Buku Panduan Pangguna Lampu Kerja LED EMOS P4538 anu tiasa dicas ulang

Bubuka

This manual provides instructions for the safe and efficient use of your EMOS P4538 Rechargeable LED Work Light. Please read this manual carefully before first use and keep it for future reference.

Émbaran Kasalametan

• Entong ningali langsung kana lampu LED.
• Jauhkeun tina jangkauan barudak.
• Ulah ngabongkar atawa ngaropéa alat.
• Paké ngan kabel USB-C disadiakeun pikeun ngecas.
• Entong kakeunaan suhu anu ekstrim atanapi sinar panonpoé langsung.
• Buang batré nurutkeun peraturan lokal.

Eusi pakét

• 1 x Lampu Kerja LED EMOS P4538 anu tiasa dicas ulang
• 1 x Kabel Ngecas USB-C
• Manual pamaké

Produk Leuwihview

Familiarize yourself with the components of your EMOS P4538 work light.

This image illustrates the key features of the EMOS P4538 work light, including the main LED strip, the SMD LED, the USB-C charging port, the battery indicator lights, the power/boost button, and the integrated magnets on the back.

gambar ieu nyadiakeun rinci view of the USB-C charging port and the LED battery indicator, which shows the current charge level of the device.

Ngecas Batré

1. Panggihan port ngecas USB-C di sisi lampu kerja.
2. Connect the provided USB-C cable to the work light and the other end to a compatible USB power adapter (not included).
3. The LED battery indicator will show the charging status. When all four segments are lit, the battery is fully charged.
4. Ngeusi batre pinuh butuh kurang leuwih 3-6 jam.

The work light features overcharge and over-discharge protection for battery longevity.

Operasi

The EMOS P4538 offers three light modes and a boost function.

This image summarizes the key operational specifications: 700 lumens maximum brightness, up to 6 hours runtime, 45 meters beam range, and its rechargeable nature with three distinct light modes.

Turning On/Off and Switching Modes

1. Pencét tombol daya sakali pikeun ngahurungkeun lampu.
2. Subsequent presses will cycle through the light modes:
   • LED Light (Front): 50 lm, 45 m beam range.
   • SMD LED (Floodlight): 350 lm, 30 m beam range.
3. Pikeun mareuman lampu, pencét jeung tahan tombol daya salila 3 detik.

Fungsi naekeun

The Boost function provides maximum light output for a short period.

1. While the light is on (in any mode), press the power button again to activate the Boost function.
2. The light output will increase to 700 lm for 30 seconds.
3. After 30 seconds, the light will return to its previous mode and brightness.

This image shows the EMOS P4538 work light in action, providing bright illumination inside an electrical panel, highlighting its utility for detailed work in dark environments.

Pamasangan sareng Penempatan

The EMOS P4538 features two integrated magnets on its back for versatile mounting options.

• Attach the work light to any metallic surface, such as car hoods, metal shelves, or machinery.
• The ergonomic rubberized handle also provides a comfortable grip for handheld use.

Pangropéa

• Clean the work light with a soft, damp lawon. Ulah make cleaners abrasive atawa pangleyur.
• Ensure the USB-C port cover is closed when not charging to prevent dust and moisture ingress.
• Simpen alat dina tempat anu tiis sareng garing upami henteu dianggo.
• Recharge the battery periodically if the device is stored for extended periods to maintain battery health.

Pamérésan masalah

Lampu teu hurung:

• Check the battery level using the LED indicator. Recharge if necessary.
• Ensure the power button is pressed correctly (short press for on, long press for off).

Kaluaran cahaya taram:

• Batré bisa jadi lemah. Ngecas deui alat.
• Ensure the correct light mode is selected.

Alat teu ngecas:

• Verify the USB-C cable is securely connected to both the light and the power adapter.
• Coba kabel USB-C atanapi adaptor kakuatan anu sanés.
• Ensure the power adapter is functional.

spésifikasi

This image provides a visual representation of the EMOS P4538 work light's dimensions, indicating its length, width, and thickness for reference.

Garansi sareng Rojongan

For warranty information or technical support, please refer to the documentation provided with your purchase or visit the official EMOS websitus.
