PRUNUS J-988 Pocket AM FM Radio User Manual

1. Introduction

The PRUNUS J-988 is a compact and portable AM/FM radio designed for personal listening. Featuring digital tuning, an LCD display, and a built-in rechargeable battery, it offers clear reception and supports TF card playback for your personal music collection. Its ultra-mini design with a convenient back clip makes it ideal for on-the-go use.

2. Package Contents

• PRUNUS J-988 Pocket AM FM Radio
• Wired Earphones
• USB-C Charging Cable
• Lanyard
• Owner's Manual

3. Product Overview

The PRUNUS J-988 radio is designed for ease of use with clearly labeled buttons and a digital display. It features a compact form factor, making it highly portable.

Image 3.1: The PRUNUS J-988 radio, showcasing its compact size comparable to a key, and its control buttons. Dimensions are approximately 3.4 x 1.6 x 0.9 inches.

Image 3.2: A person walking outdoors with the PRUNUS J-988 radio conveniently clipped to their waistband using the integrated belt clip, demonstrating hands-free portability.

4. Setup

4.1. Charging the Battery

The PRUNUS J-988 features a built-in 600mAh rechargeable battery. To charge, connect the included USB-C charging cable to the radio's USB-C port and the other end to a compatible USB power source (e.g., computer, wall adapter). The battery indicator on the LCD will show charging status. A full charge provides up to 18 hours of continuous playback at maximum volume.

Image 4.1: The PRUNUS J-988 radio connected to a USB-C charging cable, illustrating the charging process.

4.2. Connecting Earphones

Insert the included wired earphones into the 3.5mm headphone jack on the radio. The earphone cable also functions as the AM/FM antenna, which is crucial for optimal reception. Ensure the cable is uncoiled for the best signal quality.

4.3. Inserting a TF Card

To play personal music files, insert a TF (Micro SD) card into the designated slot on the side of the radio. The radio supports MP3 and WAV audio formats. APE and FLAC formats are not supported.

Image 4.2: The PRUNUS J-988 radio displaying the TF card slot and indicating supported audio formats (MP3, WAV).

5. Operating Instructions

5.1. Power On/Off

Press and hold the red power button (O) to turn the radio on or off.

5.2. AM/FM Radio Operation

The radio supports FM frequencies from 87-108 MHz and AM frequencies from 520-1710 kHz.

• Auto Scan & Store Stations: With the radio on, press the SCAN button. The radio will automatically scan for available stations and save them as presets.
• Recall Preset Stations: Use the M+ and M- buttons to navigate through saved preset stations.
• Manual Tuning: Press the MODE button to switch between FM and AM bands. Use the UP and DOWN buttons to manually tune the frequency step by step.
• Preset a Station: Once you have tuned to a desired station, press the OK button to save it. Follow the on-screen prompts to select a preset number.
• Delete a Preset Station: Navigate to the preset you wish to delete using M+ or M-, then press the DEL button.

Image 5.1: The PRUNUS J-988 radio screen showing options for auto/manual save, search, recall, and delete functions for radio stations.

5.3. TF Card Playback

If a TF card is inserted, the radio will automatically switch to TF card playback mode or you can manually switch using the MODE button. Use the UP and DOWN buttons to skip tracks. The OK button can be used for play/pause.

5.4. Volume Control

Adjust the listening volume using the VOL+ and VOL- buttons.

6. Features

• Strong AM/FM Reception: Equipped with a US DSP chip for clear and stable reception. The headphone cable acts as the antenna.
• Portable Design: Ultra-mini size (3.4 x 1.6 x 0.9 inches, 2 oz) with a back clip for easy carrying.
• Digital Tuning & Presets: Supports automatic and manual station presets, saving up to 99 FM and 99 AM stations.
• TF Card Playback: Play your own music files (MP3, WAV) from a TF card without internet access.
• USB-C Rechargeable: Built-in 600mAh battery provides up to 18 hours of playback, charged via USB-C.

Image 6.1: Illustration highlighting the DSP chip for strong AM/FM reception and various radio frequencies available.

7. Specifications

8. Troubleshooting

• No Power: Ensure the battery is charged. Connect the radio to a USB power source using the USB-C cable.
• Poor Radio Reception: Ensure the wired earphones are fully plugged in and their cable is uncoiled and extended, as it acts as the antenna. Try moving to a different location or adjusting the earphone cable's position.
• No Sound: Check the volume level. Ensure earphones are properly connected.
• TF Card Not Playing: Ensure the TF card is inserted correctly. Verify that the audio files are in MP3 or WAV format. Reformat the TF card if necessary (this will erase all data).
• Buttons Unresponsive: Try turning the radio off and then on again. If the issue persists, allow the battery to fully discharge and then recharge it.

9. Maintenance

• Cleaning: Use a soft, dry cloth to clean the radio's exterior. Do not use liquid cleaners or abrasive materials.
• Storage: Store the radio in a cool, dry place away from direct sunlight and extreme temperatures.
• Battery Care: For optimal battery life, avoid fully discharging the battery frequently. Recharge the radio regularly, even if not in use for extended periods.

10. Warranty and Support

This PRUNUS J-988 radio comes with a 1-year seller warranty. For any product-related inquiries, technical support, or warranty claims, please contact the seller directly through your purchase platform.
