Maxtec SmartStack IV Pole - Instructions for Use

Contact Information

Maxtec
2305 South 1070 West
Salt Lake City, Utah 84119
USA

Phone: (800) 748-5355

Email: sales@maxtec.com

Web: www.maxtec.com

NOTE: The latest edition of this operating manual can be downloaded from our website.

CAUTION: Federal law restricts this device to be sold by or on the order of a medical professional.

Product Overview

The SmartStack is an IV pole designed for medical use. This document provides essential information for its safe and effective operation.

Symbols and Labels

• Warning: Indicates a potentially hazardous situation.
• Do Not: Indicates an action that should not be performed.
• i (Information): Provides additional guidance.
• LOT: Lot code/Batch code.
• REF: Catalog Number.
• Federal law (USA) restricts this device to sale on or by the order of a physician.
• EC REP: Authorized Representative in the European Community.
• MD: Medical device.
• MR Unsafe: Indicates the device is not safe for use in MRI environments.
• Date of Manufacture: Manufacturing date.
• Caution: Indicates a potentially hazardous situation that may result in minor or moderate injury.

Assembly and Usage Instructions

Refer to the numbered diagrams for assembly steps. Ensure all components are correctly attached and secured.

1. Step 1: [Diagram description for step 1]
2. Step 2: [Diagram description for step 2]
3. Step 3: [Diagram description for step 3]
4. Step 4: [Diagram description for step 4]
5. Step 5: [Diagram description for step 5]
6. Step 6: [Diagram description for step 6]
7. Step 7: [Diagram description for step 7]
8. Step 8: [Diagram description for step 8]

WARNINGS

• This device is not MRI compatible.
• Never exceed 100 lbs (45 kg) on this device.
• DO NOT attach more than 11 lbs (5 kg) on one single hook. Distribute weight evenly.
• DO NOT mount equipment that places the load more than 5 inches (12 cm) off center of the pole.
• DO NOT mount more than 50 lbs (22.7 kg) on the upper portion of this device.
• Use caution when rolling a heavily loaded device, especially on uneven surfaces.
• This product should only be used under proper supervision from a healthcare professional.
• DO NOT autoclave.
• DO NOT stand on or ride this device.
• Brakes may not stop the IV pole on all surfaces.
• Follow the order of assembly as directed.
• Use caution when adjusting pole height with heavy objects mounted above hands.
• If components are damaged or missing, contact your dealer immediately.
• DO NOT use substitute parts unless provided by Maxtec or an authorized representative.
• Failure to adhere to these warnings can result in severe injury.
• Maxtec assumes no responsibility for any damage or injury caused by improper installation, assembly, or use of this product.
• Use caution if the pole is fully loaded, as the product may tip.
• Use caution around stairwells.

Cleaning

• Clean often using a cloth moistened with 65% isopropyl alcohol/water solution or a germicidal wipe.
• Clean the entire device before use.

Maintenance

Maxtec recommends inspecting this device for proper assembly and functions at least once a year.

• Inspect pole/base bolt, casters, and hook; tighten if necessary.
• Ensure the pole height adjustment mechanism functions properly.
• If the device does not function properly or is missing components, remove it from service and contact Maxtec or an authorized representative.

Warranty

4-year limited warranty on manufactured defects.

Multilingual Information

This manual is available in multiple languages including English (EN), French (FR), German (DE), Dutch (NL), Italian (IT), and Spanish (ES).
