APPASO AP-K149-BN Kitchen Faucet with Pull-Down Sprayer and Soap Dispenser User Manual

Bubuka

Thank you for choosing the APPASO AP-K149-BN Kitchen Faucet. This manual provides essential information for the safe and efficient installation, operation, and maintenance of your new kitchen faucet with a pull-down sprayer and integrated soap dispenser. Please read these instructions thoroughly before installation and keep them for future reference.

Image: APPASO AP-K149-BN Kitchen Faucet with Pull-Down Sprayer and Soap Dispenser in Brushed Nickel finish.

Émbaran Kasalametan

• Salawasna pareumkeun suplai cai utama sateuacan nyobian pamasangan atanapi pangropéa.
• Anggo alat pelindung pribadi anu pas, sapertos kacamata kaamanan sareng sarung tangan, salami instalasi.
• Pastikeun sadaya sambungan kedap pikeun nyegah bocor, tapi ulah overighten.
• Upami anjeun henteu yakin kana léngkah naon waé, konsultasi ka tukang ledeng anu mumpuni.

Komponén Kaasup

Your APPASO Kitchen Faucet package includes the following items:

• APPASO Kitchen Faucet
• Asesoris pamasangan
• Manual pamaké
• Beurat
• Lempeng Dek
• Dispenser sabun

Image: All components included in the APPASO Kitchen Faucet package, laid out for inspection.

spésifikasi

Image: Technical drawing showing the dimensions of the faucet and soap dispenser, including mounting hole size and countertop thickness requirements.

Setup sareng Instalasi

Follow these steps to install your APPASO Kitchen Faucet. For visual guidance, refer to the installation video below.

1. Nyiapkeun Area tilelep: Clear the area around the faucet hole(s) on your sink or countertop. Ensure the mounting hole size is 1-1/4" to 1-2/5" (3.2-3.5cm) and the maximum countertop thickness is 1-3/5" (4cm).
2. Pareuman suplai cai: Locate and turn off the hot and cold water supply valves under your sink. Open the existing faucet to relieve any pressure in the lines.
3. Remove Old Faucet: Disconnect the hot and cold water lines from the old faucet. Unscrew any mounting nuts or clamps holding the old faucet in place and remove it.
4. Pasang Pelat Dek (Opsional): If your sink has multiple holes and you prefer a single-hole installation, place the deck plate over the holes.
5. Pasang Keran: Insert the faucet body through the main hole in the sink or deck plate. From underneath the sink, secure the faucet using the provided mounting accessories (gasket, washer, and mounting nut). Tighten securely but do not overtighten.
6. Sambungkeun Jalur Cai: Connect the hot and cold water supply lines from the faucet to your home's hot and cold water supply valves. Use the included 1/2" adapter if necessary. Ensure all connections are hand-tight, then use a wrench for a final quarter-turn.
7. Beurat Pasang: Attach the weight to the pull-down hose beneath the sink. This ensures the sprayer head retracts smoothly.
8. Pasang Dispenser Sabun: Insert the soap dispenser into its designated hole (if applicable) and secure it from underneath the sink.
9. Uji pikeun Bocor: Slowly turn on the hot and cold water supply valves. Check all connections for leaks. Operate the faucet to ensure proper function.

Parentah Operasi

Your APPASO Kitchen Faucet is designed for ease of use and versatility.

• Operasi nanganan: The single handle controls both water temperature and flow. Move the handle left for hot water, right for cold water, and up/down to adjust flow intensity.
• Sprayer Tarik-Ka handap: Gently pull down the sprayer head from the spout. The flexible PEX hose extends up to 20 inches, providing ample reach for various tasks.
• 3-Setting Modes: The sprayer head features three distinct modes:
  ALIRAN: For filling pots and general use.
  nyemprot: For powerful cleaning and rinsing.
  REUREUH SAKEUDEUNG: Temporarily stops water flow to prevent splashing while moving the sprayer.
• Retraction Otomatis: Thanks to counterweight technology, the sprayer head automatically retracts smoothly back into the spout when released.
• 360° Putar: The faucet spout can swivel 360 degrees, making it suitable for both single and double bowl kitchen sinks.

Image: A hand demonstrating the three spray modes (Stream, Spray, Pause) of the pull-down kitchen faucet.

Image: A woman using the APPASO kitchen faucet to fill a glass of water, highlighting its ergonomic design.

Pangropéa

Proper care and maintenance will ensure the longevity and optimal performance of your APPASO Kitchen Faucet.

• beberesih: Clean the faucet regularly with a soft cloth and mild soap. Avoid abrasive cleaners, steel wool, or harsh chemicals, as these can damage the finish. The easy-clean rubber nozzles can be wiped to remove mineral buildup.
• Perhatosan Perawatan: The 7-layer nano and PVD coating technology provides an anti-fingerprint and easy-to-clean surface.
• Cartridge keramik: The high-quality ceramic cartridge is tested for 500,000 cycles, ensuring durability and drip-free performance for over 10 years.
• Inspeksi selang: Periodically check the PEX hose for any signs of wear or damage.

Image: Infographic detailing water-saving features, hot and cold water control, and surface upgrade technology for enhanced durability.

Image: Diagram illustrating the 7-layer Nano and PVD coating technology, highlighting lead-free, anti-fingerprint, and easy-to-clean properties.

Pamérésan masalah

If you encounter any issues with your APPASO Kitchen Faucet, refer to the common problems and solutions below.

• Tekanan Cai Lemah:
          Pariksa: Ensure water supply valves are fully open. Inspect the aerator for mineral buildup and clean if necessary.
• Bocor ti Spout:
          Pariksa: The ceramic cartridge may need inspection or replacement. Contact support if the issue persists.
• Sprayer Teu Retracting:
          Pariksa: Ensure the weight on the pull-down hose is positioned correctly and not obstructed.
• Difficulty Changing Spray Modes:
          Pariksa: Clean the spray head nozzles to remove any debris that might be hindering the button mechanism.

Garansi sareng Rojongan

APPASO provides a limited warranty for the AP-K149-BN Kitchen Faucet. For specific warranty details, please refer to the documentation included with your product or visit the official APPASO websitus.

We offer comprehensive support services, ongoing parts replacement, and dedicated technical support. If you have any questions, require assistance, or need to claim warranty service, please reach out to our customer support team.

Image: Certificate of Authenticity for APPASO products, ensuring quality and compliance.

Image: Display of certified core components, including the ceramic cartridge and hoses, emphasizing durability.
