1. Bubuka
This manual provides essential information for the safe and efficient installation, operation, and maintenance of your HOFTRONIC F03 IP66 LED Luminaire. This 150 cm, 60W, 7800lm luminaire features an integrated Osram transformer and offers adjustable color temperature and power output. Its IP66 rating ensures suitability for damp jeung lingkungan berdebu.
A nutup-up view of the HOFTRONIC F03 IP66 LED Luminaire, showcasing its robust design and sealed end cap.
2. Parentah Kasalametan
- Salawasna pegatkeun sambungan kakuatan saméméh instalasi, perawatan, atawa beberesih.
- Pamasangan kedah dilakukeun ku tukang listrik anu mumpuni saluyu sareng kode listrik lokal.
- Ulah ngarobah luminaire dina sagala cara.
- Mastikeun beungeut ningkatna bisa ngarojong beurat luminaire nu.
- Avoid looking directly into the LED light source when it is active.
- This product is designed for AC/DC power supply at 230 Volts.
3. Eusi Paket
Pariksa yén sadaya komponén aya sateuacan ngamimitian pamasangan:
- 1x LED TL Fixture F-Series F03
- 2x kaop
- 2x clamps
- 2x Rubber Rings + Plugs
- 4x obeng
- 4x Smaller Screws
- 4x nyolok
Hiji leuwihview of all components included in the package: 1x LED TL Fixture F-Series F03, 2x Caps, 2x Clamps, 2x Rubber Rings + Plugs, 4x Screws, 4x Smaller Screws, and 4x Plugs.
4. Setup jeung Instalasi
4.1 Pamasangan
- Choose a suitable location for wall mounting, ensuring the surface is stable and can support the luminaire's weight.
- Paké cl disadiakeunamps and screws to securely attach the luminaire to the desired surface.
4.2 Wiring jeung Sambungan
The luminaire is designed for direct connection to a 200-240V AC power supply. It is also connectable to other HOFTRONIC F03 luminaires using Hoftronic Xtrem cables (SKU: 250596) for extended lighting setups.
A detailed diagram illustrating how to connect the HOFTRONIC F03 LED Luminaire, including connections for the main luminaire and linking additional units using Hoftronic Xtrem cables (SKU: 250596).
- Pastikeun daya dina pemutus sirkuit utama geus dicabut.
- Open the luminaire's wiring compartment.
- Connect the live (brown), neutral (blue), and ground (green/yellow) wires from your power supply to the corresponding terminals inside the luminaire.
- If linking multiple luminaires, connect the Hoftronic Xtrem cable between the designated linking ports of each luminaire.
- Securely close the wiring compartment, ensuring a watertight seal with the provided caps and rubber rings to maintain the IP66 rating.
- Balikkeun kakuatan sarta nguji luminaire nu.
5. Parentah Operasi
The HOFTRONIC F03 LED Luminaire offers adjustable power output and color temperature to suit various lighting needs.
5.1 adjustment kakuatan
The luminaire allows for adjustment of its power consumption, which directly affects its brightness. Refer to the product's internal settings or external controls (if applicable) to select between 35W, 40W, 50W, or 60W output.
Visual representation of the HOFTRONIC F03 LED Luminaire's adjustable power output, demonstrating light intensity at 35W, 40W, 50W, and 60W settings.
5.2 Ngatur Suhu Warna
You can adjust the color temperature of the light to create different ambiances or suit specific tasks. Options typically include 3000K (warm white), 4000K (neutral white), and 5000K (cool white).
Illustration of the HOFTRONIC F03 LED Luminaire's adjustable color temperature feature, displaying light outputs at 3000K (warm white), 4000K (neutral white), and 5000K (cool white).
6. Pangropéa
The HOFTRONIC F03 LED Luminaire requires minimal maintenance due to its durable design and IP66 rating.
- beberesih: Periodically clean the exterior of the luminaire with a soft, damp lawon. Ulah make cleaners abrasive atawa pangleyur. Pastikeun kakuatan pareum sateuacan beberesih.
- Pamariksaan: Regularly inspect the luminaire for any signs of damage, loose connections, or wear. If any issues are found, disconnect power and consult a qualified technician.
- LEDs: The integrated LEDs are designed for a long lifespan (50,000 hours) and are not user-replaceable.
The HOFTRONIC F03 LED Luminaire is shown with water splashing, emphasizing its IP66 rating for water and dust resistance, making it suitable for harsh environments.
7. Cara ngungkulan
Upami anjeun ngalaman masalah sareng lampu anjeun, tingali masalah sareng solusi umum ieu:
- Luminaire does not turn on:
- Pariksa catu daya sareng pemutus sirkuit.
- Pastikeun sadaya sambungan kabel aman.
- Light output is dim or flickers:
- Verify the selected power setting.
- Pariksa catu daya stabil.
- Suhu warna anu salah:
- Adjust the color temperature setting as desired.
Pikeun masalah pengkuh, kontak rojongan customer.
8. Spésifikasi
| Fitur | Spésifikasi |
|---|---|
| merek | HOFTRONIC |
| Nomer modél | 5430022 |
| Item Beurat | 5 kg |
| Peunteun IP | IP66 (Tahan Cai sareng Lebu) |
| Gaya | Modern |
| Bahan | palastik |
| Tipe rengse | Dilapis bubuk |
| Jumlah Sumber Cahaya | 1 (LED terpadu) |
| Wat maksimumtage | 60 Watts (Adjustable) |
| Voltage | 230 volt |
| Mangpaat husus | Cocog jeung damp and dusty environments (e.g., garage, workshop, outdoor covered areas) |
| Fitur husus | Dimmable, Color Adjustable |
| Sudut Cahaya | Lampu handap |
| Sumber Daya | AC / DC |
| Tipe Pamasangan | Tembok Gunung |
| Batré Dibutuhkeun | No |
| Fluks Luminous | 7800 lm |
| Sarua Pijar | 300 Watt |
| Rata Kahirupan | 50,000 Jam |
| Kelas Efisiensi Énergi (2019/2015) | E |
The EU energy label for the HOFTRONIC LED Luminaire model 5430022, indicating an energy efficiency class of E and energy consumption of 60 kWh/1000h. For more product information, scan the QR code or visit eprel.ec.europa.eu/qr/739049.
9. Garansi jeung Rojongan
For warranty information and customer support, please refer to the documentation provided with your purchase or visit the official HOFTRONIC websitus. Simpen bukti pameseran anjeun pikeun klaim garansi.
