HOFTRONIC Luxor V2 LED Floodlight 100W 4000K User Manual

1. Bubuka

Thank you for choosing the HOFTRONIC Luxor V2 LED Floodlight. This manual provides essential information for the safe and efficient installation, operation, and maintenance of your new floodlight. This ultra-efficient LED floodlight delivers 160 lumens per watt, consuming only 100W to produce 16000 lumens of neutral white light (4000K). It is designed for illuminating large areas and features anti-glare glass for comfortable viewing. The robust IP65-rated, corrosion-free aluminum construction, along with a breathable membrane, ensures optimal performance in various outdoor conditions.

Figure 1: HOFTRONIC Luxor V2 LED Floodlight, a powerful and efficient lighting solution.

2. Parentah Kasalametan

Mangga baca parentah kaamanan ieu taliti saméméh instalasi tur operasi. Gagalna nuturkeun paréntah ieu tiasa nyababkeun shock listrik, seuneu, atanapi bahaya anu sanés.

• Kasalametan listrik: Installation must be performed by a qualified electrician in accordance with local wiring regulations. Ensure the power supply is disconnected before any installation, maintenance, or repair work.
• Voltage: Connect the floodlight only to a 230 Volt AC power supply.
• Grounding: Ensure the floodlight is properly grounded to prevent electric shock.
• Pamasangan: Mount the floodlight securely on a stable surface that can support its weight. Avoid mounting near flammable materials.
• Suhu: Do not operate the floodlight in environments exceeding its specified operating temperature range.
• Ruksakna: Do not use the floodlight if the housing, glass, or cable is damaged. Contact support for assistance.
• Pembongkaran: Do not attempt to disassemble or modify the floodlight. This will void the warranty and may cause safety hazards.

3. Eusi Paket

Pastikeun yén sadaya komponén aya sareng henteu ruksak:

• 1x HOFTRONIC Luxor V2 LED Floodlight (100W, 4000K)
• 1x Pamasangan Bracket
• 1 x Manual Pamaké

4. Setup jeung Instalasi

Turutan léngkah-léngkah ieu pikeun pamasangan lampu sorot LED anjeun anu leres:

1. Pilih Lokasi: Select a suitable mounting location that provides the desired illumination coverage and is structurally sound. The floodlight is suitable for both indoor and outdoor use.
2. Tanda titik pangeboran: Use the mounting bracket as a template to mark the drilling points on the chosen surface (wall, ground, or pole).
3. liang bor: Bor liang anu cocog pikeun sekrup pamasangan.
4. Bracket Aman: Attach the mounting bracket securely to the surface using suitable screws and anchors (not included).
5. Gantelkeun Lampu Sorot: Mount the floodlight onto the secured bracket. The bracket allows for tiltable adjustment to direct the light as needed.

Figure 2: The floodlight features a tiltable mount for flexible light direction.

Gambar 3: Kelamples of mounting the floodlight on a wall, ground, or pole.

6. Sambungan listrik: Connect the floodlight's power cable to your 230V AC electrical supply. Ensure all connections are secure and waterproof, especially for outdoor installations. Consult a qualified electrician if you are unsure about wiring.

5. Parentah Operasi

The HOFTRONIC Luxor V2 LED Floodlight operates directly from the main power supply. Once properly installed and connected to power, it will illuminate when the connected switch is turned on.

• Hurungkeun/Pareuman: Use the external switch connected to the floodlight's power supply to turn the light on or off.
• Arah cahaya: Adjust the tiltable mount to direct the light beam to your desired area.
• Fitur Anti-Glare: The integrated anti-glare glass reduces harshness, making it suitable for areas like driveways or parking lots where direct viewing might occur.

Figure 4: The anti-glare glass provides a more comfortable viewing experience compared to standard floodlights.

6. Pangropéa

The HOFTRONIC Luxor V2 LED Floodlight is designed for low maintenance and durability.

• beberesih: Periodically clean the floodlight's surface and glass with a soft, damp lawon. Ulah nganggo pembersih atanapi pangleyur anu abrasif. Pastikeun listrikna pareum sateuacan dibersihkeun.
• Résistansi korosi: The floodlight is made from maintenance-free, rust-proof aluminum, ensuring long-term durability in various weather conditions.
• Breathable Membrane: The integrated breathable membrane prevents moisture accumulation inside the lamp, maintaining optimal performance.
• Résistansi Cuaca: With an IP65 rating, the floodlight is protected against dust and water jets, making it suitable for use in rain, dust, and snow.

Figure 5: The floodlight is built to withstand various weather conditions, including heat, cold, and rain.

Figure 6: The patented ventilation plug prevents moisture buildup inside the fixture.

7. Cara ngungkulan

Upami anjeun mendakan masalah sareng lampu sorot anjeun, tingal masalah sareng solusi umum ieu:

• Lampu teu hurung:
  • Check the power supply and ensure the switch is in the 'ON' position.
  • Pastikeun sadaya sambungan listrik aman.
  • Pastikeun circuit breaker teu tripped.
• Cahya taram atawa kedip-kedip:
  • Ensure the floodlight is receiving the correct voltage (230V).
  • Pariksa sambungan kabel leupas.
  • Clean the glass surface if it is dirty.
• Water inside the fixture:
  • While the floodlight is IP65 rated, extreme conditions or improper installation can sometimes lead to issues. Ensure all seals are intact and the breathable membrane is not obstructed. If water ingress persists, contact support.

Upami léngkah-léngkah ieu henteu ngabéréskeun masalah, mangga ngahubungi dukungan palanggan.

8. Spésifikasi

Figure 7: The floodlight is equipped with IK07 safety glass for impact protection.

9. Garansi jeung Rojongan

HOFTRONIC stands behind the quality of its products. This floodlight comes with a standard manufacturer's warranty. For specific warranty terms, please refer to the documentation provided with your purchase or contact HOFTRONIC customer service.

If you experience any problems with your product or have questions not covered in this manual, please do not hesitate to contact us. We aim to respond to all inquiries within 24 hours.

Inpormasi kontak: Refer to your purchase documentation or the HOFTRONIC official websitus pikeun wincik kontak nu paling up-to-date.
