AMPBANK AB2000 2000A Portable Jump Starter User Manual

1. Produk Langkungview

The AMPBANK AB2000 is a powerful and portable jump starter designed to start 12V vehicles with up to 8.0L gasoline or 6.0L diesel engines. It also functions as a portable power bank and features an ultra-bright LED flashlight for emergency situations.

Gambar: The AMPBANK AB2000 Portable Jump Starter, highlighting its 2000A peak current, compatibility with 12V vehicles, and capacity for up to 8.0L gas and 6.0L diesel engines.

2. Émbaran Kasalametan

Always read and understand all safety information before using this product. Failure to follow these instructions may result in electric shock, fire, or serious injury.

• Keep the jump starter power above 50% for optimal starting efficiency.
• Ulah nganggo jump starter upami kabel atanapi stop kontaknaamps ruksak.
• Pastikeun sambungan polaritas anu leres (beureum clamp mun positif, hideung clamp ka négatip).
• Ulah nepi ka ngabalukarkeun hubungan arus pondok dina clamps.
• Do not expose the device to water, rain, or extreme temperatures.
• Jauhkeun tina jangkauan barudak.
• The AMPBANK jump starter incorporates 8 safety protections: anti-spark, anti-overcharge, anti-short circuit, anti-reverse connection, anti-surge, reverse polarity protection, over-discharge protection, and over-voltage panyalindungan.

Gambar: Répréséntasi visual tina AMPBANK AB2000's 8 built-in safety protections, ensuring safe operation.

3. Naon dina Box

Sacara saksama ngabongkar sadaya barang sareng pastikeun anjeun nampi ieu:

• AMPBANK AB2000 Car Jump Starter (x1)
• Jumper Cable with Smart Clamps (x1)
• Kabel Ngecas USB Tipe-C (x1)
• Buku Panduan Pamaké (x1)
• EVA Carrying Case (x1)

Image: All components included in the AMPBANK AB2000 package, neatly arranged.

4. Fitur produk jeung komponén

Familiarize yourself with the key features and ports of your AMPBANK AB2000 jump starter:

• Tombol Daya/Indikator Batré: Displays current battery level and turns the device on/off.
• Palabuhan Mimitian Luncat: Nyambungkeun kana kabel jumper pinter.
• USB Type-C Input/Output (PD18W): Pikeun ngecas jump starter sareng ngecas alat anu sanés.
• USB-A Output (5V/3A): Pikeun ngecas telepon sélulér, tablet, sareng alat anu didayakeun ku USB anu sanés.
• DC Output (12-16.8V/10A): Pikeun ngadayakeun alat 12V DC.
• Senter LED: Provides illumination with multiple modes (stable, strobe, SOS).

Gambar: The AMPBANK AB2000 unit, showcasing its design and interface elements.

5. Ngecas Jump Starter

Sateuacan dianggo anu munggaran, cas pinuh heula AMPBANK AB2000. It is recommended to recharge the jump starter once every three months if not used for a long time to maintain battery health.

1. Connect the provided USB Type-C charging cable to the Type-C input/output port on the jump starter.
2. Connect the other end of the USB Type-C cable to a compatible USB wall adapter (not included) or car charger.
3. Lampu indikator batré bakal hurung sareng kedip-kedip nalika ngecas. Sadaya opat lampu bakal hurung pageuh nalika dicas pinuh.

6. Pitunjuk Operasi: Ngahurungkeun Kendaraan sacara Langsung

Ensure the jump starter has at least 50% charge before attempting to jump start a vehicle.

1. Sambungkeun Kabel Jumper: Insert the blue plug of the smart jumper cables into the jump start port on the AMPBANK AB2000. Ensure it is fully seated.
2. Pasangkeun kana Batré:
   • Gantelkeun ka beureum positip (+) clamp ka terminal positif (+) batré kendaraan.
   • Gantelkeun ka hideung négatip (-) clamp ka terminal négatif (-) batré kandaraan.

   Nu pinter clamp indicator light will show the connection status. A solid green light indicates a correct and ready connection.

3. Mimitian Kendaraan: Lebet kana kendaraan anjeun sareng ngamimitian mesin.
4. Cabut Kabel: Sakali kandaraan dihurungkeun, langsung cabut konci négatif (-) hideungamp tina batré kandaraan, teras cabut konci positif (+) beureumamp. Finally, disconnect the smart jumper cables from the jump starter.

Using "BOOST" Mode for Completely Dead Batteries

If the vehicle battery is completely dead or has very low voltage, the standard jump start procedure might not work. In such cases, use the "BOOST" function:

1. Follow steps 1 and 2 above to connect the jumper cables to the jump starter and the vehicle battery.
2. Press and hold the "BOOST" button on the smart clamp for 3 seconds. The indicator light will turn solid green, indicating "BOOST" mode is active.
3. Immediately start the vehicle within 30 seconds. If the car does not start, the "BOOST" mode will exit, and you will need to repeat the process.
4. Sakali kandaraan dihurungkeun, langsung cabut konci négatif (-) hideungamp, then the red positive (+) clamp, and finally disconnect the smart jumper cables from the jump starter.

Gambar: The AMPBANK AB2000 connected to a car battery, illustrating the "BOOST" mode button on the smart clamp for starting completely dead batteries.

7. Fungsi séjén

7.1 Power Bank portabel

The AB2000 can charge various electronic devices:

• USB Type-C (PD18W) & USB-A (5V/3A): Connect your mobile phone, tablet, or other USB-powered devices using their respective charging cables to the appropriate output ports.
• DC Output (12-16.8V/10A): Use this port to power 12V DC devices, such as car vacuum cleaners or tire inflators (ensure compatibility).

Gambar: The AMPBANK AB2000 functioning as a portable power bank, charging a smartphone and a tablet simultaneously.

7.2 Ultra-Bright LED Light

The built-in LED flashlight offers three modes for various situations:

1. Pikeun Ngahurungkeun/Pareuman: Press and hold the flashlight button for 3 seconds.
2. Pikeun Ngarobah Modeu: Short press the flashlight button to cycle through modes: Stable Light → Strobe Light → SOS Signal.

Gambar: The AMPBANK AB2000's high-power LED flashlight in use, demonstrating its utility for illumination and emergency signaling.

8. Pangropéa

• Ngecas: If the jump starter is not used for a long time, it is recommended to recharge it once every three months to prolong battery life.
• beberesih: Anggo lawon anu lemes sareng garing pikeun ngabersihkeun alat ieu. Entong nganggo bahan kimia anu keras atanapi bahan anu kasar.
• Panyimpenan: Store the jump starter in its EVA carrying case in a cool, dry place, away from direct sunlight and extreme temperatures.

9. Cara ngungkulan

10. Spésifikasi

11. Garansi jeung Rojongan

The AMPBANK AB2000 comes with a 1-year quality assurance warranty and a 30-day free refund period. Lifetime free technical support is also provided.

For any questions or support needs, please contact AMPBANK customer service.
