FMS 1/7 Ford Bronco RTR EB RC Truck Instruction Manual

1. Bubuka

Welcome to the world of high-performance remote control vehicles with your new EAZYRC FMS 1/7 Ford Bronco RTR EB RC Truck. This manual provides essential information for the safe and efficient operation, maintenance, and troubleshooting of your vehicle. Designed for enthusiasts, this 4WD brushless RC truck offers speeds up to 80km/h, featuring a licensed Ford Bronco Baja 1000 design, robust CNC metal parts, and advanced stability systems for an exceptional off-road experience.

Please read this manual thoroughly before operating your RC truck to ensure proper setup and to maximize its performance and longevity.

Image: The FMS 1/7 Ford Bronco RTR EB RC Truck, showcasing its detailed exterior and aggressive stance.

2. Émbaran Kasalametan

Operating remote control vehicles requires attention to safety. Adhere to the following guidelines to prevent injury or damage:

• Kanggo panggunaan luar hungkul: This product is designed for outdoor use in open, clear areas.
• Saran umur: Recommended for users 16 years and up. Adult supervision is advised for younger operators.
• Avoid Public Roads: Never operate the RC truck on public roads, near pedestrians, or in crowded areas.
• Jaga Jarak: Keep a safe distance from people, pets, and obstacles while operating.
• Kasalametan batré: Always use recommended batteries and chargers. Follow all battery charging and handling instructions to prevent fire or explosion. Disconnect batteries when not in use.
• Cai sareng Uap: While the ESC is waterproof, avoid submerging the vehicle. Electronic components can be damaged by excessive moisture.
• Pariksa sateuacan dianggo: Always check the vehicle for loose parts, damaged components, or obstructions before each use.
• Panyimpenan anu leres: Store the RC truck and its components in a cool, dry place away from direct sunlight and extreme temperatures.

3. Eusi Paket

Saatos muka bungkusan, pariksa heula sadaya barang anu didaptarkeun di handap ieu aya:

• RC Truck (1 unit)
• 2.4GHz Remote Control (1 unit)
• Manual Produk (1 unit)
• Kunci inggris (1 unit)
• Obeng (1 unit)

Note: Batteries for the vehicle and remote control are not included and must be purchased separately.

Image: Visual representation of the FMS 1/7 Ford Bronco RTR EB RC Truck and its standard package contents.

4. Setélan

4.1. Battery Installation (Vehicle)

1. Ensure the vehicle's power switch is in the "OFF" position.
2. Locate the battery compartment, typically on the chassis.
3. Carefully connect your charged 6S LiPo battery (not included) to the ESC connector. Ensure correct polarity.
4. Secure the battery within the compartment using the provided straps or clips.
5. Tutup panutup kompartemen batré.

4.2. Pamasangan Batré Remote Control

1. Buka panutup batré dina tonggong kadali jauh.
2. Insert the required batteries (e.g., AA batteries, not included) according to the polarity markings.
3. Tutup panutup batre aman.

4.3. Pairing the Remote Control and Vehicle

1. Hurungkeun heula kadali jauh.
2. Then, turn on the vehicle's power switch.
3. The indicator lights on both the remote and vehicle receiver should show a solid light, indicating a successful connection. Refer to the remote control's specific manual for detailed pairing instructions if issues arise.

5. Parentah Operasi

5.1. Kadali dasar

• Setir: Belok ka kénca atawa ka katuhu pikeun ngadalikeun arah kandaraan.
• Throttle pemicu: Tarik pikeun maju ngagancangkeun, pencét pikeun ngerem atanapi mundur.
• Pangaluyuan Trim: Use the steering trim and throttle trim dials on the remote to fine-tune the vehicle's straight-line tracking and neutral throttle position.

5.2. Tip Nyetir

• Mimitian lalaunan: Begin with gentle throttle inputs to get a feel for the vehicle's response.
• rupa bumi: The FMS Ford Bronco is designed for off-road use. It performs well on dirt, sand, and rocky terrain. Avoid deep water or extremely muddy conditions.
• High-Speed Stability: The front independent suspension and rear solid axle, combined with the dual stability system (rear sway bar and adjustable gyro), provide excellent control even at speeds up to 80km/h.
• Pangaturan Gyro: The independent receiver with gyroscope can be adjusted via the transmitter to enhance stability, especially during high-speed maneuvers or on uneven surfaces. Refer to your remote control manual for specific adjustment procedures.

Image: The FMS 1/7 Ford Bronco RTR EB in motion, highlighting its powerful brushless motor and 150A ESC for high-speed performance.

Image: The remote control and the vehicle's independent receiver with gyroscope, illustrating the stability control system.

6. Pangropéa

Pangropéa rutin mastikeun kinerja anu optimal sareng manjangkeun umur treuk RC anjeun.

• beberesih: After each use, especially in dusty or dirty conditions, clean the vehicle. Use a soft brush or compressed air to remove dirt and debris from the chassis, suspension, and motor area. Avoid using water directly on electronics.
• Pamariksaan: Regularly check for loose screws, damaged parts, or worn tires. Pay attention to the CNC metal gears, differentials, and oil-filled aluminum shocks for any signs of wear or leakage.
• Lubrication: Apply appropriate RC-specific lubricants to moving parts like universal joints and gearboxes as needed. Consult advanced user guides for detailed lubrication points.
• Peredam Kejutan: Inspect the heavy-duty oil-filled aluminum shocks for proper function and oil levels. Refill or replace shock oil if performance degrades.
• Panyimpenan: When not in use, store the vehicle with batteries disconnected in a cool, dry place.

7. Cara ngungkulan

This section addresses common issues you might encounter with your FMS 1/7 Ford Bronco RTR EB RC Truck.

If you encounter issues not covered here, please contact customer support for assistance.

8. Spésifikasi

Gambar: Diménsi leuwihview of the FMS 1/7 Ford Bronco RTR EB RC Truck.

9. Garansi jeung Rojongan

For warranty information, please refer to the documentation provided with your purchase or contact the retailer. For technical support, parts, or service inquiries, please contact EAZYRC customer service through their official websitus atanapi inpormasi kontak anu disayogikeun dina dokuméntasi pameseran anjeun.

Always provide your product model number (1/7 Ford Bronco RTR EB) and purchase date when seeking support.
