Hikvision DS-2DE4A225IW-DE PTZ Camera User Manual

1. Bubuka

This manual provides essential information for the installation, operation, and maintenance of your Hikvision DS-2DE4A225IW-DE PTZ (Pan-Tilt-Zoom) camera. This 2MP camera features a 25x optical zoom and supports both 12V DC and Power over Ethernet (PoE) power options, making it suitable for various surveillance applications. Please read this manual thoroughly before using the product to ensure correct and safe operation.

2. Émbaran Kasalametan

• Sasayogian tanaga: Anggo ngan ukur adaptor kakuatan anu ditangtukeun. Mastikeun kakuatan voltage is stable and meets the camera's requirements (12V DC or PoE).
• Pamasangan: Installation must be performed by qualified personnel and comply with all local codes. Ensure the mounting surface can support the camera's weight.
• Lingkungan: Do not expose the camera to extreme temperatures, high humidity, dust, or corrosive environments. Avoid direct sunlight exposure for extended periods.
• beberesih: Use a soft, dry cloth for cleaning. Do not use strong detergents or abrasive materials.
• Pembongkaran: Entong nyobian ngabongkar atanapi ngarobih kaméra. Modifikasi anu teu sah bakal ngabatalkeun jaminan.

3. Eusi Paket

Verify that all items are present and in good condition upon unpacking. If any items are missing or damaged, contact your supplier immediately.

• Hikvision DS-2DE4A225IW-DE PTZ Camera
• Mounting Bracket (Wall/Ceiling)
• Power Adapter (if included with specific model variant)
• Pemasangan Screws sareng Jangkar
• Pakakas Konektor Tahan Cai
• Gancang Mimitian Guide
• Témplat Bor

4. Produk Langkungview

The Hikvision DS-2DE4A225IW-DE is a high-performance 2-megapixel PTZ dome camera designed for versatile surveillance. It features a powerful 25x optical zoom lens, allowing for detailed monitoring over large areas. The camera supports Pan, Tilt, and Zoom functions, enabling dynamic adjustment of the viewing angle and focus. Integrated infrared (IR) illumination provides clear images in low-light conditions.

Gambar 4.1: Hareupeun view of the Hikvision DS-2DE4A225IW-DE PTZ Camera, showing the dome housing and lens assembly.

5. Setélan

5.1 Masang kaméra

1. Pilih Lokasi: Select a suitable mounting location that provides the desired field of view and is structurally sound to support the camera.
2. liang bor: Use the provided drill template to mark and drill holes for the mounting bracket.
3. Bracket Aman: Attach the mounting bracket to the surface using the supplied screws and anchors.
4. Pasang kaméra: Secure the camera to the mounting bracket. Ensure all connections are made before final tightening.

5.2 Sambungan Daya

• Kakuatan DC 12V: Connect a 12V DC power adapter to the camera's power input port.
• PoE (Power over Ethernet): If using PoE, connect an Ethernet cable from a PoE-enabled switch or injector to the camera's network port. No separate power adapter is needed.

5.3 Sambungan Jaringan

Connect an Ethernet cable from your network router or switch to the camera's RJ45 network port. Ensure the network connection is stable for optimal performance.

6. Ngoperasikeun kaméra

6.1 Aksés Awal jeung Konfigurasi

1. Panggihan Alamat IP: Use the Hikvision SADP tool (available on the Hikvision websitus) pikeun mendakan alamat IP kaméra dina jaringan anjeun.
2. Aksés via Web Browser: Buka a web browser tur asupkeun alamat IP kaméra urang.
3. Lebet: Enter the default username (admin) and password (usually the verification code on the camera label or '12345'). You will be prompted to create a new strong password upon first login.
4. Setélan Dasar: Configure network settings, date/time, and video parameters as needed.

6.2 PTZ Functions

Ti live view panganteur di anjeun web browser or NVR/VMS software, you can control the camera's PTZ functions:

• Roti: Puterkeun kaméra sacara horisontal (kénca/katuhu).
• Dengdekkeun: Adjust the camera vertically (up/down).
• Zum: Adjust the optical zoom level (in/out) to magnify or widen the view.
• fokus: Automatically or manually adjust the focus for a clear image.
• Prasetél: Save specific PTZ positions for quick recall.
• Patrol/Pattern: Configure automated tours between preset points.

7. Pangropéa

7.1 beberesih

• Lensa: Gently wipe the lens with a soft, clean cloth. If necessary, use a small amount of lens cleaning fluid.
• Perumahan: Bersihkeun wadah kaméra ku sabun lemes,amp lawon. Hindarkeun bahan kimia anu kasar.

7.2 Apdet firmware

Pariksa sacara rutin ka petugas Hikvision website for the latest firmware updates. Firmware updates can improve performance, add new features, and address security vulnerabilities. Follow the instructions provided with the firmware package carefully to avoid damaging the device.

8. Cara ngungkulan

9. Spésifikasi

10. Garansi jeung Rojongan

Hikvision products typically come with a limited warranty. For specific warranty terms and conditions, please refer to the warranty card included with your product or visit the official Hikvision website. For technical support, product registration, or service inquiries, please contact Hikvision customer support through their official channels. Keep your purchase receipt for warranty claims.

Resmi Hikvision Websitus: www.hikvision.com
