ROBOTIME Terminator M870 Wooden 3D Puzzle Gun Instruction Manual

1. Bubuka

Thank you for choosing the ROBOTIME Terminator M870 Wooden 3D Puzzle Gun. This mechanical model kit offers an engaging and educational building experience, culminating in a functional rubber band gun. This manual provides detailed instructions for assembly, operation, and maintenance to ensure a safe and enjoyable experience.

2. Émbaran Kasalametan

• Saran umur: This product is recommended for individuals aged 14 years and older. It contains small parts that may pose a choking hazard for younger children.
• Pangawasan Dewasa: Pangawasan déwasa disarankeun nalika ngarakit sareng ngoperasikeun, khususna pikeun pangguna anu langkung ngora.
• Rubber Band Safety: Use only the provided rubber band bullets. Do not aim at eyes, faces, or fragile objects. Ensure a clear firing path.
• Pangolahan Bahan: The wooden pieces are precisely cut. Handle them carefully to avoid splinters or breakage.
• Henteu aya modifikasi: Do not modify the product in any way, as this may compromise its safety and functionality.

3. Eusi Paket

Before beginning assembly, please verify that all components are present and undamaged. The package should contain the following:

• 172 Laser-cut wooden pieces
• Illustrated English Instruction Manual
• Rubber band bullets (approx. 100 pieces)
• Target (cardboard or wooden standees)
• Small accessories (e.g., sandpaper, wax if needed for smooth operation)

Image: All components included in the ROBOTIME Terminator M870 kit, neatly laid out.

4. Parentah Majelis (Setup)

The Terminator M870 is a self-assembly model that requires no glue. Follow the detailed steps in the included illustrated manual for best results. Assembly typically takes approximately 1.5 hours.

1. Prepare the Pieces: Carefully pop out each wooden piece from the laser-cut sheets. Identify each piece by its corresponding number or letter as indicated in the manual.
2. Turutan Manual: Refer to the step-by-step illustrated English manual. Each step shows which pieces to connect and in what order.
3. Gentle Assembly: Assemble pieces one by one. Apply gentle, even pressure to connect parts. Do not force pieces together, as this may cause damage. If a piece doesn't fit, check its orientation and ensure no burrs are present. Small pieces of sandpaper may be used to smooth edges if necessary.
4. Bagian mékanis: Pay close attention to the assembly of moving parts, such as the trigger and rotating chamber, to ensure smooth operation.
5. Cék ahir: Once assembled, check all connections for stability and ensure all moving parts operate freely.

Image: Detailed diagram highlighting the main functional components of the Terminator M870.

5. Parentah Operasi

Once assembled, your ROBOTIME Terminator M870 is ready for action. Follow these steps for safe and effective operation:

1. Load Rubber Bands: Place the provided rubber band bullets onto the designated hooks or slots on the rotating chamber. Ensure they are securely seated.
2. Prime the Mechanism: Depending on the model, you may need to pull back a lever or slide the pump action to cock the firing mechanism.
3. Tujuan: Hold the model firmly and aim at a safe target. The effective range for the rubber band bullets is approximately 3-5 meters.
4. seuneu: Gently press the trigger to release the rubber band. The rotating chamber will advance to the next rubber band automatically.
5. Muat deui: Repeat the loading process for continuous play.

Image: The Terminator M870 ready for target practice with included wooden figures.

6. Pangropéa

To ensure the longevity and smooth operation of your wooden puzzle gun, follow these simple maintenance guidelines:

• beberesih: Wipe the model with a dry, soft cloth to remove dust and debris. Do not use water or chemical cleaners, as they can damage the wood.
• Panyimpenan: Store the model in a cool, dry place away from direct sunlight and extreme temperatures. High humidity can cause the wood to warp or swell.
• Lubrication (Pilihan): If any moving parts feel stiff over time, a small amount of paraffin wax or a dry lubricant can be applied to the contact points to improve smoothness.
• Inspect Rubber Bands: Periodically check the rubber bands for signs of wear or degradation. Replace them if they become brittle or lose elasticity.

7. Cara ngungkulan

If you encounter any issues with your Terminator M870, refer to the following common problems and solutions:

8. Spésifikasi

Key specifications for the ROBOTIME Terminator M870 Wooden 3D Puzzle Gun:

• Jumlah modél: M870
• Bahan: High-quality Wood
• Jumlah Potongan: 172
• Assembled Dimensions (L x W x H): Kira-kira 42.93 cm x 5.99 cm x 9.19 cm (16.9 inci x 2.36 inci x 3.62 inci)
• beurat: Kira-kira 700 gram
• Umur Disarankeun: 14+ taun
• Nilai atikan: Enhances logical thinking and hand-eye coordination
• Waktu Majelis: Kurang leuwih 1.5 jam
• Firing Mechanism: Mechanical, single action
• amunisi: Rubber band bullets
• Kisaran anu épéktip: 3-5 méter

Gambar: Diménsi leuwihview of the assembled Terminator M870.

9. Garansi jeung Rojongan

ROBOTIME is committed to providing high-quality products. While specific warranty details may vary by retailer, we stand behind the craftsmanship of our models. If you encounter any issues with missing or defective parts, or require assistance with assembly, please contact ROBOTIME customer support through the retailer where you purchased the product or visit the official ROBOTIME websitus pikeun inpo kontak.

Please retain your proof of purchase for any support inquiries.
