1. Bubuka
This manual provides essential information for the safe and effective operation of your ComMarker Titan1 60W JPT Mopa Fiber Laser Engraving Machine. Please read this manual thoroughly before operating the device to ensure proper usage and to prevent damage or injury. The ComMarker Titan1 is designed for high-precision engraving and marking on various materials, including metals, plastics, and jewelry, offering advanced features like color marking and 3D engraving capabilities.
2. Émbaran Kasalametan
The ComMarker Titan1 is a Class 1 Laser Product (IEC 60825-1 Report Number: 2501Q25848E-SFA1, FDA Accession No.: 2521455-000). Despite being a Class 1 product, proper safety precautions are crucial during operation.
- Always wear appropriate laser safety goggles when operating the machine.
- Ensure the work area is well-ventilated to dissipate fumes and particles generated during engraving.
- Never look directly into the laser beam or at reflections from shiny surfaces.
- Jauhkeun bahan anu gampang kaduruk tina daérah ukiran.
- Do not operate the machine if any covers are removed or safety interlocks are bypassed.
- Pastikeun mesin geus bener grounded.
- Biasakeun diri anjeun sareng lokasi sareng fungsi tombol eureun darurat.
3. Eusi Paket
Pariksa heula sadaya barang anu didaptarkeun di handap ieu kalebet kana pakét anjeun. Upami aya barang anu leungit atanapi ruksak, hubungi dukungan palanggan.
Gambar: Leuwihview of the ComMarker Titan1 60W JPT Mopa Fiber Laser Engraving Machine and its accessories.
- ComMarker Titan1 Laser Engraver Body
- Adaptor kakuatan
- Kabel Data
- Ngalih Kaki
- Kacamata Kasalametan laser
- Allen rengkuh Siapkeun
- USB Drive (containing software and drivers)
- Pangawasa
- Lemah Kawat
- Placing Helper (material positioning aids)
- Sample Materials (Rings, Metal Pendants, Pendants)
4. Fitur Produk
- 60W JPT Mopa Laser Source: Provides high-speed engraving up to 15,000mm/s and supports color marking on stainless steel.
- Akurasi luhur: Achieves 8K HD accuracy with a precision of 0.01mm.
- Area Ukiran Ageung: Maximum engraving area of 300mm x 300mm.
- Motorized Elevation: Features electric lifting for precise height adjustment and focusing.
- Dual Focusing Modes: Supports both manual and electric focusing for optimal results.
- Kasaluyuan Parangkat Lunak: Compatible with Lightburn and EzCad2 software.
- Wide Bahan kasaluyuan: Engraves stainless steel, aluminum, gold, silver, alloys, most painted products, and non-transparent plastics.
- 3D Engraving & Cutting: Capable of creating depth effects and performing cutting tasks on suitable materials.
- Umur panjang: Designed for durability with a laser source lifespan of 100,000 hours.
5. Setup Guide
- Ngabongkar bungkusan: Sacara saksama miceun sadaya komponén tina bungkusan. Simpen bungkusan pikeun transportasi atanapi neundeun ka hareup.
- Majelis: Place the laser engraver body on a stable, level surface. Connect the laser head assembly to the main unit, ensuring all fasteners are secure.
- Sambungan Daya: Connect the power adaptor to the machine and then to a grounded electrical outlet (110V).
- Grounding: Attach the provided ground wire to the designated grounding point on the machine and to a suitable ground source.
- Sambungan Data: Connect the data cable from the machine to your computer.
- Pamasangan parangkat lunak: Insert the USB drive into your computer. Install the provided EzCad2 software and drivers. If using Lightburn, download and install the latest version from the official Lightburn websitus.
- Kacamata kaamanan: Always put on the laser safety goggles before powering on the machine.
6. Parentah Operasi
- Daya Hurung: Ensure all connections are secure and safety goggles are worn. Press the power button on the machine.
- peluncuran software: Open EzCad2 or Lightburn software on your computer.
- Penempatan Bahan: Place the material to be engraved on the work platform. Use the placing helpers if needed to secure the material.
- Fokus: Adjust the laser head height using the motorized elevation until the laser is properly focused on the material surface. You can use either manual or electric focusing. Refer to the software's focusing guide for precise adjustment.
- Design Import/Creation: Import your design (BMP, GIF, JPG, JPEG, DXF, DST, AI, etc.) or create a new one within the software.
- Setélan Parameter: Set the appropriate laser parameters (power, speed, frequency, passes) based on the material type and desired engraving effect (e.g., color marking, deep engraving, cutting).
- Praview (Red Light): Use the red light preview function in the software to verify the engraving area and position on your material.
- Mimitian ukiran: Sakali wareg jeung praview and parameters, initiate the engraving process from the software. You may use the foot switch for convenient start/stop control.
- Ngawaskeun: Supervise the engraving process. In case of any issue, press the emergency stop button immediately.
- Pareum listrik: After engraving is complete, power off the machine and disconnect it from the power source.
7. Pangropéa
- Lensa beberesih: Regularly inspect and clean the laser lens with a specialized lens cleaning solution and lint-free wipes to ensure optimal laser performance.
- Wewengkon Gawé: Keep the work platform and surrounding area clean from debris and dust.
- Ventilasi: Ensure the ventilation system is clear and functioning properly to prevent accumulation of fumes and particles.
- Pamariksaan kabel: Pariksa sadaya kabel sacara berkala pikeun tanda-tanda karusakan atanapi karusakan. Ganti kabel anu ruksak langsung.
- Apdet parangkat lunak: Keep your engraving software (Lightburn, EzCad2) updated to the latest version for best performance and compatibility.
8. Cara ngungkulan
| Masalah | Mungkin Cukang lantaranana | Solusi |
|---|---|---|
| Laser teu némbak | Power not connected; Emergency stop engaged; Software error; Laser source issue. | Check power connections; Release emergency stop; Restart software/computer; Contact support if laser source is suspected. |
| Kualitas ukiran goréng | Incorrect focus; Dirty lens; Incorrect power/speed settings; Material not flat. | Re-focus the laser; Clean the lens; Adjust engraving parameters; Ensure material is flat and secure. |
| Mesin teu nyambung ka komputer | Loose data cable; Driver not installed; Software not recognizing device. | Check data cable connection; Install/reinstall drivers from USB drive; Restart software/computer. |
| Unexpected machine shutdown | Overheating; Power fluctuation; Loose power connection. | Ensure proper ventilation; Check power supply stability; Secure power cable. |
9. Spésifikasi
Image: Detailed dimensions of the ComMarker Titan1 60W JPT Mopa Fiber Laser Engraving Machine.
| Fitur | Rincian |
|---|---|
| Produsén | ComMarker |
| Nomer modél | Titan1 Mopa |
| Sumber Laser | 60W JPT Mopa Fiber Laser |
| Panjang gelombang laser | 1064nm |
| Laju ukiran | Nepi ka 15,000mm / s |
| Akurasi Ukiran | 0.01mm, 8K HD |
| Maximum Engraving Area | 300 mm x 300 mm |
| Sumber Daya | AC/DC, 110V |
| Kasaluyuan Sistim | Windows 7/8/10/11, MAC (Lightburn) |
| Supported Graphic Formats | BMP, GIF, JPG, JPEG, DXF, DST, AI, etc. |
| Dimensi produk | 22 x 25.8 x 21.5 inci (kira-kira 559 x 655 x 546 mm) |
| Kelas laser | Class 1 Laser Product (IEC 60825-1) |
10. Garansi jeung Rojongan
For warranty information, please refer to the documentation included with your purchase or contact ComMarker customer support directly. If you encounter any issues not covered in this manual or require technical assistance, please reach out to ComMarker customer service through their official website or the contact information provided at the time of purchase.
Sumberdaya Online: For additional guides, software updates, and community support, visit the official ComMarker websitus.
