1. Product Overview
The Bazyths ZYS1 Mini Smart Compact Toilet is designed to enhance your bathroom experience with advanced features and a space-saving design. This one-piece toilet integrates a built-in bidet, automatic lid operation, and various comfort functions.
Figure 1: Bazyths ZYS1 Mini Smart Compact Toilet, showcasing its compact 23-inch depth.
Compact and Space-Saving Design
The ZYS1 Mini is specifically engineered for small bathrooms and tight spaces, offering a shallow depth of 23.23 inches to maximize usability in powder rooms and compact areas.
Figure 2: Dimensional comparison illustrating the compact design of the ZYS1 Mini against a standard toilet.
Wider Seat for Enhanced Comfort
Featuring a 3.54-inch extra-wide seat, this toilet provides improved comfort and support, suitable for various users including seniors, pregnant individuals, and those with larger body types.
Figure 3: Comparison of the ZYS1 Mini's 3.54-inch wide seat with a narrower 2.95-inch seat from another small toilet.
2. Setup and Installation
Included Components
- Smart Toilet Main Unit
- Remote Control
- Angle Valve & Tee Connector
- Sealing Flange & Mounting Accessory Kit
- User Manual
Figure 4: Product dimensions and a list of included accessories for installation.
Power Requirements
- The power cord is 1.2 meters (approximately 3.9 feet) long.
- The toilet operates on standard US voltage: 110V–120V.
- Ensure the electrical outlet is GFCI (Ground-Fault Circuit Interrupter) protected, either at the receptacle or in the breaker box, for safety.
Remote Control Pairing
To pair the remote control with the toilet:
- Plug in the power cord within 30 seconds after the toilet is powered on.
- Press and hold the feminine wash button on the toilet's side panel until the display flashes once.
- Then, press and hold the rear wash button on the toilet's side panel. The display screen will flash continuously.
- While the display is flashing, press the power stop button on the remote control. Pairing is successful when the display stops flashing.
Video 1: Instructions for pairing the remote control with the Bazyths ZYS1 Mini smart toilet.
3. Operating Instructions
Automatic Lid Opening/Closing and Foot Sensor
The toilet lid automatically opens when a user approaches. Both the lid and seat close automatically 2 minutes after the user leaves the sensor range. A foot sensor allows for touchless operation to open/close the lid or seat and to flush.
Figure 5: Automatic lid opening and foot sensor functionality for hygienic, touchless operation.
Figure 6: Detailed sequence of touch-free operation, including adjustable sensing range.
Video 2: Demonstration of the automatic lid, foot sensor, and flushing features.
Flushing System
The ZYS1 Mini features a built-in tank design, eliminating reliance on external water pressure and allowing operation even under zero water pressure conditions. It utilizes a water-saving flush of 1.03 gallons per use.
- Off-Seat Flush: The toilet automatically flushes when the user leaves the seat.
- Quiet Operation: The flushing system is designed to significantly reduce noise.
Figure 7: Illustration of the dual power flush system, including the built-in tank and assist water pump, designed for stable flushing under various water pressure conditions.
Bidet Functions (Rear & Front Warm Water Cleaning)
Personalize your cleansing experience with four modes and adjustable settings:
- Modes: Rear wash, feminine wash, oscillating wash, and warm/cool wash.
- Adjustable Settings: Tailor spray position, water temperature (room temperature, 95°F, 100°F, 104°F), and pressure.
Figure 8: Automatic cleaning features, including adjustable water temperature and nozzle functions.
Figure 9: Instant heating for water and various cleaning modes for personalized hygiene.
Heated Seat
The seat includes built-in temperature sensors that automatically adjust the seat temperature based on the room's temperature, ensuring comfortable warmth. Automatic seat heating can be turned on or off via the remote control.
Figure 10: Adjustable seat, water, and dryer temperatures for personalized comfort.
Figure 11: Automatic seat temperature adjustment for comfort across all seasons.
Warm Air Dryer
The warm air dryer offers four adjustable temperature settings (room temperature, 95°F, 113°F, 131°F) with a 3-minute drying cycle for efficient drying.
Figure 12: Powerful warm air dryer with four adjustable temperature settings.
Nightlight and LED Display
The toilet features a frameless LED display and a gentle nightlight for safe and undisturbed use during nighttime.
Figure 13: Frameless LED display and gentle night guidance for low-light conditions.
Video 3: Demonstration of the night light feature on the Bazyths smart toilet.
Remote Control and Side Buttons
All features can be easily controlled with the included remote or via the intelligent side control buttons on the toilet unit.
Figure 14: Overview of the intelligent side control buttons and the remote control for comprehensive feature management.
4. Maintenance
High-Density Foam Shield
The advanced foam shield technology creates a dense barrier to control splashes and block odors, ensuring a cleaner and fresher bathroom experience.
Figure 15: Foam shield in action, demonstrating its effectiveness in preventing splashes and blocking odors.
Figure 16: Explanation of the high-density foam shield's benefits, including leak-proof comfort, antibacterial protection, odor blocking, and anti-stick properties.
Self-Cleaning and Detachable Nozzle
The bidet nozzle self-cleans before and after each use. It is also detachable for easy manual maintenance, ensuring high hygiene standards.
Figure 17: Overview of enhanced cleanliness features, highlighting the self-cleaning and detachable nozzle.
5. Troubleshooting
Water Droplets Inside the Toilet
It is normal to find water droplets inside the toilet upon opening the box. Each toilet undergoes a water test before shipping to ensure proper function. Any residual water is from this quality check and is not a defect.
Power-Off Flushing
Equipped with a built-in battery compartment (requires 10 AA alkaline batteries, not included), this smart toilet supports flushing during power outages, ensuring functionality even without electrical power.
Figure 18: Power-off flushing capability with a backup battery box for continued use during outages.
6. Specifications
- Color: White
- Product Dimensions: 23.23"D x 15.35"W x 18.31"H
- Material: Ceramic, Plastic
- Item Weight: 85 Pounds
- Installation Type: Floor Mounted
- Shape: Compact
- Seat Material Type: Plastic
- Item Model Number: ZYS1 Mini
- Item Package Quantity: 1
- Batteries Included?: No
- Batteries Required?: No
7. Safety Information
8-Layer Safety Protection
The Bazyths ZYS1 Mini Smart Compact Toilet is equipped with multiple safety features to ensure user protection and product longevity.
- Seat Temperature Protection
- Dry Burning Protection
- Flame-Retardant Material
- Leakage Protection
- Water Temperature Protection
- Voltage Protection
- Air Temperature Protection
- IPX4 Waterproof (No need for Dry-Wet Separation)
Figure 19: Visual representation of the 8-layer safety protection system.
General Warnings
- Do not dismantle or repair the product without authorization. The smart toilet contains precision components; do not pour water or detergent on the product or power plug.
- Always use GFCI-protected safety sockets. All power sockets must be grounded and installed by a licensed electrician.
- Be aware of the risk of low-temperature burns. Set the temperature to "low" when using the toilet for extended periods.
- Do not step on the toilet lid or seat. Do not forcefully open or close the toilet lid, which may cause damage.
- Lit cigarettes and other flammable objects should not be placed in the toilet.
- Clean soiled areas using a dry, soft cloth. Avoid using chemical cleaners or harsh chemicals on the product.
- When using the product, ensure children do not pour water on it. If the product will not be used for an extended period, close the water inlet valve and unplug the power plug to disconnect the power supply.
8. Warranty and Support
For customer support or inquiries, please contact Bazyths. We are committed to quality and aim to improve your daily routine.
This product is returnable until January 31, 2026.
