Buku Panduan Pangguna Spiker Pesta Bluetooth pTron Fusion Saga 48W

Bubuka

The pTron Fusion Saga is a portable 48W Bluetooth party speaker designed for immersive audio experiences. It features dual dynamic drivers, rhythmic RGB LED lights, and multiple playback options, making it suitable for various indoor and outdoor settings. This manual provides detailed instructions for setting up, operating, and maintaining your speaker.

Naon dina Box

• 1 x pTron Fusion Saga Bluetooth Speaker
• 1 x User Guide Card
• 1 x Kabel Aux
• 1 x Kabel Ngecas Tipe-C
• 1 x Kartu Garansi

Produk Leuwihview

The pTron Fusion Saga speaker delivers powerful sound with its dual dynamic drivers and enhances the listening experience with integrated RGB lighting. It offers versatile connectivity and easy-to-use controls.

Image: The pTron Fusion Saga speaker showcasing its internal dual dynamic drivers, highlighting the 48W pure power output.

Image: The pTron Fusion Saga speaker with its vibrant, rhythmic RGB LED lights illuminated, creating an engaging visual effect.

Ngecas Speaker

Before first use, fully charge the speaker. The pTron Fusion Saga features a Type-C charging port for convenience.

1. Connect the provided Type-C charging cable to the speaker's Type-C port.
2. Connect the other end of the cable to a 5V DC power adapter (not included) or a compatible USB port.
3. Lampu indikator ngecas bakal hurung.
4. Ngeusi batre pinuh biasana nyandak kirang langkung 2 jam.
5. Saatos dicas pinuh, lampu indikator tiasa robih atanapi pareum, gumantung kana modélna. Pegatkeun sambungan kabel ngecas.

A fully charged speaker provides approximately 6 hours of music playback via TF card, which may vary with volume level and RGB light usage.

Image: The pTron Fusion Saga speaker illustrating its charging time of 2 hours and a playtime of 6 hours.

Gambar: A lengkep view of the Type-C charging port located on the pTron Fusion Saga speaker.

Parentah Operasi

Daya Hurung/Pareuman

• Pikeun ngahurungkeun, pencét jeung tahan kenop Kakuatan tombol nepi ka lampu indikator hurung.
• Pikeun pareum, pencét jeung tahan Kakuatan pencet deui tombolna nepi ka lampu indikatorna pareum.

Papasangan Bluetooth

1. Ensure the speaker is powered on and in Bluetooth mode. The speaker will automatically enter pairing mode, indicated by a flashing LED.
2. Dina alat anjeun (smartphone, tablet, jsb.), aktipkeun Bluetooth sareng milarian alat anu sayogi.
3. Pilih"pTron Fusion Saga"tina daptar alat.
4. Sakali dipasangkeun, spéker bakal ngaluarkeun konfirmasi karungu, sareng indikator LED bakal padet.
5. Spiker bakal otomatis nyambung deui ka alat anu terakhir dipasangkeun nalika dihurungkeun, upami alatna aya dina jangkauan.

Sababaraha Modeu Playback

The speaker supports Bluetooth v5.3, 3.5mm Aux, TF Card, and USB playback modes.

Image: The pTron Fusion Saga speaker highlighting its multiple playback options: Bluetooth V5.3, 3.5mm Aux, TF Card, and USB Port.

• Mode Bluetooth: Connect wirelessly as described above.
• Mode Aux: Insert the 3.5mm Aux cable into the speaker's AUX port and connect the other end to your audio device. The speaker will automatically switch to Aux mode.
• Mode Kartu TF: Selapkeun kartu TF (microSD) sareng audio files kana slot kartu TF. Spéker bakal otomatis ngadeteksi sareng maénkeun musik tina kartu.
• Mode USB: Selapkeun USB flash drive kalawan audio filekana port USB. Spiker bakal otomatis ngadeteksi sareng muterkeun musik tina drive.
• Ngalihkeun Mode: Ngagunakeun éta MODÉ button on the control panel to cycle through available playback modes.

Integrated Multi-function Controls

Gambar: A lengkep view of the multi-function control panel on the top of the pTron Fusion Saga speaker.

• Tombol Daya: Pencét jeung tahan pikeun mareuman/nonaktipkeun.
• Tombol Puter/Reureuh: Pencét pikeun muterkeun atawa ngareureuhkeun musik.
• Tombol Saméméhna/Tombol Volume Turun: Press to go to the previous track. Press and hold to decrease volume.
• Tombol Salajengna/Naékkeun Volume: Press to go to the next track. Press and hold to increase volume.
• Tombol MODE: Press to switch between Bluetooth, Aux, TF Card, and USB modes.
• Tombol LED: Press to control the RGB lighting effects.

True Wireless Stereo (TWS) Fungsi

You can connect two pTron Fusion Saga speakers together for a stereo sound experience.

1. Pastikeun duanana speaker dipareuman.
2. Hurungkeun kadua spiker. Spiker éta bakal asup kana modeu pasangan Bluetooth.
3. Dina salah sahiji spiker (ieu bakal janten spiker utama), pencét dua kali tombol MODÉ button. The speaker will search for another Fusion Saga speaker.
4. Once connected, both speakers will emit an audible confirmation, and their LEDs will synchronize.
5. Ayeuna, sambungkeun alat anjeun ka spiker utama via Bluetooth sapertos anu dijelaskeun dina bagian "Pasangan Bluetooth".
6. Audio will play simultaneously through both speakers, creating a stereo effect.

Image: Two pTron Fusion Saga speakers demonstrating the True Wireless Stereo (TWS) function, connected to double the sound impact.

Port mikropon

The speaker includes a 6.5mm wired microphone port for karaoke or announcements (microphone not included).

• Insert a compatible 6.5mm wired microphone into the MIC port.
• Adjust microphone volume as needed (if available on the microphone or speaker controls).

Gambar: A close-up view of the 6.5mm wired microphone port on the pTron Fusion Saga speaker.

Pangropéa

• Keep the speaker away from water and excessive moisture. This product is not waterproof.
• Ngabersihan spéker nganggo kaén anu lemes sareng garing. Ulah make cleaners abrasive atawa pangleyur.
• Hindarkeun ngalaan spéker ka suhu anu ekstrim (panas atanapi tiis).
• Simpen spéker dina tempat anu tiis sareng garing upami henteu dianggo kanggo waktos anu lami.
• Ulah nyobian ngabongkar atawa ngalereskeun speaker sorangan. Ieu bakal ngabatalkeun jaminan.

Pamérésan masalah

spésifikasi

Garansi sareng Rojongan

Émbaran jaminan

The pTron Fusion Saga speaker comes with a 1-Taun Garansi Produsén ti tanggal pameseran. Garansi ieu nutupan cacad manufaktur. Mangga simpen resi pameseran anjeun kanggo klaim garansi.

Rojongan Palanggan

Kanggo patarosan, bantosan téknis, atanapi klaim garansi, mangga ngahubungi dukungan palanggan pTron:

• Surélék: Support@ptron.in
• Telepon: 040-67138888
