T5C LED TROFFER

INSTALLATION INSTRUCTIONS
The installation must only be performed by a licensed electrician.
To prevent death, injury or damage to property, this product must be installed in accordance with National Electrical Code (NFPA70) in the US or the Canadian Electrical Code (CSA 22.1) in Canada.
Disconnect power before installing the product or servicing it.
Wait until the fixture has cooled down before installing or servicing the fixture.
MIN. 90°C SUPPLY CONDUCTORS

What’s In The Box

Tools Needed

This LED Troffer requires very few tools for installation. A drill or a screwdriver and a pair of wirecutter.

1. Carefully unpack the fixture from its packaging. Inspect product for defects due to shipping.

2. Locate the desired position for the fixture in the ceiling grid. Remove ceiling tiles if necessary.

3. Turn off power to the appropriate circuit at the breaker panel.

4. Place the fixture into the T-grid ceiling panel. Secure to structure and/or grid per state and local codes.

5. Remove the access plate from the junction box (do not discard it) by removing the screws.
   Another end is for low voltage connection.

6. Connect wiring as shown. Grey and purple wiring are for 0-10V dimming systems. Cap off if not used.

7. Reattach the cover of the junction box and secure it with (2) two screws.
8. Turn the power on and verify that the panel is lit.
