Angrox Universal Remote Control User Manual

1. Produk Langkungview

The Angrox Universal Remote Control (Model: BN59-01199F) is designed to be a direct replacement and compatible solution for a wide range of Samsung LCD, LED, HDTV, and 3D Smart TVs. It offers a seamless user experience without the need for complex programming or setup, functioning immediately upon battery insertion.

Gambar 1: Hareup, sisi, jeung tukang views of the Angrox Universal Remote Control.

This remote is engineered for broad compatibility with numerous Samsung remote models, ensuring that it can replace your original remote if it is lost or damaged. Its compact size and ergonomic design make it comfortable to hold and easy to operate.

Figure 2: Compatibility chart showing the remote works with various Samsung TV types.

Compatible Samsung remote models include, but are not limited to: BN59-01175N, BN59-01199F, AA59-00741A, AA59-00786A, AA59-00602A, BN59-01247A, AA59-00743A, BN59-01175B, AA59-00818A, AA59-00603A, BN59-01199G, AA59-00622A, AA59-00496A, AA59-01180A, BN59-01268D, AA59-0066A, AA59-01289A, AA59-00600A.

2. Setélan

2.1 Pamasangan batré

Remot kontrol ieu peryogi dua (2) batré AAA (teu kalebet) pikeun dioperasikeun. Turutan léngkah-léngkah ieu pikeun masang batréna:

1. Remove the battery cover from the back of the remote control by sliding it downwards.
2. Insert two AAA batteries, ensuring the positive (+) and negative (-) terminals align correctly with the indicators inside the battery compartment.
3. Geser panutup batré deui kana tempatna nepi ka ngaklik aman.

Figure 3: Step-by-step guide for installing AAA batteries into the remote control.

2.2 Pamakéan awal

This universal remote control is designed for immediate use with compatible Samsung TVs. No programming or complex setup is required. Once batteries are installed, point the remote towards your TV and begin using it.

3. Parentah Operasi

3.1 Fungsi Tombol

Biasakeun diri anjeun sareng fungsi unggal tombol dina remot kontrol anjeun:

Figure 4: Detailed diagram of remote control buttons and their functions.

• Daya (Tombol Beureum): Hurungkeun TV sareng pareuman.
• Tombol Jumlah (0-9): For direct channel input or numerical selections.
• SUMBER: Displays and selects available video sources (e.g., HDMI, AV).
• TTX-MIX: Activates Teletext display, mixing teletext information with the normal broadcast.
• PRE-CH: Balik deui ka saméméhna viewsaluran ed.
• Volume (+/-): Saluyukeun tingkat polumeu.
• Channel (Up/Down Arrows): Robah saluran.
• Bisu: Motong kaluar sora samentara.
• DAFTAR CH: Displays the channel list on the screen.
• SMART HUB: Brings up Smart Hub applications for accessing streaming services and apps.
• MENU: Nampilkeun ménu utama dina layar.
• ALAT: Quickly selects frequently used functions or settings.
• pituduh: Accesses the electronic program guide (EPG).
• INFO: Displays information about the current program or TV screen.
• PULIH: Mulih ka ménu atawa layar saméméhna.
• KALUAR: Kaluar tina menu atawa aplikasi ayeuna.
• Color Buttons (A, B, C, D - Red, Green, Yellow, Blue): Shortcut keys for interactive functions, often context-sensitive.
• Olahraga: Directly accesses sports-related content or modes.
• E-MANUAL: Accesses the electronic manual (if supported by TV).
• AD/SUBT: Toggles audio description or subtitles.
• Pad Navigasi (Kaluhur, Turun, Kénca, Katuhu, OK): Navigates ngaliwatan ménu jeung confirms selections.
• Kontrol Puteran (Mundur, Puter / Reureuh, Maju Gancang, Eureun): Ngadalikeun putereun média.

3.2 Operasi Umum

The remote control features sensitive buttons and stable performance, ensuring a reliable connection with your TV. Its design allows for effective control from multiple angles and offers a farther transmitting distance.

Figure 5: The remote control offers sensitive buttons and stable performance for reliable use.

With its intuitive layout, you can easily find your favorite content faster, explore TV shows, movies, music, and more across multiple applications. The remote is designed for ease of use, making your TV viewing experience more convenient.

Figure 6: The remote's easy-to-use design allows quick access to content and apps.

4. Pangropéa

4.1 beberesih

Pikeun ngabersihan kadali jauh anjeun, usap gently eta ku lawon lemes, garing. Keur kokotor bandel, rada dampBilas lawon ku cai atanapi pembersih anu hampang sareng henteu abrasif. Hindarkeun nganggo bahan kimia anu keras atanapi bahan abrasif, sabab ieu tiasa ngaruksak permukaan remote atanapi komponén internal.

4.2 Ngagantian batré

Replace the AAA batteries when the remote's responsiveness decreases or it stops functioning. Always replace both batteries at the same time with new ones. Dispose of used batteries according to local regulations.

5. Cara ngungkulan

If you experience issues with your Angrox Universal Remote Control, refer to the following common problems and solutions:

• Jauh teu ngabales:
  • Pastikeun batré dipasang leres kalayan polaritas anu leres.
  • Ganti batré heubeul ku nu anyar.
  • Check for any obstructions between the remote and the TV's infrared receiver.
• Jarak transmisi pondok:
  • Pastikeun batréna seger.
  • Arahkeun remot langsung ka sénsor IR TV.
  • Minimize strong light sources (e.g., direct sunlight) that might interfere with the IR signal.
• Tombol husus teu jalan:
  • Clean the remote's surface and buttons to ensure no debris is preventing proper contact.
  • This remote is designed to cover all functions of the original remote. If a specific function is not working, ensure your TV model supports that function with a standard IR remote.

The remote features an upgraded chip for enhanced signal stabilization and durability, which helps prevent many common issues.

Figure 7: The remote's upgraded chip ensures fine workmanship, signal stabilization, and durability.

6. Spésifikasi

7. Garansi jeung Rojongan

7.1 Émbaran jaminan

This Angrox Universal Remote Control comes with a 60-day warranty from the date of purchase. This warranty covers manufacturing defects and ensures the product functions as described. Please retain your proof of purchase for warranty claims.

7.2 Rojongan Palanggan

For any questions, issues, or support needs regarding your remote control, please contact Angrox customer service. We are committed to providing excellent after-sales service and resolving any problems you may encounter.

Figure 8: Dedicated after-sales service is available for customer inquiries and support.

Please note that batteries and instructions are not included in the product packaging, as stated in the product description. This manual serves as your comprehensive guide.
