Bubuka
Thank you for choosing the Haier 7 Kg 5 Star Inverter Direct Motion Motor Fully Automatic Front Load Washing Machine, model HW70-IM12929S6. This manual provides essential information for the safe and efficient operation, installation, and maintenance of your new appliance. Please read it thoroughly before using the washing machine and keep it for future reference.
Parentah Kasalametan
Pikeun nyegah tatu pribadi atawa karuksakan harta, salawasna turutan pancegahan kaamanan dasar ieu:
- Pastikeun yén mesin cuci geus bener grounded.
- Ulah ngantep barudak maén dina atawa dina alat.
- Keep flammable materials away from the washing machine.
- Entong ngumbah barang-barang anu parantos dibersihkeun, dikumbah, direndam, atanapi katémbong ku bahan anu kaduruk atanapi ngabeledug.
- Cabut colokan alat sateuacan beberesih atanapi ngalakukeun perawatan naon waé.
- Do not operate the washing machine if it is damaged or malfunctioning. Contact customer service.
- Always close the water taps after use.
Produk Leuwihview
Fitur konci
- Kapasitas: 7 kg, suitable for 3-4 members.
- Énergi Énergi: 5 rating béntang pikeun efisiensi pangalusna-di-kelas.
- Motor: Inverter Direct Motion Motor with 1200 RPM for faster wash and drying.
- Program nyeuseuh: 15 diverse wash programs.
- Tipe Drum: 525 Super Drum with Pillow shape and Laser Seamless Welding for gentle fabric care.
- Hygiene Features: Puri Steam, Dual Spray, Anti-bacterial technology.
- Kontrol: LED display and button controls.
- Fitur husus: Child Lock, Drum Clean, Vibration Reduction, AI-DBT.
Komponén Kaasup
- Selang solokan
- Ngeusian Selang
produk Views
Gambar 1: Hareupeun view of the Haier HW70-IM12929S6 Front Load Washing Machine, showing the control panel and drum door.
Gambar 2: Sisi view of the Haier HW70-IM12929S6 Washing Machine, highlighting its compact design.
Gambar 3: Balik view of the Haier HW70-IM12929S6 Washing Machine, showing hose connections and power cord.
Figure 4: Illustration of key features including the 525mm Super Drum, Inverter Motor (1200 RPM), and Anti-Bacterial Technology with Dual Spray.
Figure 5: Illustration detailing the Pillow Drum, PuriStream Refresh function, and Dual Spray system for enhanced cleaning.
Setup sareng Instalasi
Ngabongkar bungkusan
- Taliti miceun sadaya bahan bungkusan.
- Remove the transit bolts from the rear of the machine. Keep them for future transport.
- Check for any damage during transit. If damaged, do not install and contact your dealer.
Lokasi
- Teundeun mesin cuci dina permukaan anu rata.
- Mastikeun spasi nyukupan sabudeureun mesin pikeun ventilasi jeung perawatan.
- Hindarkeun sinar panonpoé langsung atanapi suhu anu ekstrim.
Sambungan Cai
- Connect the supplied fill hose to a cold water tap with a 3/4 inch thread.
- Pastikeun sadaya sambungan kedap pikeun nyegah bocor.
- Posisikeun selang pembuangan kana pipa tegak atanapi di luhureun sisi bak cuci, pastikeun selangna parantos dipasang pageuh sareng henteu bengkok.
Sambungan Listrik
- Colokkeun kabel listrik kana stop kontak listrik anu grounded leres.
- Entong nganggo kabel ekstensi atanapi adaptor.
- Pastikeun voltage jeung frékuénsi cocog spésifikasi dina plat rating.
Parentah Operasi
Sateuacan Paké Kahiji
- Run an empty wash cycle with a small amount of detergent to clean the drum.
Loading laundry
- Urutkeun cucian dumasar kana jinis lawon, warna, sareng tingkat kekotoran.
- Open the door and load items loosely into the drum, ensuring not to overload.
- Tutup panto pageuh.
Nambahkeun Detergent jeung Aditif
- Tarik kaluar laci dispenser detergent.
- Tambahkeun deterjen dina jumlah anu cekap kana kompartemen cuci utama.
- Tambahkeun softener lawon atawa aditif séjén kana compartments maranéhanana ditunjuk.
- Nyorong laci deui gently.
Milih Program Nyeuseuh
Turn the program selector knob to choose one of the 15 available wash programs. Refer to the control panel for program names such as Cotton, Synthetics, Mix, Quick 15', Sportswear, Jeans, Baby Care, Daily, Delicate, Spin, Refresh, PuriSteam, etc.
Additional options like temperature, spin speed, delay start, and extra rinse can be selected using the corresponding buttons on the control panel.
Ngamimitian Siklus Ngumbah
- Pencét tombol "Start/Pause" pikeun ngamimitian siklus nyeuseuh anu dipilih.
- The machine will automatically lock the door and start filling with water.
Nutup Siklus Nyeuseuh
- Once the cycle is complete, the machine will signal with an audible alert and the door will unlock.
- Cabut laundry geuwat pikeun nyegah wrinkles.
- Unplug the machine and close the water tap.
Pangropéa sareng Perawatan
Ngabersihan Luar
- Ngusap luar ku hipu, damp lawon. Ulah make cleaners abrasive.
Ngabersihan Dispenser Deterjen
- Remove the dispenser drawer and rinse it under running water to remove detergent residue.
- Bersihkeun wadah laci dispenser nganggo sikat.
Drum Beresih Fungsi
- Regularly use the "Drum Clean" program to maintain hygiene and prevent odor buildup.
- Follow the instructions on the control panel for this specific cycle.
Ngabersihkeun saringan pompa solokan
- Manggihan panutup filter di hareup handap mesin.
- Teundeun wadah deet underneath pikeun nyekel sagala cai sésa.
- Carefully unscrew and remove the filter. Clean any lint or debris.
- Pasang deui sareng kencengkeun saringan kalayan pageuh.
Pamérésan masalah
Sateuacan ngahubungi layanan palanggan, mangga parios masalah umum ieu:
| Masalah | Mungkin Cukang lantaranana | Solusi |
|---|---|---|
| Mesin teu ngamimitian | Power cord unplugged, door not closed, program not selected, "Start/Pause" not pressed. | Check power connection, ensure door is latched, select program, press "Start/Pause". |
| Taya eusian cai | Water tap closed, water supply cut off, fill hose kinked. | Open water tap, check water supply, straighten fill hose. |
| Cai teu draining | Selang solokan kinked atanapi diblokir, filter pompa solokan clogged. | Luruskeun selang solokan, bersihan saringan pompa solokan. |
| Geter / noise anu kaleuleuwihi | Baut transit teu dicabut, mesin teu rata, beban teu rata. | Cabut bolts transit, saluyukeun leveling suku, redistribute laundry. |
| Panto teu tiasa dibuka | Cycle in progress, water still in drum, child lock active. | Wait for cycle to finish, select drain program, deactivate child lock. |
spésifikasi
| Nomer modél | HW70-IM12929S6 |
| Kapasitas | 7 kg |
| Modeu Operasi | Pinuh Otomatis |
| Lokasi Aksés | Beban hareup |
| Laju rotasi maksimum | 1200 rpm |
| Jumlah Daur Cuci | 15 |
| Bahan Drum | Beusi sténless |
| Ukuran produk (L x W x H) | 48.2D x 59.6W x 84.4H Sentimeter |
| Item Beurat | 56 kg |
| Fitur husus | Child Lock, Drum Clean, Hygiene Steam, Inverter, Vibration Reduction |
| Énergi Star Rating | 5 Béntang |
Garansi sareng Rojongan
Émbaran jaminan
- Garansi produk: 5 years comprehensive warranty from the date of purchase.
- Garansi Motor: 12 years warranty on the Inverter Direct Motion Motor.
- This warranty covers manufacturing defects under normal use. Please retain your purchase receipt for warranty claims.
Rojongan Palanggan
Pikeun patalékan, paménta jasa, atanapi bantosan téknis, mangga ngahubungi Haier Customer Care:
- Nomer Bebas Pulsa: 1800-102-9999
- Surélék: info@haierindia.com
- Alamat Pabrikan: Haier Appliances (India) Pvt. Ltd., B-3, MIDC Ranjangaon, Tal. Shirur, Pune-412209, India.
