MOVA E20 Plus Robot Vacuum and Mop with Auto-Emptying Station User Manual

1. Bubuka

Thank you for choosing the MOVA E20 Plus Robot Vacuum and Mop. This device is designed to provide efficient and convenient floor cleaning with its advanced features, including an auto-emptying station, precise LDS navigation, powerful suction, and integrated vacuuming and mopping capabilities. Please read this manual thoroughly before use to ensure proper operation and maintenance.

Image: The MOVA E20 Plus robot vacuum and its auto-emptying station, highlighting its automatic features.

2. Émbaran Kasalametan

Pikeun ngurangan résiko tatu atawa karuksakan, baca parentah kaamanan ieu taliti tur nyimpen aranjeunna keur rujukan ka hareup. Perkakas ieu kanggo panggunaan rumah tangga wungkul.

• Ulah ngantep barudak maén kalawan robot. Ngawaskeun barudak sareng piaraan nalika robot beroperasi.
• Pastikeun vol kakuatantage cocog voltage ditandaan dina dok ngecas.
• Ulah make robot di lingkungan baseuh atawa dina surfaces baseuh.
• Jauhkeun rambut, pakean longgar, ramo, sareng sadaya bagian awak tina bukaan sareng bagian anu obah.
• Ulah nyokot naon bae anu kaduruk atawa ngaroko, kayaning roko, korek api, atawa lebu panas.
• Entong dianggo tanpa tempat lebu sareng / atanapi saringan dina tempatna.
• Avoid using the robot to pick up large debris, sharp objects, or liquids.
• Upami kabel listrik ruksak, éta kedah digentos ku produsén atanapi agén jasa pikeun ngahindarkeun bahaya.

3. Eusi Paket

Pastikeun yén sadaya komponén aya sareng dina kaayaan anu saé nalika dibongkar.

• Robot vakum (x1)
• Auto-Emptying Base (x1)
• Mop Pad Holder (x1)
• Sikat Samping (x1)
• Buku Panduan Pamaké (x1)
• Dust Bag (pre-installed in base)

Image: A visual representation of the MOVA E20 Plus robot, auto-emptying base, mop pad holder, side brush, and user manual.

4. Produk Langkungview

Fitur konci:

• Basis Ngosongkeun Otomatis: Enjoy hands-free cleaning as the robot automatically empties dust and debris into a 4L sealed bag, providing up to 90 days of maintenance-free use.
• Pathfinder Smart Technology: The vacuum precisely maps your interior, even in the dark, using laser sensors for a smooth and uninterrupted cleaning session.
• 5000 Pa Vormax Suction: Powerful 5000 Pa suction adapts quickly to hard floors, carpets, and rugs, easily removing stubborn dirt and reaching hidden corners.
• Nyedot debu sareng ngepel 2-in-1: The 2-in-1 design combines vacuuming and mopping with a large 245 ml water tank. Select one of three water flow levels for spotless floors throughout your home.
• Flexible App Control: Customize your cleaning experience with adjustable modes, suction levels, and schedules. Save up to 3 floor plans, define no-go zones, and set virtual boundaries for targeted cleaning control.

komponén:

The MOVA E20 Plus consists of the robot vacuum and the auto-emptying charging base.

Gambar: A lengkep view of the robot vacuum docking with its auto-emptying station, illustrating the dust collection process.

Image: The robot vacuum navigating a room, demonstrating its Pathfinder smart technology for precise mapping.

Image: An illustration showing the powerful 5000 Pa suction of the robot vacuum, effectively lifting debris from the floor.

Image: The robot vacuum simultaneously vacuuming and mopping, demonstrating its dual cleaning capability.

5. Setélan

5.1 Ngabongkar sareng Nempatkeun

1. Remove all packaging materials from the robot and the auto-emptying base.
2. Place the auto-emptying base against a wall in an open area, ensuring there are no obstacles within 1.5 meters (5 feet) in front and 0.5 meters (1.6 feet) on either side.
3. Connect the power cord to the base and plug it into a wall outlet. Ensure the base is powered on.

Image: The MOVA E20 Plus robot vacuum positioned next to its auto-emptying base, ready for initial setup.

5.2 Ngecas Awal

Place the robot onto the charging contacts of the auto-emptying base. The robot will automatically align and begin charging. For first-time use, fully charge the robot before operation (approximately 4-5 hours).

5.3 Ngundeur Aplikasi sareng Sambungan

1. Download the "MOVA" app from your smartphone's app store (iOS or Android).
2. Open the app and follow the on-screen instructions to create an account and add your MOVA E20 Plus device.
3. Ensure your Wi-Fi network is 2.4 GHz for successful connection.

6. Parentah Operasi

6.1 Ngamimitian siklus beberesih

• Via Robot: Pencét tombol daya dina robot sakali pikeun ngamimitian siklus beberesih. Pencét deui pikeun ngareureuhkeun.
• Via Aplikasi: Open the MOVA app, select your device, and tap "Start Cleaning."

6.2 Ngagunakeun Fungsi Ngepel

1. Fill the water tank with clean water. Do not use detergents or cleaning solutions not approved by MOVA.
2. Attach the mop pad to the mop pad holder and slide it into the designated slot on the robot.
3. In the app, select the desired water flow level (low, medium, high) for mopping.
4. Mimitian siklus beberesih. Robot bakal nyedot debu sareng ngepel sakaligus.

6.3 Fitur Aplikasi

The MOVA app provides comprehensive control over your robot vacuum:

• Manajemén Peta: View and edit floor maps, create virtual walls, and set no-go zones.
• Modeu Ngabersihan: Choose from various cleaning modes (e.g., Auto, Spot, Zone, Edge).
• Daya Sedot & Aliran Cai: Adjust suction strength and water output for mopping.
• Jadwal: Set cleaning schedules for automated cleaning.
• Kontrol sora: Compatible with Amazon Echo (Alexa) for voice commands.

Image: A smartphone screen displaying the MOVA app interface, showing options for cleaning modes, suction power, and water flow settings.

7. Pangropéa

Regular maintenance ensures optimal performance and extends the lifespan of your MOVA E20 Plus.

7.1 Auto-Emptying Dust Bag

The 4L dust bag in the auto-emptying base typically lasts up to 90 days, depending on usage. Replace the dust bag when the indicator light on the base or the app notifies you.

1. Open the top cover of the auto-emptying base.
2. Cabut kantong lebu sagemblengna kalawan ati-ati teras miceunana.
3. Insert a new dust bag, ensuring it is properly seated.
4. Tutup panutup luhur.

7.2 Cleaning the Dust Bin and Filters (Robot)

Even with auto-emptying, it's recommended to periodically check and clean the robot's internal dust bin and filters.

1. Open the robot's top cover and remove the dust bin.
2. Kosongkeun tong lebu.
3. Remove the filter assembly and tap it gently to remove dust. Rinse the filter with water if necessary, and ensure it is completely dry before re-inserting.
4. Reassemble the dust bin and place it back into the robot.

7.3 Sikat beberesih

• Sikat utama: Cabut panutup sikat utama teras angkat sikatna. Anggo alat beberesih pikeun motong sareng miceun rambut atanapi kokotor anu kusut.
• Sikat samping: Unscrew the side brush and remove any tangled hair. Reattach securely.

7.4 Ngabersihan Sénsor sareng Ngecas Kontak

Wipe all sensors (cliff sensors, wall sensor, LDS sensor window) and charging contacts on both the robot and the base with a clean, dry cloth.

8. Cara ngungkulan

If you encounter issues with your MOVA E20 Plus, refer to the following table for common problems and solutions.

9. Spésifikasi

Image: An illustration highlighting the 3200 mAh battery capacity of the MOVA E20 Plus, capable of cleaning up to 175 m² on a single charge.

10. Garansi jeung Rojongan

MOVA offers a 3-year warranty for quality and reliability. Please refer to the official MOVA website for detailed warranty information and terms and conditions. Some products and parts may not be covered.

For technical support, troubleshooting assistance, or to purchase replacement parts, please visit the official MOVA websitus atanapi ngahubungan layanan palanggan maranéhna.
