Hiseeu 16-Channel Wireless NVR Instruction Manual

Bubuka

This manual provides detailed instructions for the installation, operation, and maintenance of your Hiseeu 16-Channel Wireless Network Video Recorder (NVR) Model CS-1202000. Please read this manual thoroughly before using the product to ensure proper functionality and safety.

Émbaran Kasalametan

• Ensure the NVR is powered by a 12V2A or 12V3A output power supply.
• Ulah ngalaan alat ka cai atawa beueus.
• Hindarkeun nempatkeun alat dina sinar panonpoé langsung atanapi caket sumber panas.
• Handle the hard drive with care during installation to prevent damage.
• Jauhkeun alat tina médan magnét anu kuat.

Eusi pakét

The standard package for your Hiseeu 16-Channel Wireless NVR includes the following items:

• Hiseeu 16-Channel Wireless NVR (Hard Drive and Cameras not included)
• Sasayogian tanaga
• Kabel HDMI
• Kabel Jaringan
• Beurit kabel
• Screws for Hard Drive Installation

Produk Leuwihview

The Hiseeu 16-Channel Wireless NVR supports recording at 1080P/2MP, 3MP, and 5MP resolutions. It features a built-in Wi-Fi router, allowing it to receive and record all cameras using its own bandwidth, minimizing impact on your home network. An internet connection is only required for remote viewing.

Disetél

Pamasangan Hard Drive

To save recordings, an internal 2.5'' or 3.5'' hard drive (up to 6TB capacity) must be installed. Follow the steps in the video below for proper installation.

Nyambungkeun Kaméra

New cameras are not pre-paired with your NVR. Follow these steps to add new cameras to your system:

1. Right-click your NVR mouse.
2. Choose "camera" then select the "+" icon.
3. Press the camera reset button for approximately 10 seconds.
4. Click "Continue" on the NVR interface.
5. Wait for a new IP address to appear, then click "Continue". If no IP address appears, click "Search again".

For a visual guide, refer to the video below:

Connecting a WiFi Repeater

If you need to extend the wireless range for your cameras, you can connect a WiFi repeater. The following video demonstrates the process:

Operasi

NVR Interface Napigasi

Navigate the NVR interface using the provided wired mouse. Right-clicking the mouse will typically bring up the main menu options.

PTZ Functionality

If your extended camera supports Pan-Tilt-Zoom (PTZ) functionality, you can control these movements directly through the NVR's mouse interface. This allows for dynamic adjustment of camera views.

Jauh Viewing

Pikeun jauh viewing of your camera feeds from other locations, an internet connection is required. The NVR supports 2.4G/5G WiFi when connected to a network. Utilize the mobile application for two-way audio functionality, ensuring your camera also supports this feature.

Pangropéa

Reset kecap akses

If you need to reset your NVR password, follow the instructions in the video below. Ensure you set a new, strong password for security.

Manajemén Hard Drive

The NVR supports hard drives up to 6TB for continuous recording. Regularly check the hard drive status and ensure sufficient storage space. Formatting the hard drive may be necessary during initial setup or if issues arise.

Pamérésan masalah

• Taya Sinyal Video: Check all power connections to the NVR and cameras. Ensure cameras are properly paired (refer to "Connecting Cameras" section). Verify HDMI/VGA cable connection to the display.
• NVR Teu Nyala: Confirm the power adapter is correctly connected and providing the specified voltage (12V2A or 12V3A).
• Cannot Access NVR: If you forgot your password, refer to the "Password Reset" video. Ensure your network connection is stable for remote access.
• Sinyal Wireless goréng: Consider using a WiFi repeater (refer to "Connecting a WiFi Repeater" video) or repositioning cameras/NVR to improve signal strength.
• Henteu aya Kaluaran Audio: Ensure an HDMI cable is used to connect to an HD TV. Verify that the connected camera supports audio functionality.

spésifikasi

Garansi sareng Rojongan

Hiseeu offers lifetime support for its products, including email, phone call, and online chat assistance. For specific warranty details and to access support, please refer to the official Hiseeu websitus atanapi inpormasi kontak anu disayogikeun dina bungkusan produk anjeun.
