Buku Panduan Pangguna Hauck Atlantic Twin Double Stroller

1. Bubuka

The Hauck Atlantic Twin Double Stroller is designed to provide comfortable and safe transportation for two children from birth up to approximately 3 years of age, with a maximum load capacity of 36 kg. This multifunctional stroller is suitable for both city environments and light terrain, such as gravel and pavement, ensuring a smooth ride for your little ones.

Key features include an adjustable handle, swivel and lockable front wheels, adjustable backrests and footrests, a large removable canopy with UV 50+ protection, a removable bumper bar, a secure 5-point harness system, suspension for comfort, spacious storage baskets, and a convenient cup holder.

The innovative design allows the carrycots, used for newborns, to easily convert into practical sports seats as your children grow. The carrycots come equipped with soft mattresses and covers, which can be combined to form cozy footmuffs for cooler weather. Each sports seat features a padded 5-point harness and a removable bumper bar for quick and easy entry and exit.

Figure 1.1: The Hauck Atlantic Twin double stroller in melange grey, showing both seats in a forward-facing configuration.

2. Émbaran Kasalametan

Always prioritize the safety of your children when using the Hauck Atlantic Twin Double Stroller. Adhere to the following safety guidelines:

• Never leave your children unattended in the stroller.
• Salawasna nganggo Sistim abah 5-titik to secure your children in the seats. Ensure it is properly adjusted and fastened.
• Ngalibetkeun rem parkir whenever the stroller is stationary, especially on inclines.
• Entong ngalangkungan éta maximum weight capacity of 36 kg (total for both children and contents in the basket).
• Ensure the stroller is fully unfolded and locked in position before placing children inside.
• Keep children's fingers and limbs clear of moving parts when folding or unfolding the stroller.
• Do not hang heavy bags on the handle, as this can cause the stroller to tip over.
• Regularly inspect the stroller for any signs of wear, damage, or loose parts. Discontinue use if any safety concerns are identified.
• The bumper bar is not a carrying handle. Do not lift the stroller by the bumper bar.

3. komponén Leuwihview

The Hauck Atlantic Twin Double Stroller consists of several key components:

• Pigura stroller: The main aluminum chassis providing structural support.
• Carrycots/Seats: Two convertible units that function as carrycots for newborns and transform into sports seats for older children.
• Roda: Four large, puncture-proof rubber wheels (two front swivel/lockable, two rear fixed with brake).
• Kanopi: Two large, removable canopies with UV 50+ protection.
• cecekelan: Height-adjustable handlebar for comfortable pushing.
• Sistim abah: Two padded 5-point harness systems for securing children.
• Bumper Bars: Two removable bumper bars for added security and child comfort.
• Karanjang Panyimpen: Two spacious under-seat storage baskets.
• Panyekel Piala: A detachable cup holder for beverages.
• Carrycot Inserts/Mattresses: Soft inserts and mattresses for the carrycot mode.
• Carrycot Covers/Footmuffs: Covers for the carrycots that can be converted into footmuffs.

4. Setup jeung Majelis

Follow these steps to assemble and set up your Hauck Atlantic Twin Double Stroller:

1. Ngabuka pigura: Release the folding lock (if engaged) and lift the handle until the frame clicks into its fully unfolded and locked position. Ensure all locking mechanisms are secure.
2. Ngalampirkeun Roda: Insert the front and rear wheels into their respective slots on the frame until they click securely into place. Pull on them to ensure they are firmly attached.
3. Attaching Carrycots/Seats: Align the connectors on the bottom of the carrycots/seats with the attachment points on the stroller frame. Press down firmly until they click into place. Ensure both units are securely fastened.
4. Installing Canopies: Attach the canopies to the designated points on the carrycots/seats.
5. Inserting Carrycot Liners: If using in carrycot mode, place the soft inserts and mattresses into the carrycots.
6. Attaching Bumper Bars: Clip the bumper bars onto the front of the seats. They are removable for easier access.
7. Attaching Cup Holder: Clip the cup holder onto the side of the handle.

Figure 4.1: The Hauck Atlantic Twin double stroller configured with two carrycots, suitable for newborns.

Figure 4.2: Illustration of the interchangeable seats, demonstrating the conversion process from carrycot to sports seat mode.

5. Parentah Operasi

5.1 Nyaluyukeun Gagangna

The handle height can be adjusted to suit parents of different heights. Locate the adjustment buttons on either side of the handle and press them simultaneously while moving the handle up or down to the desired position. Release the buttons to lock the handle in place.

5.2 Reclining the Seats

Each seat's backrest can be independently reclined. Locate the recline mechanism (usually a lever or button) on the back of the seat. Press or lift it and adjust the backrest to the desired angle. Ensure it locks securely into position. The seats can be reclined to a comfortable lying position for naps.

Figure 5.1: Demonstration of the seat recline adjustment feature, showing various possible positions for child comfort.

5.3 Ngagunakeun Harness 5 Titik

To secure your child, place them in the seat and bring the shoulder straps over their shoulders, the waist straps around their waist, and the crotch strap between their legs. Insert the buckles from the shoulder and waist straps into the central buckle until they click. Adjust the strap length for a snug, secure fit. To release, press the button on the central buckle.

5.4 Locking/Swiveling Front Wheels

The front wheels can be locked for stability on rough terrain or unlocked to swivel for easier maneuverability in tight spaces. Locate the locking mechanism above each front wheel and engage or disengage as needed.

Gambar 5.2: A close-up view of the sophisticated rubber wheels, highlighting their design and puncture-proof characteristics for a smooth ride.

5.5 Ngaaktipkeun Rem

The parking brake is located on the rear axle. Press down firmly on the brake pedal to engage the brake. Ensure the stroller does not move. To release, lift the brake pedal.

5.6 Tilepan kareta nu

To fold the stroller for transport or storage, ensure both seats are in their most upright position and the canopies are retracted. Locate the folding mechanisms (usually buttons or levers on the handle or frame) and activate them while pushing the handle forward and down. The stroller will collapse into a compact size (approximately 50 x 95 x 64 cm). Secure the folding lock if present.

Figure 5.3: Dimensions diagram for the Hauck Atlantic Twin double stroller, including its compact folded dimensions.

Figure 5.4: Composite image showcasing various functional features: the cup holder, the bumper bar release mechanism, the 5-point harness buckle, and the wheel lock mechanism.

6. Pangropéa sarta perawatan

Regular maintenance will extend the life of your stroller and ensure its safe operation:

• Bagian-bagian lawon anu dibersihkeun: The fabric components (seats, canopies, carrycot covers) can typically be spot cleaned with a mild soap and water solution. Refer to any specific care labels on the fabric for detailed washing instructions. Do not use harsh detergents or bleach.
• Cleaning Frame and Plastic Parts: Lap rangka aluminium sareng komponén plastik nganggo iklanamp lawon. Garing tuntas.
• Pangropéa roda: Periodically clean dirt and debris from the wheels and axles. Lubricate moving parts of the wheels and folding mechanisms with a silicone-based lubricant if they become stiff.
• Panyimpenan: Store the stroller in a dry, cool place away from direct sunlight and extreme temperatures to prevent material degradation.
• Pamariksaan: Regularly check all screws, rivets, and fasteners to ensure they are tight and secure. Inspect the harness, brakes, and locking mechanisms for proper function and wear.

angka 6.1: Tutup-up view of the carrycot interior with its soft insert and a separate footmuff, emphasizing the comfort and weather protection features.

7. Cara ngungkulan

If you encounter issues with your Hauck Atlantic Twin Double Stroller, refer to the following common problems and solutions:

• Stroller does not unfold/fold smoothly:
  Solusi: Check for any obstructions in the folding mechanism. Ensure all locks are disengaged before attempting to fold/unfold. Apply a silicone-based lubricant to the moving parts if they are stiff.
• Wheels are squeaky or difficult to turn:
  Solusi: Clean any dirt or debris from the wheel axles. Lubricate the axles with a silicone spray. Ensure the wheel locks are disengaged if you want them to swivel.
• Brake is not holding:
  Solusi: Check for any debris obstructing the brake mechanism. Ensure the brake pedal is fully engaged. If the issue persists, contact customer support.
• Harness buckles are stiff:
  Solusi: Clean any dirt or food residue from the buckles. Avoid using oil-based lubricants.
• Seat recline mechanism is stuck:
  Solusi: Ensure no fabric or debris is caught in the mechanism. Apply gentle pressure while operating the lever/button.

If the problem persists after attempting these solutions, please contact Hauck customer support for further assistance.

8. Spésifikasi

9. Émbaran jaminan

Warranty terms and conditions for the Hauck Atlantic Twin Double Stroller are typically provided with your purchase documentation. Please refer to the warranty card or leaflet included in the product packaging for specific details regarding coverage, duration, and claims procedures. For any warranty-related inquiries, it is recommended to contact Hauck customer service directly or the retailer from whom the product was purchased.

10. Rojongan Palanggan

For further assistance, technical support, or to inquire about spare parts, please visit the official Hauck websitus atanapi ngahubungi departemén layanan palangganna. Inpormasi kontak biasana tiasa dipendakan dina produsén websitus atanapi dina bungkusan produk.

Sumberdaya Online:

• Official Hauck Websitus: www.hauck.de/en/ (Punten Catet: URL nyaéta urutample and may vary by region.)
