B.K.Licht LED Panel Light 1000x250mm User Manual

1. Safety Instructions

Please read these instructions carefully before installation and use. Keep this manual for future reference.

• Ensure the main power supply is disconnected before attempting any installation, maintenance, or cleaning.
• Installation should be performed by a qualified electrician if you are unsure about electrical wiring.
• This product is designed for indoor use only. Do not expose to moisture or extreme temperatures.
• Do not modify the product in any way. Unauthorized modifications may void the warranty and pose safety risks.
• Do not use this LED panel with external dimmers. Dimming is exclusively controlled by the provided remote control.
• Keep the remote control and small parts out of reach of children.

2. Product Overview

The B.K.Licht LED Panel Light 1000x250mm is a modern, ultra-flat ceiling fixture designed for various indoor spaces. It offers versatile lighting options with adjustable brightness and color temperature, controlled conveniently via a remote.

Image 2.1: B.K.Licht LED Panel Light with remote control, illustrating its dimmable and CCT features.

Key Features:

• Dimmable: Adjust light intensity to your preference.
• Color Temperature Control (CCT): Switch between Warm White (3000K), Neutral White (4000K), and Cool White (6500K).
• Remote Control: Conveniently manage all functions from a distance.
• Night Light Function: Provides a soft, low-intensity light.
• Timer Function: Automatically turns off the light after 30 minutes.
• Memory Function: Retains the last used settings when turned off and on.
• Ultra-flat Design: Sleek profile for modern interiors.

Image 2.2: Visual representation of the panel's dimming, CCT, and ultra-flat characteristics.

3. Setup and Installation

This section provides instructions for safely installing your LED Panel Light. Ensure you have read the safety instructions before proceeding.

3.1 Package Contents:

• 1x B.K.Licht LED Panel Light
• 1x Remote Control
• 4x Anchors
• 4x Screws
• Insulation Sleeves

Image 3.1: All mounting hardware and accessories included with the LED panel.

3.2 Tools Required (Not Included):

• Drill
• Screwdriver
• Pencil
• Measuring Tape

3.3 Installation Steps:

1. Disconnect Power: Before starting, turn off the main power supply at your circuit breaker to prevent electrical shock.
2. Mark Drilling Points: Position the mounting bracket on the ceiling where you intend to install the light. Use a pencil to mark the drilling points. The distance between the drilling holes is 65mm.
3. Drill Holes and Insert Anchors: Drill holes at the marked positions and insert the provided anchors flush with the ceiling surface.
4. Secure Mounting Bracket: Attach the mounting bracket to the ceiling using the provided screws. Ensure it is firmly secured.
5. Connect Electrical Wires: Carefully connect the electrical wires from your ceiling to the terminal block on the LED panel. Ensure Live (L), Neutral (N), and Ground (E) wires are connected correctly and securely. Use the insulation sleeves for protection.
6. Attach LED Panel: Carefully align the LED panel with the mounting bracket and secure it.
7. Restore Power: Once installation is complete and all connections are secure, restore power at the circuit breaker.

4. Operating Instructions

Your B.K.Licht LED Panel Light is operated using the included remote control. Ensure batteries are inserted correctly into the remote control.

Remote Control Functions:

• ON/OFF: Press the 'ON' button to turn the light on, and 'OFF' to turn it off.
• Brightness Adjustment (Dimming): Use the brightness buttons (sun icons) to increase or decrease the light intensity.
• Color Temperature Control (CCT): Use the CCT buttons (sun/snowflake icons) to cycle through or select specific color temperatures:
  • 3000K (Warm White): For a cozy and relaxing atmosphere.
  • 4000K (Neutral White): Ideal for general illumination and daily tasks.
  • 6500K (Cool White): Bright, invigorating light suitable for work areas.
• Night Light Function: Activates a very low brightness setting for subtle illumination.
• Timer Function: Press the timer button to set the light to automatically turn off after 30 minutes.
• Memory Function: The light will remember your last brightness and color temperature setting when it is turned off and then back on.

Image 4.1: Illustration of the adjustable color temperature range (3000K to 6500K).

Important Note: The dimming function is exclusively controlled by the provided remote control. Do not connect this LED panel to an external dimmer switch, as this may damage the product.

5. Maintenance

Proper maintenance ensures the longevity and optimal performance of your LED Panel Light.

• Always disconnect power before cleaning.
• Clean the surface of the LED panel with a soft, dry cloth.
• Do not use abrasive cleaners, solvents, or harsh chemicals, as these can damage the finish and electronic components.
• There are no user-serviceable parts inside the LED panel. Do not attempt to open or repair the unit.

6. Troubleshooting

If you encounter issues with your LED Panel Light, refer to the following common problems and solutions:

• Light does not turn on:
  • Check if the main power supply is connected and switched on.
  • Ensure the remote control batteries are correctly inserted and have sufficient charge. Replace if necessary.
  • Verify that the electrical wiring connections are secure and correct.
• Remote control not working:
  • Check the battery polarity and charge. Replace batteries if they are old or depleted.
  • Ensure there is a clear line of sight between the remote control and the LED panel.
  • Make sure you are within the effective range of the remote control.
• Light flickers or behaves erratically:
  • Ensure all electrical connections are tight and secure.
  • Confirm that no external dimmer switch is connected to the light fixture.
  • If the issue persists, disconnect power and consult a qualified electrician.

7. Specifications

8. Warranty and Support

For warranty information, technical support, or any questions regarding your B.K.Licht LED Panel Light, please contact your retailer or the manufacturer directly. Keep your proof of purchase for warranty claims.
