Tsong HD03R Microwave Motion Sensor Remote For Dimmable Sensors With Memory Function

Over View

HD03R lnstruction

Memory & Apply Mode

1. Press “ON/OFF button” to turn on the light or off.
2. To reset the parameters, Please follow the steps as below:
   Step 1 – Press ON, to turn on the light if it was off at the start.
   Step 2 – Press “Start” to the well-setting sensor.
   Step 3 – Press the button of Detection range, Hold time, Stand-by dimming level, Stand-by period and Daylight threshold one after the other in sequence.
   Step 5 – Press “Memory” to memor;7e the settings.
   Note: The interval of each parameter setting shall be controlled within 30s.
3. To programme other lights in !he array that have simi!ar sensors to !he same programme.
   Step 1 – Press “ON” to the second sensor
   Step 2 – Press “Apply”

lsolated Setting Mode

1. Press “ON/OFF button” to turn on the light or off. Press “Auto Mode”, the remote will activate settings that were saved last or remain at the factory default settings.
2. To reset the parameters, Please follow !he steps as below:
   Step 1 – Press ON, to turn on the light if it was off at the start.
   Step 2- Press any button of “Auto Mode”, “Reset” , Test” and “Apply” to begin the sensor detection mode.
   Step 3 – Press the button of Detection range, Hold time, Stand-by dimming level, Stand-by period and Daylight threshold one after the other in sequence.

Notes:

1. Settings will be saved automatically and remain until you press reset again.
2. Ught will flicker when setting each parameter.
