1. Bubuka
The BLUETTI Apex 300 Portable Power Station, paired with the B500K Expansion Battery, provides a robust and reliable energy solution for various applications, including home backup, RV use, camping, and emergency power. This system features a substantial 7884.8Wh LFP battery capacity, delivering 3840W of continuous AC output with a 7680W surge capability. It supports dual voltage output (120V/240V) and offers multiple charging options for flexibility.
Image: The BLUETTI Apex 300 Power Station stacked on top of the B500K Expansion Battery, illustrating their combined capacity and smart energy management features.
2. Émbaran Kasalametan
Please read and understand all safety instructions before operating the BLUETTI Apex 300 and B500K system. Failure to follow these instructions may result in electric shock, fire, or serious injury.
- Entong ngabongkar, ngaropea, atanapi ngarobih unitna.
- Jauhkeun unit tina seuneu, cai, sareng suhu anu ekstrim.
- Pastikeun ventilasi anu cekap nalika operasi sareng ngecas.
- Anggo ngan ukur asesoris sareng kabel anu disatujuan BLUETTI.
- Jauhkeun tina jangkauan barudak sareng piaraan.
- Upami aya seuneu, paké alat pemadam seuneu bubuk garing.
Gambar: internal view of the BLUETTI Apex 300, emphasizing its robust design and safety mechanisms, including the LiFePO4 battery and advanced Battery Management System (BMS).
3. Setélan
3.1 Naon dina Box
Saatos ngabongkar bungkusan, pariksa yén sadaya komponén aya:
- Apex 300 Power Station (x1)
- B500K Expansion Battery (x1, shipped separately)
- CA90 Battery Connection Cable for BLUETTI Apex 300 (x1)
- Kabel Ngecas AC (x1)
- Kabel Pangisi Daya Mobil (x1)
- Sekrup Pembumian (x1)
- Buku Panduan Pamaké (x1)
Image: All items included in the BLUETTI Apex 300 and B500K kit, neatly arranged for identification.
3.2 Produk Leuwihview
The Apex 300 features a comprehensive interface for power management and output. The front panel includes AC outlets, a voltage selector, ECO mode, AC output control, and a charging mode selector. The rear panel provides AC input/output ports, a circuit protector, and battery expansion ports.
Image: Close-up of the BLUETTI Apex 300's front panel, detailing the display, AC output ports, and control buttons for voltage and charging modes.
Image: A visual representation of the BLUETTI Apex 300 and B500K Expansion Battery connected, showing the modular design.
3.3 Connecting the Apex 300 and B500K
To expand the capacity of your Apex 300, connect the B500K Expansion Battery using the provided CA90 battery connection cable. Ensure both units are powered off before making connections.
- Locate the battery expansion ports on both the Apex 300 and the B500K.
- Connect one end of the CA90 cable to the Apex 300's expansion port.
- Connect the other end of the CA90 cable to the B500K's expansion port.
- Pastikeun sadaya sambungan aman.
Video: This video demonstrates the connection process for the BLUETTI B300 (similar to B500K) expansion battery to a compatible power station, showing how to link the units for increased capacity.
4. Operasi
4.1 Pilihan ngecas
The Apex 300 offers versatile charging methods to ensure your power station is always ready:
- Pengisian AC: Connect the AC charging cable to a standard wall outlet. The unit can reach 80% charge in approximately 45 minutes using TurboBoost 2000W fast charging.
- Ngecas Surya: Connect compatible solar panels to the DC/PV input ports. The Apex 300 supports up to 2400W built-in solar input, expandable to 6400W with SolarX 4K expansion.
- Ngecas Generator: The unit is 95% compatible with various generators for flexible power restoration.
- Ngecas mobil: Anggo kabel ngecas mobil anu disayogikeun pikeun ngecas tina stop kontak 12V/24V kendaraan anjeun.
Image: Visual demonstration of the multiple charging methods available for the BLUETTI Apex 300: solar, AC, and generator.
Image: The BLUETTI Apex 300 being charged by solar panels, highlighting its fast solar charging capabilities and MPPT technology.
4.2 Modeu operasi
The Apex 300 features a clear display and intuitive controls for managing power output and charging modes:
- Voltage Pamilih: Toggle between 120V and 240V output to match your appliance requirements.
- Mode Eco: Activates power-saving features to conserve battery life when loads are low.
- Kaluaran AC: Controls the activation of the AC outlets.
- Mode ngecas: Select from Silent, Auto, or Turbo modes. Silent mode minimizes fan noise, Auto mode balances charging speed and noise, and Turbo mode provides the fastest charging.
Video: A demonstration of the BLUETTI Apex 300 in action, showcasing its display, various ports, and control options for different operating modes.
4.3 Skenario Pamakéan
The Apex 300 + B500K system is designed for diverse power needs:
- Cadangan imah: Nyayogikeun kakuatan penting salami anjeuntages, keeping refrigerators, lights, and critical devices running.
- RV jeung Camping: Powers RV ovens, AC units, and other appliances without needing shore power.
- Bengkel: Capable of powering heavy-duty tools and equipment with its 7680W surge capacity.
- Hirup di luar grid: Offers energy independence with solar charging capabilities and silent operation.
Image: The BLUETTI Apex 300 and B500K providing reliable backup power for a household, illustrating its capacity to run essential appliances during outages.
Image: The BLUETTI Apex 300 and B500K powering various tools in a workshop setting, highlighting its suitability for demanding power requirements.
4.4 Expansion and Parallel Connection
Expand your power capabilities further with additional B500K batteries and the BLUETTI Hub A1 for parallel connection:
- The Apex 300 system can scale from 2764.8Wh up to 33484.8Wh with multiple B500K expansion batteries.
- The BLUETTI Hub A1 allows for parallel connection of up to three Apex 300 head units, providing up to 11.4kW AC output and access to 30A and 50A outputs for larger loads.
Video: This video explains how the BLUETTI Hub A1 enables the Apex 300 system to achieve up to 58kWh capacity and 11.4kW AC output through parallel connections.
Video: An initial impression and setup guide for the BLUETTI Hub A1 with dual Apex 300 units, demonstrating how to connect and utilize the parallel system.
5. Pangropéa
Proper maintenance ensures the longevity and optimal performance of your BLUETTI Apex 300 and B500K system:
- Ngabersihan rutin: Keep the unit clean and free from dust and debris. Use a dry, soft cloth.
- Panyimpenan: Store the unit in a cool, dry place away from direct sunlight and extreme temperatures. For long-term storage, charge the battery to 50-80% every 3-6 months.
- Kaséhatan batré: The 2nd-gen LiFePO4 battery is designed for 6,000+ cycles to 80% capacity, offering an estimated 17-year lifespan with proper care.
- Ventilasi: Pastikeun bukaan ventilasi teu diblokir pikeun nyegah overheating.
Image: An infographic detailing BLUETTI's core technological advancements, including the 6,000+ cycle lifespan of the LiFePO4 battery, ensuring long-term durability.
6. Cara ngungkulan
If you encounter issues with your BLUETTI Apex 300 system, refer to the following common troubleshooting tips:
- Unit teu diaktipkeun: Ensure the main power button is pressed and held until the display activates. Check battery charge level.
- Henteu aya kaluaran AC: Verify the AC output button is enabled. Check for overload protection (circuit protector). Reduce connected load if necessary.
- Masalah ngecas: Ensure charging cables are securely connected. Check the power source (wall outlet, solar panels, generator) for proper function. Verify selected charging mode.
- Perlindungan Overload: Upami unit pareum kusabab kaleuwihan beban, pegatkeun sababaraha alat teras hurungkeun deui unit.
- Konéktipitas Aplikasi: Ensure Bluetooth or Wi-Fi is enabled on your device and the power station. Restart both devices if connection fails.
Video: This video discusses a minor issue with the BLUETTI Hub D1 (similar to A1) and its setup, offering insights into potential connectivity or compatibility considerations.
7. Spésifikasi
| Fitur | Rincian |
|---|---|
| merek | BLUETTI |
| Modél | Apex 300 + B500K |
| Jenis Batré | LFP (LiFePO4) |
| Kapasitas | 7884.8Wh (Apex 300: 2764.8Wh, B500K: 5120Wh) |
| Kakuatan Kaluaran AC | 3840W (7680W Lonjakan) |
| AC Kaluaran Voltage | 120V / 240V Dual Voltage |
| Outlet AC | 6 (3840W), 1x NEMA TT-30R (120V/30A), 1x NEMA 14-50R (120V/240V, 50A) |
| Input DC / PV | 12-60V/20A/1200W Max ×2 (Solar: 2400W built-in, 6400W expanded) |
| Siklus Kahirupan | 6,000+ siklus nepi ka kapasitas 80% |
| Waktu Ngecas (AC) | 80% in 45 minutes (TurboBoost 2000W) |
| Item Beurat | 83.8 Pounds (Apex 300 unit) |
| Dimensi produk | 20.67"L x 12.87"W x 12.6"H (Apex 300 unit) |
| Fitur husus | 14 Versatile Ports, Smart App Control, BLUETOPUS AI-BMS, ≤10ms UPS Backup, Silent Operation (22dB) |
8. Jaminan & Dukungan
BLUETTI stands behind the quality and durability of its products. The Apex 300 and B500K system features a 2nd-gen LiFePO4 battery with 6,000+ cycles to 80% capacity, ensuring a long lifespan of approximately 17 years. The product is CNAS-certified and has undergone 33 extreme tests for reliability.
For any questions, technical assistance, or warranty claims, please refer to the contact information provided in your user manual or visit the official BLUETTI website. Our widespread sales and after-service networks are available to assist you.
Image: A customer service representative, representing BLUETTI's commitment to after-sale support and assistance.
