Product Safety Guidelines

⚠️ WARNING

Improper use may result in fire, property damage or personal injury. Make sure to use the product according to the following safety rules and guidelines.

Product Use:

• DO NOT expose the product to any liquids. Do not immerse the product in water. DO NOT leave the batteries out in the rain or near a source of moisture. Moisture in the device could cause short circuits, component failure, fires or even an explosion.
• Never use NON- EcoFlow parts. Go to http://www.EcoFlow.com to purchase new parts. EcoFlow takes no responsibility for any damage caused by the use of non-EcoFlow parts.
• Never install or remove other modules from the RIVER 600 MAX when it is turned on. Do Not plug or unplug other modules when the power of the product is turned on, otherwise the power interface may be damaged.
• The product should be used in temperatures between -4°F and 140°F (-20°C and 60°C). Use above 140°F (60°C) may cause fire or explosion. Use below -4°F (-20°C) will severely affect performance. Allow the product to return to normal operating temperature before use.
• DO NOT use the batteries in strong electrostatic or electromagnetic environments. Otherwise, the battery control board may malfunction and cause a serious accident.
• Never disassemble or pierce the product. Otherwise, it may leak, catch on fire, or explode.
• DO NOT use the product if it was involved in a crash or a heavy bump.
• If the product falls into water during use, take it out immediately and put it in a safe, open area. Keep a safe distance until it is completely dry. Never use it again and dispose of it properly. If the product catches fire, use fire extinguishing equipment in the order: water or water mist, sand, fire blanket, dry powder, carbon dioxide fire extinguisher.
• DO NOT put the machine in a microwave oven or in a pressurized container.
• Do Not allow pins, wires or other metal pieces to insert into the device case, outlets or controls. Metal pieces may short circuit the product.
• Avoid collision. DO NOT place heavy objects on the machine.
• If there is dirt on any plug or outlet surface, use a dry cloth to clean it. Otherwise, it will cause abrasion and result in energy loss or inability to charge.

Product Charging:

• Always use EcoFlow approved charging cables. EcoFlow is not responsible for damage caused by using non-EcoFlow cables.
• When charging, place the product on the ground with no flammable or combustible materials around. Never leave the machine unattended during charging.
• DO NOT charge a product immediately after a long heavy load, as its temperature may be too high. DO NOT charge until it cools down to room temperature. The product may be unable to charge outside the temperature range 32°F to 104°F (0 to 40°C). The ideal charging temperature range is 71°F to 82°F (22°C to 28°C).

Product Storage and Transportation:

• Keep the product out of the reach of children. If any children accidentally swallow parts, seek medical attention immediately.
• If a low-battery warning appears, charge the battery before storing. Otherwise, long-term storage may damage the battery. Batteries will enter hibernation mode if depleted and stored for a long time. Recharge the product to bring the battery out of hibernation.
• DO NOT place the product near a heat source, such as a car in direct sunlight, a fire source, or a heating stove.
• Store the product in dry environments. Keep the machine away from water.
• Make sure no small metal objects can fall on or around the product while in storage.
• Never ship a product with a battery power level higher than 30%.

Product Battery Disposal:

• Dispose of the product in specific recycling boxes only after a complete discharge. Batteries are hazardous chemicals. Strictly follow your local regulations regarding battery disposal and recycling.
• Dispose of the product immediately if it cannot be powered on after over-discharging.

Product Maintenance:

• Never store the product in environments below -4°F (-20°C) or above 140°F (60°C).
• If the product is not used for a long time, the battery life may be reduced.
• Fully charge and discharge the battery at least once every 3 months to keep the battery healthy.

Travel Notice:

It is forbidden to carry lithium batteries and equipment with a capacity greater than 160Wh on airplanes due to regulations. Do Not bring this product on flights.

RIVER 600 MAX Use Care and Safety Guide

CONGRATULATIONS!

You now own the best quality Portable Battery Generator in the world. This brief pamphlet is meant to help you. Please take some time to read it before using the product. Read it through to fully understand how to use the Lithium Generator!

ℹ️ NOTICE

To turn RIVER 600 MAX on or off, you need to PRESS and HOLD the ON/OFF system Power Button. To turn on the AC power outlet, you need to PRESS and HOLD the AC Button after turning on RIVER 600 MAX. The AC power button is set for users to turn off AC power when they don't need it to save power usage. Please follow this introduction step-by-step to be familiar with each of RIVER 600 MAX's ports, buttons, display screens and more. Please fully charge (100%) your RIVER 600 MAX before use.

FCC Statement

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

⚠️ WARNING

Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

ℹ️ NOTICE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1. Orient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
4. Consult the dealer or an experienced radio/TV technician for help.

FCC Radiation Exposure Statement

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

EcoFlow App User Guide

1. EcoFlow App Download Guide

Search "EcoFlow" in the Google Play Store or App Store to download the App. You may also use your mobile phone to scan this QR code or enter the download link in your browser: https://ecoflow.com/pages/RIVER600-app-download

2. App Login and Registration Guide

1. Open your App, click on "Sign up" to register. (If you already have an account, please click on "Login").
2. Fill your information and click on "Submit" to receive the activate email.
3. Open your activation email and click the link to activate your account. Go back to the EcoFlow app to log in.

3. Device Connection Guide

Outdoor Mode: Connect to the nearby RIVER 600 MAX hotspot. Make sure the mobile phone is within the hotspot range.

1. Open your App, click on the "+" on the top right corner. Press and hold the "IOT RESET" button for more than 3 seconds on EF product. After a beep sound, your device is ready to be connected.
2. Go to your phone Settings > Wi-Fi, turn on Wi-Fi and find the new device in the network list: Ecoflow_XXXX. Tap it to make a connection.
3. Return to EcoFlow App, click on "Nearby" and wait for the device to appear. If it doesn't, please scroll down to refresh the list.

Indoor Mode: Connect to the home router (support remote control).

1. Open your App, click on the "+" on the top right corner. Press and hold the "IOT RESET" button for more than 3 seconds on EF product, after a beep sound, your device is ready to be connected. Go to your phone Settings > Wi-Fi, turn on Wi-Fi and find the new device in the network list: Ecoflow_XXXX. Tap it to make a connection. Return to EcoFlow App. Confirm the operation, and tap "Next" to continue.
2. Choose a Wi-Fi for your EF product. Your EF product can only connect to 2.4 GHz Wi-Fi networks. Enter a name for your EF product. Tap "Next" to finish adding your EF product.
3. Please confirm: Connection successful, Device info setup successful, Network setup successful, Server connection successful, Device registration successful.

If it fails to connect, move the EF product closer to the router, confirm whether it is a 2.4GHz network, and repeat the operations of the first step.

For more information about the App, please follow the instruction on the App or our official website www.ecoflow.com.

Features of the RIVER 600 MAX

Diagram Description:

The product features are illustrated with a diagram showing various ports and buttons. Key features include: LCD Display, USB-A Output Ports, LED Light ON/OFF Button, IOT Reset Button, USB-C 100W Output Port, Power Button & LCD Display Screen, DC Output ON/OFF Button (Car Outlet, 2 DC 5521 Output Ports) & DC Output Indicator, Fast Charge USB-A Output Port, AC Power Button (ON/OFF) AC Output Indicator, AC Output Sockets (100-120V or 220-240V), Ventilation Fan, X-STREAM Charging Input Port, Overload Protection Switch, Solar Charge/Car Charge Input Port, Power Earth Screw, and Ambient Light.

1. LCD Display

Displays various conditions of the product.

2. USB-A Output Ports

Charge a wide array of devices such as your iPhone, tablet, GoPro, speakers, or anything else that could be charged through USB Port. The USB Output Indicator Light will automatically light up when a USB port is in use.

3. ON/OFF Button of LED Light

There are three types of LED light: low light, strong light, and SOS rescue signal flash. Press once for low light; twice for strong light; one more time for SOS rescue signal flash; press again to turn off the LED light. Long press can turn off the LED directly.

4. IOT Reset Button (PRESS & HOLD 3s to reset WiFi)

Use to reset WiFi when first using IOT function or changing network environment. Press and hold for 3 seconds. It can connect with a mobile phone to reconfigure the wireless network through the APP. Ensure the power station has sufficient power or is connected to a power source to keep IOT standby.

5. USB-C 100W Output Port

Devices like MacBook Pro, Android phones, or others can be charged via the RIVER 600 MAX USB-C port. The USB-C Output icon will appear on the LCD Display when a USB port is in use.

6. System Power Button & LCD Display Screen ON/OFF Power Indicator

Press and hold the system power button to turn RIVER 600 MAX on or off. When on, the power indicator is in breathing mode, and the display is on. Short press the power button to turn on/off the LCD while keeping RIVER 600 MAX running. The display automatically lights up when any output port is in use. If no output port is in use, the screen enters sleep mode after 5 minutes of inactivity, but the battery continues running. After two hours in idle mode, the unit will automatically shut down (system standby time can be set via APP).

7. DC Output Port (Car Outlet, 2 DC 5521 Output Ports) DC Output Indicator

Press DC ON/OFF to turn on or off RIVER 600 MAX DC power. The 13.6V DC power button controls the car charger output and two DC 5521 outputs. The car charger output supports up to 10A, sufficient for most vehicle electrical appliances (like mini-refrigerators). It can also fully charge a 12V lead-acid car battery (under professional guidance).

8. Fast Charge USB-A Output Port

The USB-A Output Indicator Light illuminates when a USB-A port is in use. Fast charge-enabled devices can be charged at a maximum speed of 28W. Devices not supporting fast charging will charge at a normal speed.

9. AC Power Button AC Output Indicator

The AC power button controls the AC output. AC power must be turned on manually by pressing the button. To turn off AC power when not in use, press the button again. Ensure the power cord is unplugged from the AC port. The AC indicator lights up when AC power is enabled. If AC power is not used for over 12 hours, the product will automatically turn off (system standby time can be set via APP).

10. 3 AC Output Sockets (100-120V) / 2 AC Output Sockets (220-240V)

For charging devices requiring 230V (220-240V region) or 100-120V (220-240V region) wall chargers, such as laptops, TVs, mini-refrigerators, vacuums. The X-Boost function supports an additional 600W-1,200W power reduction. This function may not support all high-power devices; test to confirm before use.

11. Ventilation Fan

The fan prevents RIVER 600 from overheating. Ensure nothing blocks the vents at both ends of the RIVER 600 MAX.

12. X-STREAM Charging Input Port

Plug in an AC cable with a universal three-pin plug (15A effective current) and connect to an AC power source. The U.S. and Japanese version supports 100Vac-120Vac (50Hz/60Hz); international version supports 220Vac-240Vac (50Hz/60Hz) charging. The X-STREAM system supports an entry-level UPS function, allowing use of the AC socket while connected to a wall socket with AC power supply (grid power, not battery). If grid power is suddenly lost, the device automatically switches to RIVER 600 MAX battery power mode in <30ms for uninterrupted work. This is an entry-level UPS function that does not support 0ms switching. Do not connect devices with high uninterrupted power supply requirements. Perform multiple tests to confirm compatibility before connecting devices like data servers and workstations. EcoFlow is not responsible for data loss or equipment damage due to failure to follow instructions.

13. Overload Protection Switch

When input current continuously exceeds 10A during charging, the AC charging port triggers overload protection (Overload Protection Switch button pops out). When the device is confirmed normal, press the button to continue charging.

14. Solar Charge/Car Charge Input Port

Supports connection of up to two 110W solar panels in parallel. RIVER 600 MAX has a limit input of 200W. Supports 12V/24V car charge up to 10A (ensure the engine is running, otherwise the car battery may be drained).

15. Power Earth Screw

For safety, some electrical appliances require grounding. The power earth screw provides an option to ground your RIVER 600 MAX using a grounding cable.

16. *Ambient Light

User can set the color, brightness, and various modes of the ambient light through the EcoFlow App.

*Ambient Light

1. Status Signals

Powering up: The blue light will move from the middle to the sides.

Powering down: The blue light will move from the sides to the middle.

Charging: The blue light will move from left to right repeatedly.

2. Customizing the Ambient Light

Click Module Settings to set various functions. You can set up to turn on/off the ambient light or keep it always on (it can also be on in standby mode). Select your preferred color. Adjust the brightness. Set the lighting mode (default, breathing, flow, dynamic, rainbow). Enjoy the ambient light.

User Interface Introduction

Diagram Description:

The user interface display is shown with labels for various indicators and information:

• a. Remaining Charge/Discharge Time: Indicates remaining charge/discharge time in minutes.
• b. Battery Level Indicator: Shows remaining power. The icon rotates while charging.
• c. Battery Level Percentage: Shows the percentage of power. Charge immediately if it displays 0%.
• d. High Temperature Indicator: A warning icon appears when the temperature is too high. Cool down the product.
• e. Low Temperature Indicator: A warning icon appears when the temperature is too low. Warm up the product properly before use.
• f. Fan Indicator: Shows fan speed, which is intelligently controlled.
• g. Current Input: Shows the current input power in watts.
• h. Current Output: Shows the current output power in watts.
• i. Overload Warning: The overload icon and corresponding icon indicate the overload module.
• j. Port Usage Indicators: Indicate the usage status of each port.

Protection Information Instruction

The RIVER 600 MAX display screen uses different icons or combined icons to indicate the reason for device protection or error.

Solar Panel Connection

How to recharge the RIVER 600 MAX using solar panels?

Refer to the Solar Panel User Guide for detailed connection information. This section demonstrates connecting one or two solar panels in parallel. The RIVER 600 MAX supports a 10-25V DC input. Input exceeding 25V triggers overvoltage protection, which may damage the product. EcoFlow does not provide free repair services for damage caused by incorrect connection of solar panels.

1. Recommend Charging Method

Example 1: Connect a solar panel (not more than one in series) using an EF MC4 to XT60 solar charge cable. Connect the XT60 connector to the RIVER 600 MAX's XT60 input.

Example 2 (Parallel connection only): Connect up to 2 sets of solar panels in parallel using a solar MC4 parallel connection cable (sold separately). Connect the XT60 connector to the RIVER 600 MAX's XT60 input.

2. RIVER 600 MAX supports the use of third party solar panels (DIY solution)

Universal solar panels with MC4 connection standard can be used if voltage and current (10-25V DC, 12A Max) comply with specifications. Use the MC4 to XT60 conversion cable for charging. EcoFlow does not provide free repair services for damage caused by quality issues or improper operation of third-party solar panels.

Entry-Level UPS

RIVER 600 MAX Entry-level UPS Use Reminder

The RIVER 600 MAX's X-STREAM system supports an entry-level UPS function. You can use the AC socket while connected to a wall socket with AC power supply. When grid power is lost, the device automatically switches to battery power mode in <30ms for uninterrupted work. This UPS function does not support 0ms switching. Do not connect devices with high uninterrupted power supply requirements. Perform multiple tests to confirm compatibility for devices like data servers and workstations. EcoFlow is not responsible for data loss or equipment damage due to user failure to follow instructions. Parallel mode uses Parallel Cables to connect two products for nearly doubled power. Since the UL2743 standard socket cannot be grounded effectively, connect the grounded wire to the grounding screw port of the input end for safety.

Entry-Level UPS User Guide

Connect the AC charging cable of RIVER 600 MAX to the power grid and a device to RIVER 600 MAX. Turn on the AC switch to automatically enter the entry-level UPS mode. When external power is cut off, power is supplied from the battery immediately to protect your device.

* UPS is only applicable to electrical appliances below 600W. Do not use other equipment simultaneously to avoid OVERLOAD. EcoFlow is not responsible for abnormal operation or data loss caused by careless use. Only one RIVER 600 MAX can conduct the UPS function. Connecting more than one RIVER 600 MAX CANNOT conduct the UPS function.

AC X-Boost Mode

EcoFlow AC X-Boost allows use of 600W-1200W appliances with the RIVER 600 MAX AC inverter without overload protection disruption. This eliminates the need for different electrical devices. Traditional inverters overload with higher-rated appliances. EcoFlow AC X-Boost enables powering of 600W-1200W appliances. Note the following:

1. X-Boost mode is enabled by default. Use the App to turn it on/off. Do not connect AC output to the home grid under X-Boost mode, as low voltage protection will trip.
2. X-Boost mode is not available in parallel connection state, charging state, or when X-Boost mode is off.
3. When using appliances with a rated power of 600W-1200W, connect only one appliance. Connecting multiple devices may affect voltage and usage of other devices.

* X-Boost mode is not applicable to all devices. Some devices with strict voltage requirements (600W-1200W) are still not compatible. Conduct a full test before usage. It is recommended to use electrical equipment with heating elements and a rated power between 600-1200W, such as hair dryers, electric kettles, coffee machines.

Technical Specifications

General Specs

Outputs

Input

Battery

* Please Note: The above weight, size, etc. have certain measurement errors. Please refer to the actual measurement.

How to Recharge RIVER 600 MAX

Example 1:

Charge using AC cable. 500W Max X-STREAM charging. 0-80% charged in 1 hour, 0-100% charged in 1.6 hour (AC charging cable included).

Example 2:

Charge using Car Charger (120W Input). 0-100% charged in less than 5 hours (Car charge cable included).

How do I recharge my RIVER 600 MAX?

RIVER 600 MAX has an AC charging port and an XT60 charging port. It can be charged via AC power, 12V car charger, or solar panels connected to the XT60 solar charging port.

Can RIVER 600 MAX power my devices while it's charging?

Yes, RIVER 600 MAX can output power while being charged.

FAQs

How do I clean for RIVER 600 MAX?

Use dry, non-abrasive cloths. For thorough cleaning, use detergent for mobile phones and computer screens. Do not expose to liquid.

How do I store RIVER 600 MAX?

Store in a dry, cool place away from water. For long-term storage, charge to around 85%, turn off the main switch, and store at room temperature.

How do I use RIVER 600 MAX safely?

Use within its operating temperature range. Using it outside the range may exceed safe working limits. Do NOT immerse in water; this voids the warranty. RIVER 600 MAX is not waterproof. If powering devices with heating elements (600W) for over half an hour, over-temperature protection may occur. Wait about 1 hour before using or charging.

Can it be upgraded?

Firmware can be upgraded using the EcoFlow App. It is recommended to have RIVER 600 MAX plugged into AC or have 50% power and System Power ON when upgrading. Refer to the "How to upgrade firmware" FAQ in the APP for details.

What's in the Box

• EcoFlow RIVER 600 MAX
• AC Charging Cable (Input)
• Car Charge Cable (Input)
• Solar Charge Cable (MC4 to XT60 Input)
• DC5521-DC5525 Cable
• User Manual and Warranty Card
