1. Introduction
Thank you for choosing the Zinus Evelyn Upholstered Platform Bed Frame. This manual provides essential information for the safe and efficient assembly, operation, and maintenance of your new bed frame. Please read all instructions carefully before beginning assembly and retain this manual for future reference.
2. Safety Warnings
- Assemble with care, following all instructions precisely to prevent instability or collapse.
- Do not exceed the maximum recommended weight capacity of 160 kg (352.74 lbs) for the single size, or 318 kg (700 lbs) for all other sizes.
- Exercise caution when cleaning with a damp cloth to avoid injury from sharp edges or other hazards.
- Keep small parts away from children during assembly.
3. Setup and Assembly
Your Zinus Evelyn bed frame is designed for straightforward assembly. All necessary parts, tools, and instructions are conveniently packed within the zippered compartment located in the back of the headboard. We recommend two people for assembly, which typically takes less than one hour.
3.1 Unpacking and Part Identification
Carefully unpack all components. Verify that all parts listed in the instruction manual are present before proceeding. The compact packaging ensures all items are contained within a single box.
Figure 1: Compact packaging with parts and tools stored in the headboard.
3.2 Assembly Steps
Follow the step-by-step instructions provided in the included assembly guide. The system uses numbered parts and a time-saving ratchet tool for quick setup.
Figure 2: Visual guide illustrating the simple 1-2-3 assembly process.
Figure 3: Detail of the assembly process, highlighting the use of the included ratchet tool.
4. Operation and Usage
The Zinus Evelyn bed frame is designed to provide robust support for your mattress, enhancing its lifespan and ensuring a quiet sleeping environment.
4.1 Mattress Support
The bed frame features durable bamboo slats engineered to support any mattress type without the need for a box spring. The steel inner frame and dense foam padding contribute to comfort and longevity.
Figure 4: The Zinus Evelyn bed frame fully assembled with a mattress.
Figure 5: Front view of the Zinus Evelyn bed frame, showcasing the upholstered finish.
Figure 6: Side view of the Zinus Evelyn bed frame, highlighting the wingback headboard design.
4.2 Noise Reduction
The bamboo slats are designed to minimize noise, ensuring a quiet and undisturbed sleep experience.
Figure 7: Detail of the durable bamboo slats and robust frame construction.
5. Maintenance
Proper maintenance will help preserve the appearance and longevity of your Zinus Evelyn bed frame.
5.1 Cleaning
For general cleaning, wipe the upholstered surfaces with a soft, damp cloth. Avoid using harsh chemicals or abrasive cleaners, as these can damage the fabric. Ensure the cloth is only damp, not wet, to prevent moisture damage to the frame components.
5.2 Regular Checks
Periodically check all bolts and connections to ensure they remain tight. Re-tighten if necessary to maintain stability and prevent squeaking.
6. Troubleshooting
If you encounter any issues with your bed frame, refer to the following common solutions:
- Squeaking Noises: Squeaking often indicates loose connections. Re-tighten all bolts and screws, especially those connecting the side rails to the headboard and footboard, and the center support legs.
- Instability: If the frame feels unstable, ensure all components are correctly assembled according to the instructions. Check that all legs are firmly on the ground and that the center support legs are properly installed.
- Missing Parts: If any parts were missing upon delivery, please contact Zinus customer support immediately.
7. Specifications
| Feature | Detail |
|---|---|
| Brand | Zinus |
| Model Number | EU-FPPWB3-38E |
| Color | Dark Grey |
| Material | Bamboo (slats), Steel (inner frame), Upholstered Fabric |
| Product Dimensions (L x W x H) | 195L x 96W x 96H cm (Overall) |
| Bed Height (from floor to top of frame) | 25 cm |
| Item Weight | 15.6 Kilograms |
| Compatible Mattress Size | 90 x 190 cm |
| Maximum Weight Capacity (Single) | 159 kg (350 lbs) |
| Maximum Weight Capacity (Other Sizes) | 318 kg (700 lbs) |
| Special Feature | Easy to install |
Figure 8: Detailed dimensions of the Zinus Evelyn bed frame.
8. Warranty and Support
The Zinus Evelyn Upholstered Platform Bed Frame includes a 5-year limited worry-free warranty. For warranty claims, missing parts, or any other product-related inquiries, please contact Zinus customer support through their official website or the retailer where the product was purchased. Please have your model number (EU-FPPWB3-38E) and proof of purchase ready.
