Ultra Clean Smart Bidet Toilet Instruction Manual

Product Overview

The Bazyths Ultra Clean Smart Bidet Toilet (Model ZYC8A) is an advanced one-piece toilet designed for enhanced hygiene and comfort. It integrates a built-in tank, smart features like automatic lid opening/closing, foot sensor operation, and a comprehensive cleansing system. This manual provides essential information for installation, operation, and maintenance to ensure optimal performance and longevity of your smart toilet.

Bazyths specializes in smart bidet toilets and seats that combine advanced technology and ergonomic design for an enhanced bathroom experience. Our products feature auto open/close, auto flush, smart sensors, warm water cleansing, and air drying for comfort and ease. Committed to quality, we aim to improve your daily routine.

Key Features

• Compatible with Toilet Cleaning Tablets: Features a built-in compartment for dissolvable cleaning tablets that release with each flush, aiding in waste breakdown, deodorizing, and maintaining bowl cleanliness without residue or clogging.


  Image: The toilet features a dedicated slot for cleaning tablets, ensuring a fresh bowl with every flush.
• High-Density Foam Shield: Advanced foam technology creates a dense barrier to effectively control splashes and block odors, ensuring a cleaner and fresher bathroom experience.


  Image: A protective foam layer covers the water surface, preventing splashes and containing odors.

  Video: Demonstrates the Bazyths Foam Shield in action, highlighting its ability to keep the toilet cleaner and fresher.
• Wider Seat Design: The 3.94-inch extra-wide seat provides enhanced comfort and support, ideal for seniors, pregnant women, and individuals with larger body types.
• Convenient Features: Includes automatic opening/closing lid, foot operation for lid/seat and flush, rear and front cleaning, warm air dryer, instant warm water, heated seat, off-seat flush, water-saving flush (1.03 gallons/use), nightlight, and LED display, all controlled with the included remote.
• Automatic Opening Toilet: The lid automatically opens upon approach and closes 2 minutes after departure. The foot sensor allows touch-free lid/seat operation and flushing.


  Image: The toilet lid automatically opens as a user approaches, demonstrating the smart sensor functionality.

• Built-in Tank & No Water Pressure Limit: The built-in tank design resolves low or unstable water pressure issues, allowing operation under zero water pressure. The flushing system significantly reduces noise for a quiet experience.


  Image: An internal view showing the built-in water tank, which ensures consistent water pressure regardless of external supply.
• Powerful Warm Air Dryer: Offers quicker and more efficient drying with a 3-minute cycle and four adjustable temperature settings (room temperature, 95°F, 113°F, 131°F) for personalized comfort, especially in colder months.


  Image: Visual representation of the heated seat and adjustable warm air dryer temperatures for user comfort.

• Rear & Front Warm Water Cleaning: Four modes available: rear wash, feminine wash, oscillating wash, and warm/cool wash. Adjustable spray position, water temperature, and pressure ensure a personalized cleansing experience.
• One-Press Quick Mode (Wash + Flush + Dry): A single side button press (rear or feminine wash) initiates a sequence of wash (90 seconds), automatic flushing, and a 3-minute drying cycle.
• Self-Cleaning & Detachable Nozzle: The nozzle self-cleans before and after each use for high hygiene standards. Its detachable design allows for easy and convenient cleaning.

Setup and Installation

For detailed installation instructions, please refer to the Installation Manual (PDF). Key considerations include:

• Power Outlet: Ensure a standard 110V–120V power outlet is near the toilet for operation.
• Water Supply: The built-in tank design allows operation under zero water pressure. An angle valve and tee connector are included.
• Dimensions: Product dimensions are 27.83"D x 15.31"W x 17.95"H. Ensure adequate space for installation.
• Included Components: Smart Toilet Main Unit, Sealing Flange & Mounting Accessory Kit, User Manual, Angle Valve & Tee Connector, Remote Control.
• Battery Backup: A backup battery box is included for flushing during power outages (requires 10 AA alkaline batteries, not included).

Image: Overview of the toilet's dimensions and all components included in the package for installation.

Video: A step-by-step guide on how to install the Bazyths Smart Toilet, suitable for beginners.

Operating Instructions

Automatic Functions

• Auto Open/Close: The toilet lid automatically opens when a user approaches and closes 2 minutes after the user leaves the sensor range.
• Foot Sensor: Tap your foot against the sensor at the base of the toilet to open/close the lid or seat, and to flush.
• Off-Seat Flush: The toilet automatically flushes when the user leaves the seat.

Cleansing and Drying

• Rear & Feminine Wash: Activate via remote or side buttons. Adjust spray position, water temperature, and pressure for comfort.
• Oscillating Wash: Provides a wider, more thorough cleaning.
• Warm/Cool Massage: The nozzle alternates between warm and cool water for a massaging effect.
• Warm Air Dryer: Activate via remote. Choose from four temperature settings (room temperature, 95°F, 113°F, 131°F). Cycle lasts up to 3 minutes.
• Heated Seat: Adjustable temperature settings (room temperature, 95°F, 100°F, 104°F). Can be set to auto-adjust based on room temperature.

Control Options

• Remote Control: Provides full access to all functions from a distance. Includes buttons for water temp, wind temp, seat temp, cleansing modes, flushing, and foam shield.
• Side Control Buttons: Integrated buttons on the toilet for essential functions like front/female wash, rear wash, and stop/flush.
• Multi-Color Ambient Lighting: 64 adjustable levels. Use the remote to cycle through options (long press ambient light button, then use rear/feminine wash buttons).

Image: The remote control displays various functions for personalized settings of the smart toilet.

Maintenance

• Nozzle Cleaning: The nozzle performs a self-cleaning cycle before and after each use. It is also detachable for manual cleaning.
• Toilet Bowl Cleaning: Utilize dissolvable cleaning tablets in the built-in compartment for continuous bowl hygiene.
• Foam Shield Maintenance: The foam shield helps keep the bowl clean and fresh. Ensure the foam agent reservoir is adequately filled.

Troubleshooting

• Water Droplets in Box: It is normal to find water droplets inside the toilet upon opening the box. Each toilet undergoes a water test before shipping to ensure proper function.
• Power Outage: The toilet has a backup battery box (requires 10 AA batteries, not included) to enable flushing during a power outage.
• Instruction Manual Clarity: If the included manual is unclear, refer to the official User Guide (PDF) for more detailed and translated instructions.
• Ambient Light Control: If the remote control for ambient light is not functioning as expected, try a long press on the night light button until the LED display shows a mode number (1-64), then use the wash buttons to cycle through options. A long press can also toggle the light completely off/on.

Specifications

Warranty and Support

For any product inquiries or support, please visit the Bazyths Store.

Protection plans are available for purchase:

• 3-Year Protection Plan: $78.99
• 4-Year Protection Plan: $104.99
• Complete Protect: $16.99/month (covers all eligible past and future purchases)

The product comes with a 30-day easy returns policy.
