Cecotec Cecofry DuoLevel 10000 Air Fryer Instruction Manual

1. Safety Instructions

Please read all instructions carefully before using the Cecotec Cecofry DuoLevel 10000 Air Fryer. Retain this manual for future reference.

• Do not immerse the appliance, cord, or plug in water or other liquids.
• Ensure the voltage indicated on the appliance matches your local mains voltage before connecting.
• Keep the appliance out of reach of children and pets.
• Do not operate the appliance if the plug, power cord, or the appliance itself is damaged.
• Always unplug the appliance when not in use and before cleaning. Allow it to cool down completely before handling.
• Do not place the appliance against a wall or other appliances. Leave at least 10 cm of free space on the back, sides, and above the appliance.
• Do not place anything on top of the appliance.
• During hot air frying, hot steam is released through the air outlet openings. Keep your hands and face at a safe distance from the steam and the air outlet openings.
• The surfaces may become hot during use. Do not touch hot surfaces directly. Use handles or oven mitts.
• This appliance is intended for household use only.

2. Product Overview

The Cecotec Cecofry DuoLevel 10000 is a 10-liter air fryer designed for efficient and healthy cooking. It features two independent 5-liter baskets, allowing you to cook two different dishes simultaneously or larger quantities of a single dish. Its vertical design optimizes counter space.

Image: The Cecotec Cecofry DuoLevel 10000 Air Fryer positioned on a kitchen counter, surrounded by plates of prepared food, demonstrating its capacity and versatility.

This appliance is equipped with a powerful 2400W heating system and a user-friendly touch control panel, offering 6 pre-configured programs for quick and convenient meal preparation.

3. Key Features

• 10-Liter Total Capacity: Two stackable 5-liter baskets allow for cooking large meals or multiple dishes simultaneously.
• Dual-Zone Cooking: Cook two different foods at different temperatures and times, or use the Sync function to finish cooking simultaneously.
• 2400W Power: Ensures fast and efficient cooking for various recipes.
• Touch Control Panel: Intuitive and practical interface for easy operation.
• 6 Pre-configured Programs: Dedicated settings for common dishes, simplifying cooking.
• Adjustable Temperature: Temperature range from 35°C to 210°C for precise cooking control.
• Timer Function: Set cooking times up to 60 minutes (or longer for specific functions).
• Includes Raised Racks: Two raised racks allow for up to 4 layers of food to be cooked evenly.

Image: An internal view of the air fryer, illustrating the heating elements and the two levels of racks for cooking different items simultaneously.

4. Setup and First Use

4.1 Unpacking

1. Carefully remove the air fryer and all accessories from the packaging.
2. Remove any stickers or labels.
3. Check that all components are present and undamaged.

4.2 Initial Cleaning

1. Wipe the exterior of the appliance with a damp cloth.
2. Wash the baskets, racks, and any removable accessories with hot soapy water. Rinse thoroughly and dry completely.
3. Do not use abrasive cleaning agents or scouring pads.

4.3 Placement

• Place the air fryer on a stable, heat-resistant, and level surface.
• Ensure there is adequate ventilation around the appliance (at least 10 cm clearance on all sides).
• Do not place the appliance near flammable materials or heat sources.

4.4 Pre-heating (Optional but Recommended)

• Plug the appliance into a grounded wall outlet.
• Turn on the appliance. Set the temperature to 200°C and the timer to 10 minutes.
• A slight odor or smoke may be present during the first use; this is normal and will dissipate.

5. Operating Instructions

5.1 General Operation

1. Place food into the desired basket(s). Do not overfill. For best results, use the included racks to create multiple layers if needed.
2. Slide the basket(s) back into the appliance until they click into place.
3. Plug in the air fryer. The control panel will illuminate.
4. Select a preset program or manually set the temperature and time.
5. Press the Start/Pause button to begin cooking.
6. During cooking, you can pull out the baskets to shake or turn food. The appliance will pause automatically and resume when the basket is reinserted.
7. Once cooking is complete, the timer will sound. Carefully remove the baskets and transfer food to a serving plate.

Image: Demonstrates how to safely remove a cooking basket from the air fryer, showing cooked food inside.

5.2 Using the Control Panel

Image: A detailed view of the air fryer's touch control panel, displaying various preset icons and control buttons for temperature and time.

• Power Button: Turns the appliance on/off.
• Preset Programs: Icons represent different food types (e.g., fries, chicken, fish, cake). Touch an icon to select a program. The default time and temperature will be displayed.
• Temperature Control: Use the +/- buttons or dial to adjust the temperature (35°C - 210°C).
• Time Control: Use the +/- buttons or dial to adjust the cooking time.
• Basket Selection (1/2): If using only one basket, select which basket to control.
• SYNC Function: Allows two different programs in each basket to finish cooking at the same time. Select programs for both baskets, then press SYNC.
• MATCH Function: Copies the settings from one basket to the other, useful for cooking the same food in both baskets.
• Start/Pause Button: Begins or temporarily stops the cooking process.

5.3 Cooking Tips

• For crispy results, lightly coat food with oil.
• Shake the baskets halfway through cooking for even browning, especially for smaller items like fries.
• Use oven-safe accessories (e.g., silicone molds, small baking dishes) in the baskets for certain recipes.
• Refer to a reliable air fryer recipe guide for specific cooking times and temperatures for various foods.

6. Cleaning and Maintenance

Regular cleaning ensures optimal performance and extends the lifespan of your air fryer.

1. Unplug and Cool: Always unplug the appliance and allow it to cool down completely before cleaning.
2. Clean Baskets and Racks: Wash the cooking baskets and racks with hot soapy water. For stubborn food residue, soak them in warm water for about 10-15 minutes before cleaning. They are generally dishwasher safe, but hand washing is recommended to prolong their non-stick coating.
3. Clean Interior: Wipe the interior of the appliance with a damp cloth. If necessary, use a soft brush to remove food residue from the heating element, ensuring the appliance is unplugged and completely cool.
4. Clean Exterior: Wipe the exterior with a damp cloth. Do not use abrasive cleaners or immerse the main unit in water.
5. Storage: Ensure all parts are clean and dry before storing the air fryer in a cool, dry place.

7. Troubleshooting

If you encounter issues with your air fryer, consult the following table before contacting support.

8. Technical Specifications

9. Warranty and Support

Cecotec products are manufactured to high-quality standards. For detailed warranty information, please refer to the warranty card included with your purchase or visit the official Cecotec website.

If you require technical assistance, have questions about your product, or need to report a defect, please contact Cecotec customer support through their official channels. Keep your proof of purchase handy when contacting support.

• Online Support: Visit the official Cecotec website for FAQs, troubleshooting guides, and contact forms.
• Customer Service: Refer to your product packaging or the Cecotec website for regional customer service contact details.
