Pyle PFA330BT Wireless Bluetooth Home Audio Amplifier.
Specifications.
- BRAND: Pyle
- CONNECTIVITY TECHNOLOGY: Bluetooth
- CONNECTOR TYPE: Rca
- POLAR PATTERN: Unidirectional
- MAX POWER OUTPUT: 90 Watt Output
- RMS POWER OUTPUT: 10 Watt x 2 @ 4 Ohm
- DIMENSIONS (L x W x H): 6.0” x 4.6” x 1.6” -inches
INTRODUCTION
The Pyle dual channel audio amplifier boosts your PA or entertainment system and provides low distortion audio reproduction. support for speakers with 4 to 8 Ohms You can listen to high-quality audio thanks to impedance. The compact integrated professional indoor stereo receiver has Bluetooth wireless music streaming capabilities. Works with the newest technology available today, including smartphones, tablets, laptops, and computers, and features simple receiver pairing.
It has a Bluetooth connection and an aux/MP3 switch button that lets you choose which input you’ll be using. To use Bluetooth-enabled devices, fully depress the button; to utilize aux/MP3 devices, fully release the button. Expert class-T amplifiers support different output and external devices.
The amplifier uses a Class- T audio amplifier IC for low distortion and acoustically accurate reproduction of music. And Bluetooth wireless music streaming ability makes it work with virtually any Bluetooth-compatible devices like iPhone, Android, Smartphones, Tablet, MP3 players, TV, PC, etc. Over-voltage protection circuit shuts down the amplifier if the input voltage exceeds 14. 4V DC.
Features:
- Compact and Powerful Mini Amp System
- Built-in Bluetooth for Wireless Audio Streaming
- Compatible with All Your Favorite Bluetooth Devices
- (Works with iPhone, Android, Smartphone, iPad, Tablet, PC, etc.)
- 1/4” Microphone Input Connector Jack
- Aux (3.5mm) iPod/MP3 Input Connector Jack
- RCA (L/R)Audio Input Connector Jacks
- Four Push Type Speaker Terminals
- Rotary Treble, Bass, Master Volume Adjustable Controls
- Short Cut, Overload & Overheat Protection
- Source Input Selection
- Includes Power Adapter
Bluetooth Connectivity:
- Instant Bluetooth Wireless Streaming Ability
- Works with All of Your Favorite Devices
- (iPhone, Android, Smartphone, iPad, Tablet, MP3 Player, etc.)
- Bluetooth Version: 4.0
- Bluetooth Wireless Range: 30’+ Feet
BLUETOOTH OPERATION INSTRUCTION
External devices which have a built-in Bluetooth feature can be connected to this amplifier wirelessly to play through the amplifier’s speakers. If your amp is connected to speakers, you will hear
audible tones which will help for connecting.
1. At first be sure that the amplifier is powered on and turn the volume to low. Please remember to connect the Bluetooth Antenna at the back panel for a better receiving signal.
2. Press the BT/Line button switch on the front panel, you will hear the voice “POWER ON” and also “PAIRING”, and then the unit is automatically ready to pair with your external device.
3. Turn on the Bluetooth of your external device.
4. Search for available Bluetooth devices and make sure to be within range of your amp, and wait for your device to select “BT-RY” on the pairing devices lists of Bluetooth networks.
5. Once connecting you will hear a voice say, “Your Device is Connected”, then the Bluetooth pairing is successful and you have established a Bluetooth connection.
6. You can now play music on your external device through the amplifier.
PRODUCT DIMENSION
1. POWER On /Off
2. BLUETOOTH Indicator
3. Master Volume Control
4/5.Bass And Treble Tone Control
6. Bluetooth/ AUX-MP3 Input Button Switch
7. Line AUX/MP3 Input
8. Aux RCA Stereo Input
9. 1/4″ MIC Input Jack
10. Push Type Speaker L/ R Terminals
11.DC12V Input
12. Bluetooth Antenna
This multipurpose digital Hi-Fi audio amplifier packs a punch. It can be used in your car or home and don’t be fooled by the size, it’ll give your entertainment system a serious boost. The state-of-the-art
the design uses surface mount components and advanced engineering for proven performance, reduced signal interference, and long operational life. This unit will ensure low distortion and acoustically accurate reproduction of audio. The PFA330BT, 90- watt class-T circuit-designed amp will turn it up to the next level.
- Plug it In
Connect your iPod/MP3 player to the 3.5mm input jack! This unit also has a microphone and audio input jacks. (iPod & MIC not included) - Party Machine
Create a Karaoke session and let the fun begin. Use the MIC and aux inputs to add life to the party. You will be in control of the music and then you can configure the audio just the way you want it to sound.
