The Electro-Voice EVOLVE 30M is a portable powered column loudspeaker system designed for superior audio performance and flexible functionality in a compact package. It features an eight-channel digital mixer, studio-quality onboard effects, and remote control capabilities via the Electro-Voice QuickSmart Mobile application. This system is ideal for solo musicians, small musical groups, and venues requiring an easy-to-use, highly portable, and lightweight sound solution with excellent connectivity, control, coverage, and output.
Disetél
Setting up your EVOLVE 30M system is designed to be quick and straightforward, allowing for single-trip portability. Follow these steps for proper assembly and initial power-up.
1. Unpacking sarta Idéntifikasi komponén
Carefully remove all components from the packaging. The system includes a speaker array, a two-piece pole connector, an array and pole backpack carry case, and a powered subwoofer.
Angka 1: Ngabeledug view of the EVOLVE 30M components, showing the subwoofer, two pole pieces, and the column array.
2. Majelis
- Place the subwoofer on a stable, flat surface.
- Insert the first pole connector into the top of the subwoofer. Ensure it is securely seated.
- Connect the second pole connector to the first.
- Attach the column array to the top of the assembled pole. The system is designed for a secure, interlocking fit.
Figure 2: Fully assembled EVOLVE 30M system, ready for operation.
Gambar 3: Sisi view of the assembled EVOLVE 30M, highlighting its compact design.
3. Sambungan Daya
Connect the IEC power cable to the power inlet on the rear panel of the subwoofer. Plug the other end into a suitable AC power outlet. The system operates on corded electric power.
Figure 4: Rear panel of the EVOLVE 30M subwoofer, displaying various input/output ports and the power connection.
Parentah Operasi
The EVOLVE 30M features an intuitive control panel and can also be managed remotely via the QuickSmart Mobile application.
1. Ngahurungkeun sareng Setup Awal
- Pastikeun sadaya sambungan aman.
- Flip the power switch on the rear panel to the "ON" position. The QuickSmart DSP display will illuminate.
- Use the master volume knob to set an initial low volume level.
2. Sambungan Input
The system offers a variety of input options:
- Input XLR: For microphones and line-level devices.
- 1/4" TRS Inputs: For instruments and line-level devices.
- Input RCA: Pikeun alat audio konsumen.
- 3.5 mm Input: For portable media players.
- Bluetooth: Pikeun streaming audio nirkabel tina alat anu cocog.
- Saklar suku: For remote control of effects or other functions.
Gambar 5: Detil view of the EVOLVE 30M's input and output section on the rear panel.
3. QuickSmart DSP and Mobile App Control
The integrated QuickSmart DSP allows for comprehensive control over your sound. You can adjust settings directly on the unit's display or via the QuickSmart Mobile application (available on Apple Store and Google Play).
- Adun: Control individual channel levels, effects sends, and main mix.
- Balukar: Access studio-quality onboard effects.
- System Presets: Optimize sound for different applications (e.g., music, speech, live).
- Kontrol Subwoofer: Adjust subwoofer level and crossover.
Figure 6: The QuickSmart Mobile app interface on a tablet, showing mixer controls for the EVOLVE 30M.
Pangropéa
Proper maintenance ensures the longevity and optimal performance of your EVOLVE 30M system.
- beberesih: Anggo lawon anu lemes sareng garing pikeun ngabersihkeun permukaan luar. Hindarkeun pembersih atanapi pangleyur anu abrasif.
- Panyimpenan: When not in use, store the system in its provided carry case in a dry, temperature-controlled environment.
- Manajemén Kabel: Always coil cables neatly after use to prevent damage.
- Pamariksaan: Periodically inspect cables and connectors for any signs of wear or damage.
Pamérésan masalah
This section provides solutions to common issues you might encounter with your EVOLVE 30M system.
| Masalah | Mungkin Cukang lantaranana | Solusi |
|---|---|---|
| Taya Kaluaran Sora |
|
|
| Audio distorsi |
|
|
| Masalah Konektipitas Bluetooth |
|
|
spésifikasi
| Fitur | Rincian |
|---|---|
| Modél | F.01U.366.319 |
| Tipe Pamasangan | Stépar |
| Sumber Daya | Kabel Listrik |
| Tipe Panyambung | XLR, RCA, IEC power |
| Item Beurat | 16.6 pon |
| Jumlah Saluran | 8 |
| Input Audio | XLR, 1/4" TRS, RCA, 3.5 mm, Bluetooth, Footswitch |
| Wattage | 1000 watt |
| Dimensi produk | 19.69 x 15.35 x 19.69 inci |
| Warna | Hideung |
Émbaran jaminan
Electro-Voice products are manufactured to the highest quality standards. For detailed warranty information, please refer to the official Electro-Voice websitus atanapi ngahubungan rojongan customer. Simpen bukti pameseran anjeun pikeun klaim garansi.
Rencana panyalindungan sayogi kanggo ngagaleuh:
- Plan Protection 2 Taun
- Plan Protection 3 Taun
- Lengkep Nangtayungan (tagihan bulanan)
Ngarojong
For technical assistance, product registration, or further inquiries, please visit the official Electro-Voice website or contact their customer support team. Online resources, FAQs, and driver downloads may also be available.
Pabrikan: Éléktro-Sora
Websitus: www.electrovoice.com (Kelample link, actual link not provided in input)
