1. Introduction
This manual provides essential information for the safe and efficient installation, operation, and maintenance of your AVERA C6L Instant LP Gas Water Heater. Please read this manual thoroughly before installation and use, and keep it for future reference.
The AVERA C6L is designed to provide instant hot water for one service point, with a capacity of 6 liters per minute. Its compact design, combined with a copper coil and flame detector, ensures optimal performance and safety.
Image: AVERA C6L Instant LP Gas Water Heater showing its compact size and dimensions (44 cm height, 13 cm depth). The product specifications list a width of 30 cm.
2. Important Safety Information
WARNING: Improper installation, adjustment, alteration, service, or maintenance can cause property damage, injury, or death. Read the installation, operating, and maintenance instructions thoroughly before installing or servicing this equipment.
- This appliance is for LP Gas only. Do not attempt to use with Natural Gas or any other fuel.
- Ensure proper ventilation. Never install the water heater in an unventilated area.
- The unit is equipped with a flame detector and an over-temperature sensor for your safety. Do not bypass or tamper with these safety features.
- Do not install the water heater in locations exposed to strong air currents, as this may extinguish the flame and cause unsafe operation.
- Always check for gas leaks after installation and during maintenance.
- Keep flammable materials away from the water heater.
- Ensure the water heater is installed by a qualified professional in accordance with local codes and regulations.
3. Product Components and Controls
Familiarize yourself with the main components and controls of your AVERA C6L water heater.
Image: Detailed view of the AVERA C6L water heater's control panel and connection points, including gas, water inlets/outlets, battery box, and on/off switch.
Controls:
- Temperature Control Knob: Adjusts the gas flow to regulate the water temperature. Turning it towards "Alta" (High) increases temperature, and towards "Baja" (Low) decreases it. Note that the effective range for flame regulation is primarily within the first quarter of its rotation.
- Water Flow Control Knob: Adjusts the water flow rate. Turning it towards "Alto" (High) increases flow, and towards "Bajo" (Low) decreases it.
- On/Off Switch: Powers the unit on or off.
Connections:
- Gas Connection (1/2"): Inlet for LP gas supply.
- Cold Water Inlet (1/2"): Inlet for cold water supply.
- Hot Water Outlet (1/2"): Outlet for heated water.
- Battery Box: Holds two D-type 1.5V alkaline batteries (not included), required for ignition.
- Drain/Relief Valve: For draining the unit and pressure relief.
4. Installation and Setup
The AVERA C6L water heater is designed for easy installation. However, for safety and optimal performance, professional installation is highly recommended.
4.1 Pre-Installation Checklist:
- Water Pressure: Ensure sufficient water pressure. If your shower pressure is low, consider installing a water pressurizer for better performance.
- Fuel Type: Confirm your gas supply is LP Gas. This model is exclusively for LP Gas.
- Batteries: Install two D-type 1.5V alkaline batteries into the battery box.
- Location: Choose an appropriate installation location.
Image: Guide on how to select the correct water heater, emphasizing water pressure, capacity, energy type, temperature control, and efficiency.
4.2 Installation Location Requirements:
- The water heater can be installed in a covered outdoor area or a ventilated indoor space.
- Avoid areas with strong air currents that could extinguish the pilot flame.
- Maintain a minimum distance of 2 meters between your shower and the water tank, and a maximum of 5 meters between your shower and the water heater for optimal performance.
Image: Diagram illustrating recommended distances for water heater installation relative to the shower and water/gas tanks.
Image: Visual examples of suitable installation environments: a covered outdoor area and a ventilated indoor space.
4.3 Connection Steps:
- Mount the water heater securely to a wall using the provided hardware.
- Connect the LP gas supply line to the gas inlet (1/2"). Ensure all gas connections are tight and leak-free.
- Connect the cold water supply line to the cold water inlet (1/2").
- Connect the hot water line to the hot water outlet (1/2").
- Open the main water supply valve to fill the water heater. Check for water leaks.
- Open the gas supply valve.
5. Operating Instructions
The AVERA C6L water heater features automatic ignition and instant heating.
- Power On: Ensure the On/Off switch is in the "On" position.
- Open Hot Water Tap: Open any hot water tap in your home. The water heater will automatically ignite and begin heating water.
- Adjust Temperature: Use the Temperature control knob to adjust the desired water temperature. Turn towards "Alta" for hotter water, "Baja" for cooler.
- Adjust Water Flow: Use the Water Flow control knob to adjust the flow rate. A minimum flow of 4 liters per minute is required for efficient operation.
- Shut Off: Close the hot water tap. The water heater will automatically turn off.
Note: The digital thermometer (if present on your model) measures internal pipe temperature, which may not accurately reflect the actual water temperature at the tap. Always test the water temperature manually before use to prevent scalding.
Image: Avera C6L water heater providing hot water, highlighting its instant heating capability as water flows from a showerhead.
6. Maintenance
Regular maintenance ensures the longevity and efficient operation of your AVERA C6L water heater.
- Annual Inspection: It is recommended to have a qualified technician inspect the water heater annually.
- Clean Exterior: Wipe the exterior with a soft, damp cloth. Do not use abrasive cleaners.
- Check Connections: Periodically check all gas and water connections for leaks.
- Battery Replacement: Replace the D-type batteries when the ignition becomes slow or inconsistent.
- Drainage: In areas with hard water, periodic draining and flushing of the unit may be necessary to prevent mineral buildup. Consult a professional for this procedure.
7. Troubleshooting
This section provides solutions to common issues you might encounter. For problems not listed here, contact customer support.
| Problem | Possible Cause | Solution |
|---|---|---|
| No hot water / Heater does not ignite. |
|
|
| Water is not hot enough. |
|
|
| Water is too hot. |
|
|
| Heater turns off unexpectedly. |
|
|
8. Specifications
| Feature | Detail |
|---|---|
| Model | C6L |
| Brand | AVERA |
| Fuel Type | LP Gas (Propano líquido) |
| Capacity | 6 Liters per minute (for 1 service) |
| Material | Stainless Steel, Copper Coil |
| Dimensions (H x W x D) | 44 cm x 30 cm x 30 cm |
| Weight | 5 kg |
| Wattage | 6970 watts |
| Special Features | Gas saving, Overheating protection, Flame detector, Automatic ignition, Compatible with solar systems |
| Batteries Required | 2 x D-type 1.5V Alkaline (not included) |
Image: Summary of key features including 1 service, 6 L/min heating, automatic ignition, temperature protection, 80% gas saving, and 2-year warranty.
Image: Another visual representation of the AVERA C6L highlighting its specifications and benefits.
9. Warranty and Support
Your AVERA C6L Instant LP Gas Water Heater comes with a 2-year warranty from the date of purchase. This warranty covers manufacturing defects under normal use.
For warranty claims, technical assistance, or any questions regarding your product, please contact AVERA customer support. Keep your proof of purchase for warranty validation.
Contact information for AVERA support can typically be found on the official AVERA website or on your product packaging.
