DEERC 1/10 Brushless RC Truck Instruction Manual

1. Émbaran Kasalametan penting

This product contains small parts and is not suitable for children under 14 years old as it may pose a choking hazard. Always operate the product under adult supervision, especially in areas with traffic or hazards. Read all instructions before operation.

• Jaga leungeun, beungeut, jeung pakean anu leupas jauh tina bagian anu obah.
• Do not operate in public streets or near people.
• Avoid operating in wet conditions or near water unless explicitly stated as waterproof.
• Always disconnect the battery after use and before cleaning or maintenance.
• Use only recommended chargers and batteries.

2. Naon dina Box

Your DEERC 1/10 Brushless RC Truck package includes the following items:

• 1 x DEERC 1/10 Brushless RC Truck
• 1 x Kadali Jauh
• 2 x 3S (11.1V) 1500mAh LiPo Batteries
• 1 x Wheelie Bar
• 1 x Kabel Ngecas
• 1 x Manual Produk

Figure 2.1: Contents included in the DEERC RC Truck package.

3. Setup Guide

3.1 Inspeksi Awal

Carefully remove all components from the packaging. Inspect the RC truck for any visible damage from shipping. Ensure all parts listed in the 'What's in the Box' section are present.

Gambar 3.1: Utama view of the DEERC 1/10 Brushless RC Truck.

3.2 Pamasangan Batré & Ngecas

The DEERC RC Truck uses custom-sized 3S (11.1V) 1500mAh LiPo batteries. Ensure batteries are fully charged before first use.

1. Connect the provided charging cable to the battery and a compatible USB power source.
2. Once fully charged, carefully remove the body clips from the RC truck's chassis.
3. Lift the body shell to access the battery compartment.
4. Insert a charged 3S LiPo battery into the designated compartment. Ensure the battery is securely fastened.
5. Connect the battery's power connector to the ESC (Electronic Speed Controller) connector.
6. Carefully reattach the body shell and secure it with the body clips.

Figure 3.2: The 3S LiPo battery connected to the ESC within the RC truck.

3.3 Setup Kontrol Jauh

The remote control requires 2 AAA batteries (included). Install them into the battery compartment on the back of the remote.

1. Buka panutup batré dina tonggong kadali jauh.
2. Selapkeun 2 batré AAA, mastikeun polaritasna bener.
3. Tutup panutup batré.
4. Turn on the remote control using the power switch.

4. Parentah Operasi

4.1 Powering on / Pareum

To power on the RC truck, ensure the battery is connected and then press the power button on the ESC. The LED lights will illuminate. To power off, press the power button again.

4.2 Driving Basics

The remote control features a trigger for throttle and a steering wheel for direction. This 4x4 off-road truck is designed for high-speed action and all-terrain capabilities.

• Throttle: Pull the trigger to accelerate forward. Push the trigger to brake or reverse.
• Setir: Turn the steering wheel left or right to control the direction of the truck.
• Laju: With its powerful 2847 2300KV brushless motor, the truck can reach speeds of 60 KM/H. Adjust throttle input for desired speed.
• Kamampuhan Sadaya Terrain: The truck's robust design, including a full metal drivetrain, metal gear differentials, and alloy oil-filled shocks, allows it to handle various surfaces like mud, sand, gravel, and grass.
• Lampu LED: The built-in LED headlights provide enhanced visibility for night runs.
• Roda Bar: The rear-mounted wheelie bar helps stabilize the truck during hard acceleration and prevents it from flipping backward.

Figure 4.2: The RC truck in action, emphasizing its speed and key internal components like metal dogbones and the brushless motor.

angka 4.3: Tutup-up view of the truck's reinforced metal chassis plates and the optional wheelie bar, demonstrating its rugged construction.

5. Pangropéa

5.1 beberesih

After each use, especially after running in dirt, mud, or sand, clean the truck to prevent debris buildup.

• Use a soft brush or compressed air to remove loose dirt and dust.
• Wipe down the body and chassis with a damp cloth. Avoid excessive water, especially near electronics.

5.2 Perawatan Batré

Proper battery care extends the lifespan of your LiPo batteries.

• Always charge batteries using the provided charger.
• Ulah overcharge atawa over-discharge batré.
• Simpen batré di tempat anu tiis sareng garing jauh tina sinar panonpoé langsung sareng suhu anu ekstrim.

5.3 Drivetrain and Shock Absorbers

Regular inspection of the drivetrain and shocks ensures optimal performance.

• Check the full metal drivetrain components (driveshafts, gear differentials) for any signs of wear or damage.
• Inspect the alloy oil-filled shock absorbers for leaks or damage. Ensure they provide smooth damping.
• Keep moving parts free from obstructions.

Figure 5.1: Breakdown of key components, illustrating the robust construction of the drivetrain and suspension.

6. Cara ngungkulan

If you encounter any issues with your DEERC RC Truck, refer to the common problems and solutions below. For further assistance, please contact DEERC customer support.

• Henteu aya kakuatan: Ensure batteries are fully charged and correctly installed in both the truck and the remote control. Check all connections.
• Jangkauan/Gangguan Goréng: Ensure the remote control batteries are fresh. Avoid operating near other radio-controlled devices or strong electromagnetic interference.
• Masalah Setir: Check for any obstructions in the steering mechanism. Ensure the steering servo is functioning correctly.
• Performance ngurangan: This could indicate a low battery charge or debris affecting moving parts. Clean the truck and recharge batteries.

Worry-Free Support: Your satisfaction is our priority. DEERC offers responsive customer support, step-by-step troubleshooting, and replacement service for parts and accessories. Whether you're a beginner or a seasoned hobbyist, our team is here to ensure you get the best RC experience—buy with confidence and drive with peace of mind.

7. Spésifikasi

8. Jaminan & Dukungan

DEERC is committed to providing excellent customer service and support for your product.

• For any product-related inquiries, troubleshooting, or replacement parts, please contact DEERC US customer support directly.
• Additional protection plans are available for purchase to extend coverage beyond the standard warranty. These include 2-Year and 3-Year Protection Plans, as well as a Complete Protect monthly plan.
