1. Bubuka
This manual provides essential information for the safe and efficient operation of your Anker SoundCore Sport XL Portable Bluetooth Speaker. Please read this guide thoroughly before using the product and retain it for future reference.
2. Naon dina Box
- Anker SoundCore Sport XL Speaker
- Kabel Micro USB
- Tali Leungeun
- Wilujeng sumping Guide
3. Fitur Produk
Gambar 1: Leuwihview of the Anker SoundCore Sport XL Portable Bluetooth Speaker.
3.1 Powerful Audio Output
Figure 2: Illustration of the speaker's internal components, showcasing dual 8-watt stereo speakers and dual subwoofers for powerful, dynamic sound.
The SoundCore Sport XL delivers powerful, dynamic sound through its dual 8-watt stereo speakers and dual subwoofers, providing a rich audio experience.
3.2 Ngalegaan Playtime
Figure 3: Graphic depicting the speaker's long-lasting battery, offering up to 15 hours of continuous audio playback.
Equipped with a high-capacity 5200 mAh battery, the speaker provides up to 15 hours of non-stop audio, ensuring your music lasts all day.
3.3 Tahan Cai sareng Kejutan
Figure 4: The speaker shown in a water environment, highlighting its IP67 waterproof rating.
The SoundCore Sport XL features an IP67 waterproof rating, making it suitable for use near water. Its robust design also provides shockproof protection against accidental drops.
Figure 5: The speaker is depicted in a scenario illustrating its shockproof capabilities, designed to withstand impacts.
3.4 Built-in USB Charging Port
Figure 6: The speaker is shown charging a mobile phone, demonstrating its built-in USB charging capability.
A convenient USB charging port allows you to charge your mobile devices directly from the speaker's internal battery, ideal for emergencies.
4. Setélan
Before first use, fully charge your SoundCore Sport XL speaker. Use the provided Micro USB cable to connect the speaker to a compatible USB power adapter (not included).
4.1 Ngecas Awal
Connect the Micro USB cable to the charging port on the side of the speaker. The LED indicator will show charging status. A full charge is recommended for optimal battery performance.
5. Parentah Operasi
5.1 Daya Hurung/Pareuman
- Pikeun ngahurungkeun: Pencét jeung tahan kenop Tombol daya (
) for 2 seconds. The LED indicator will light up. - Pikeun mareuman: Pencét jeung tahan tombol Tombol daya for 2 seconds. The LED indicator will turn off.
5.2 Volume Control
- Increase volume: Press the Tombol Volume Up ().
- Decrease volume: Press the Tombol Volume Turun ().
5.3 Playback Control
- Play / Reureuh: Pencét tombol Tombol Puter / Reureuh ().
- Lagu salajengna: Pencét dua kali dina Tombol Puter / Reureuh.
6. Papasangan Bluetooth
The SoundCore Sport XL uses Bluetooth 4.1 for a stable connection up to 66 feet (20 meters).
- Power on the speaker. The Bluetooth indicator will flash blue, indicating it's in pairing mode.
- Dina alat anjeun (smartphone, tablet, laptop), aktipkeun Bluetooth sareng milarian alat anu sayogi.
- Select "SoundCore Sport XL" from the list of devices.
- Sakali nyambung, indikator Bluetooth bakal robah jadi biru polos.
6.1 Official Product Video: Anker Soundcore Sport XL
video ieu nyadiakeun leuwih umumview of the Anker Soundcore Sport XL speaker, demonstrating its features and design.
6.2 Official Product Video: The Ready-for-anything Bluetooth Speaker - Anker SoundCore Sport XL
This video showcases the ruggedness and versatility of the Anker SoundCore Sport XL, highlighting its suitability for various environments.
7. Spésifikasi
| Fitur | Rincian |
|---|---|
| Nomer modél | A3181G11 |
| Diménsi (D x W x H) | 3.07" x 5.04" x 8.23" |
| Item Beurat | 1.32 pon (599 gram) |
| Speaker Maksimum Kaluaran Power | 16 Watt |
| Kapasitas batré | 5200 Miliamp Jam-jaman |
| Waktu maén | Nepi ka 15 jam |
| Téknologi Komunikasi Nirkabel | Bluetooth 4.1 |
| Rentang Bluetooth | Up to 66 feet (20.12 Meters) |
| Tingkat Résistansi Cai | IP67 (Tahan cai) |
| Fitur husus | Portable, Shockproof, Built-in Mic, USB Charging Port |
| Alat nu cocog | Smartphone, Tablet, Laptop |
| Bahan | Plastic (or similar synthetic material) |
8. Pangropéa
- beberesih: Ngagunakeun lemes, damp lawon pikeun ngabersihan spéker. Ulah make bahan kimia kasar atawa bahan abrasive.
- Panyimpenan: Simpen spéker dina tempat anu tiis sareng garing jauh tina sinar panonpoé langsung sareng suhu anu ekstrim.
- Tahan cai: Ensure the charging port cover is securely closed when using the speaker near water to maintain its IP67 rating.
9. Cara ngungkulan
| Masalah | Solusi |
|---|---|
| Speaker teu hurung | Pastikeun batréna tos dicas. Sambungkeun ka sumber daya nganggo kabel Micro USB. |
| Teu tiasa dipasangkeun sareng alat Bluetooth | Ensure the speaker is in pairing mode (flashing blue LED). Turn off and on Bluetooth on your device. Move the speaker closer to your device. |
| Teu aya sora atanapi volume handap | Adjust the volume on both the speaker and your connected device. Ensure the speaker is not muted. |
| Kualitas sora goréng | Move the speaker closer to your device to reduce interference. Ensure there are no obstructions between the speaker and the device. |
10. Garansi jeung Rojongan
The Anker SoundCore Sport XL typically comes with a limited warranty. Please refer to the included 'Welcome Guide' or visit the official Anker websitus wéb kanggo inpormasi garansi anu lengkep sareng kontak dukungan palanggan.
For technical assistance or product inquiries, please contact Anker customer support.
