iSpring AFLT3 Automatic Water Filter Timer Instruction Manual

1. Produk Langkungview

The iSpring AFLT3 Automatic Filter Lifespan Timer is designed to simplify the maintenance of your water filtration system. It provides an intuitive interface for precise tracking of filter lifespans, ensuring timely replacements. This timer supports multi-filter management for up to three stages, allowing individual tracking even if each stage has a different replacement cycle (within one year). By helping you adhere to the recommended filter change schedule, the AFLT3 maintains optimal water flow, system efficiency, and water quality throughout your household. Installation is straightforward and does not require special tools.

Image: The iSpring AFLT3 Filter Life Timer displaying its compatibility with different multi-stage water filtration systems, including whole house and under-sink models. A cartoon polar bear mascot points to the timer and various filter system diagrams with green checkmarks, indicating broad compatibility.

2. Fitur konci

• Kasaluyuan lega: Compatible with most whole house and under-sink water filtration systems, including iSpring WGB, WCB, US31, CW series, Waterdrop TSA, TSB, TST, WHF series, Express Water WH series, Simpure DB series, HQUA WF series, and other systems with up to 3 stages and a filter life of up to one year.
• Individual Multi-Filter Tracking: Supports individual lifespan tracking for up to three filters. Separate reminders can be set for each stage, provided the cycle is within one year.
• Gampang Setup & Paké: Simple timer setup. The device features magnets on the back for convenient attachment to metal surfaces, such as a refrigerator or near your filtration system.
• Optimized System Performance: Helps maintain peak efficiency of your water filter system by ensuring timely filter changes, contributing to clean, safe, and great-tasting water.
• Durable & Dependable: Constructed for long-lasting performance and reliability in managing filter maintenance schedules.

Gambar: A lengkep view of the iSpring AFLT3 Filter Life Timer's intuitive features. It shows flexible timer options (days/months), individual filter tracking for three stages, magnetic mounting capability, and a table explaining visual filter alerts (LED indicators and buzzer prompts for countdown, near-expiry, and expired states).

3. Eusi Paket

• iSpring AFLT3 Filter Life Timer
• Instruksi Manual

4. Spésifikasi

5. Parentah Setup

1. Pasang Batré: Open the battery compartment on the back of the AFLT3 timer and insert the required batteries (not specified in input, assume standard AAA or AA).
2. Pilih Stage:

   Press the "1st", "2nd", or "3rd" button to choose the filter stage you wish to configure. The selected stage icon will illuminate on the display.



   Image: A diagram illustrating the "Easy Quick Start" process for the iSpring AFLT3. Step 1 shows a hand pressing the "1st" button to select a filter stage for configuration.

3. Set Countdown:
   • Press and hold the "Month/Day" button until the screen digits begin to flash.
   • Short press the "Month/Day" button to adjust the time (days or months) for the selected filter stage.
   • Wait approximately 10 seconds for the digits to stop flashing, confirming the setting.
   • Press the "Start" button to activate the countdown for the selected channel.
4. Check Active Countdown:

   A flashing icon for the configured stage (1st, 2nd, or 3rd) indicates that its countdown is active.

5. Change Countdown Display:

   Short press the "Month/Day" button to switch between displaying the remaining time in months or days.

6. Pamasangan: Place the filter life reminder near your water filtration system or on a metal surface using the integrated magnets on the back.

6. Parentah Operasi

6.1. Ngartos Tampilan

Image: A detailed diagram of the iSpring AFLT3 Filter Lifespan Timer's display. It labels the Battery Display, Channel Display (1st, 2nd, 3rd), Countdown Display, Filter Life Percentage Display, Buzzer Display, Filter Life LED Indicators (green, yellow, red), and Remaining Days/Months Display.

• Témbongkeun batré: Nunjukkeun tingkat batré ayeuna.
• Channel Display (1st, 2nd, 3rd): Shows which filter stage is currently selected or active.
• Countdown Display: Shows the remaining time until filter replacement.
• Filter Life Percentage tampilan: Shows the remaining filter life as a percentage.
• Buzzer Display: Indicates if the buzzer is active for alerts.
• Filter Life LED Indicators:
  • héjo: Filter life > 5% (Countdown begins).
  • Koneng: Filter life 1% - 5% (Near-expiry, beeps twice every 2 hours for 48 hours if not reset).
  • Beureum: Filter life 0% (Expired, beeps three times every 2 hours for 48 hours if not reset).
• Remaining Days/Months Display: Shows the unit of time for the countdown.

6.2. Resetting a Filter Countdown

After replacing a filter, it is crucial to reset its corresponding countdown on the AFLT3 timer:

1. Press the button for the filter stage (1st, 2nd, or 3rd) that you have replaced.
2. Press and hold the "Reset/Mute" button until the display for that stage resets to its initial set time.

6.3. Muting the Buzzer

If the buzzer is sounding due to a near-expiry or expired filter, you can temporarily mute it:

1. Press the "Reset/Mute" button once. This will mute the buzzer for the current alert cycle.
2. Note: The buzzer will sound again after 2 hours if the filter is not reset.

7. Pangropéa

• Ngagantian saringan: Replace your water filters according to the manufacturer's recommendations or when the AFLT3 timer indicates expiry. Timely replacement ensures optimal water quality and system longevity.
• Ngagantian batré: When the battery indicator shows low power, replace the batteries promptly to ensure continuous monitoring.
• beberesih: Ngusap timer ku lemes, damp cloth as needed. Do not use abrasive cleaners or immerse the device in water.

8. Cara ngungkulan

9. Garansi jeung Rojongan

For warranty information, technical support, or to purchase replacement parts, please visit the official iSpring website or contact iSpring customer service directly.

Websitus: www.ispringfilter.com

Kontak: Refer to the contact section on the iSpring websitus pikeun nomer telepon atawa rojongan email.
