CAMRY CR 8076 Portable Refrigerator 38L Instruction Manual

1. Introduction

This manual provides essential information for the safe and efficient operation of your CAMRY CR 8076 Portable Refrigerator. Please read these instructions carefully before using the appliance and retain them for future reference. The CAMRY CR 8076 is a versatile portable cooling unit designed for extended storage of temperature-sensitive products, featuring both a refrigerator and a freezer compartment.

2. Safety Instructions

WARNING: Failure to follow these safety instructions may result in fire, electric shock, or injury.

• Read all instructions before operating the appliance.
• Ensure proper ventilation around the unit. Do not block ventilation openings.
• Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.
• Connect the appliance only to a suitable power source as indicated in the specifications.
• Keep the appliance away from direct heat sources and direct sunlight.
• Do not immerse the appliance or its power cord in water or other liquids.
• Unplug the appliance from the power source before cleaning or performing any maintenance.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.

3. Product Overview

The CAMRY CR 8076 portable refrigerator features a robust design with dual compartments for flexible cooling and freezing. It includes an intuitive control panel for temperature management.

Figure 3.1: Front view of the CAMRY CR 8076 portable refrigerator, highlighting the digital control panel and the CAMRY Premium logo.

Figure 3.2: The refrigerator with both lids open, illustrating the two distinct cooling compartments. The left compartment is the refrigerator (15L) and the right is the freezer (23L).

Figure 3.3: Capacity distribution: 15 liters for the refrigerator section and 23 liters for the freezer section.

Figure 3.4: Rear view of the unit, displaying the ventilation system and the technical parameter label.

4. Setup

1. Unpacking: Carefully remove the refrigerator from its packaging. Inspect for any damage during transit.
2. Placement: Place the refrigerator on a stable, level surface. Ensure there is adequate space (at least 10 cm) around all sides for proper ventilation. Avoid placing it in direct sunlight or near heat sources.
3. Power Connection: Connect the provided power cable to the refrigerator's power input port.


Figure 4.1: The included 12V power cable for connecting to a car cigarette lighter socket.

4. Initial Power-Up: Plug the other end of the power cable into a suitable 12V DC power source (e.g., car cigarette lighter socket). The unit will power on, and the LCD display will illuminate.
5. Pre-cooling: For optimal performance, allow the refrigerator to operate empty for at least 30 minutes to reach the desired temperature before loading items.

5. Operating Instructions

5.1 Control Panel

The control panel, located on the front of the unit, allows you to manage the refrigerator's settings. It typically includes a digital display and control buttons.

• LCD Display: Shows the current temperature of each compartment and other operational data.
• Temperature Adjustment Buttons: Use these buttons (often marked '+' and '-') to set the desired temperature for each compartment.
• Mode Button: Cycles through different operating modes or settings.

5.2 Temperature Settings

• Freezer Compartment: Adjustable from -20 °C to +10 °C.
• Refrigerator Compartment: Adjustable from +2 °C to +10 °C.
• The refrigerator compartment features automatic temperature level control via a thermostat.

5.3 Power Protection Modes

The unit is equipped with 3 discharge protection modes to prevent excessive draining of your vehicle's battery. Refer to the full user manual for detailed instructions on how to select and adjust these modes.

5.4 Parameter Saving Function

The refrigerator includes a parameter saving function, which retains your last settings even after a power failure, ensuring consistent operation when power is restored.

6. Maintenance

6.1 Cleaning

• Always unplug the refrigerator before cleaning.
• Wipe the interior and exterior surfaces with a soft cloth dampened with mild detergent and water.
• Do not use abrasive cleaners, solvents, or sharp objects, as these can damage the surfaces.
• Ensure all surfaces are dry before reconnecting power.

6.2 Defrosting

The unit features an automatic defrost system. If ice buildup occurs, manually defrost by unplugging the unit and allowing the ice to melt naturally. Drain any water and wipe the interior dry before restarting.

6.3 Storage

When storing the refrigerator for an extended period, ensure it is clean, dry, and the lid is slightly ajar to prevent odors and mildew.

7. Troubleshooting

If you encounter issues with your CAMRY CR 8076, refer to the following common problems and solutions:

For problems not listed here, or if solutions do not resolve the issue, please contact customer support.

8. Specifications

9. Warranty and Support

For warranty information, please refer to the documentation provided at the time of purchase or contact your retailer. For technical support or service inquiries, please contact CAMRY customer service through their official website or the contact details provided in your purchase documentation.
