Leica Rangemaster CRF-R Laser Rangefinder User Manual

1. Bubuka

This manual provides essential information for the proper use and maintenance of your Leica Rangemaster CRF-R Laser Rangefinder. Please read this manual thoroughly before operating the device to ensure optimal performance and safety.

The Leica Rangemaster CRF-R is a compact, lightweight, and weather-resistant laser rangefinder designed for quick and precise distance measurement in outdoor and hunting environments. It offers rapid measurement results and high-quality optics for clear target identification.

2. Produk Langkungview jeung Fitur

The Leica Rangemaster CRF-R is engineered for reliability and ease of use, providing accurate distance readings up to 1,800 meters.

Fitur konci:

• Precision Rangefinding: Delivers exact measurement results in under 0.3 seconds, up to 1,800 meters.
• Optik kualitas luhur: Ensures clear and sharp images for precise target identification, even in challenging lighting conditions, with excellent light transmission.
• Fast Measurement Speed: Allows for quick acquisition of distances, enabling timely and informed decisions.
• Konstruksi Tahan Cuaca: Built to withstand diverse weather conditions, maintaining accuracy and functionality in rain, snow, or extreme temperatures.
• Desain Kompak & Ringan: Designed for portability and comfortable handling during extended use in the field.
• Equivalent Horizontal Range (EHR): Displays actual measured range or equivalent horizontal range for angle shots.

komponén:

• Leica Rangemaster CRF-R Laser Rangefinder
• Mawa Kasus
• Manual pamaké
• Battery (CR2 Lithium-Ion, not included)

Gambar 1: Angled view of the Leica Rangemaster CRF-R Laser Rangefinder, showing the objective lens and eyepiece.

Gambar 2: Top view of the Leica Rangemaster CRF-R, highlighting the control buttons.

3. Setélan

3.1 Pamasangan batré

1. Panggihan panutup kompartemen batréna, biasana di sisi atawa handap alat.
2. Unscrew or open the cover.
3. Insert one CR2 Lithium-Ion battery, ensuring correct polarity (+/-).
4. Tutup panutup kompartemen batréna.

Note: Batteries are not included with the device and must be purchased separately.

3.2 Diopter adjustment

To ensure a sharp image, adjust the diopter to your individual eyesight:

1. Look through the eyepiece at a distant object.
2. Rotate the diopter adjustment ring (usually located on the eyepiece) until the image appears sharp and clear.

4. Parentah Operasi

4.1 Nyandak Pangukuran

1. Point the rangefinder at your desired target.
2. Press and hold the main measurement button (typically on the top of the device).
3. The distance measurement will appear in the display within 0.3 seconds.
4. Release the button to turn off the display and conserve battery life.

Figure 3: A user demonstrating the compact size and ease of handling of the Leica Rangemaster CRF-R in an outdoor setting.

4.2 Switching Measurement Modes (Actual vs. EHR)

The CRF-R can display either the actual measured distance or the Equivalent Horizontal Range (EHR), which compensates for uphill or downhill angles.

1. With the device on, press the mode button (usually a smaller button near the main measurement button) to cycle through available display modes.
2. Select the desired mode (e.g., actual distance or EHR) as indicated in the display.

4.3 Using in Different Environments

The weather-resistant design allows for use in various conditions. However, extreme fog, heavy rain, or snow may affect measurement accuracy and range. For optimal performance, ensure the lenses are clean and free from obstructions.

Figure 4: The compact design of the rangefinder allows for easy storage in a backpack, demonstrating its portability.

5. Pangropéa

5.1 Ngabersihan Optik

To maintain optical clarity, clean the lenses regularly:

• Use a soft, lint-free cloth or a lens brush to remove dust and loose particles.
• For stubborn dirt or smudges, use a specialized optical cleaning solution and a clean microfiber cloth.
• Ulah make bahan abrasive atawa bahan kimia kasar, sabab ieu bisa ngaruksak coatings lénsa.

5.2 Perawatan Umum

• Simpen rangefinder dina wadah pelindungna nalika teu dianggo.
• Hindarkeun ngalaan alat ka suhu anu ekstrim atanapi sinar panonpoé langsung kanggo waktos anu berkepanjangan.
• If the device becomes wet, dry it thoroughly with a soft cloth before storing.
• Cabut batré upami alatna moal dianggo kanggo waktos anu panjang pikeun nyegah bocor.

6. Cara ngungkulan

If problems persist, please contact Leica customer support.

7. Spésifikasi

8. Garansi jeung Rojongan

For detailed warranty information and customer support, please refer to the official Leica website or the documentation included with your product. Leica offers comprehensive support for its products.

Anjeun oge bisa nganjang ka Toko Leica di Amazon pikeun émbaran produk tambahan jeung asesoris.
