MGC DSPL-2440DS Graphical Main Display Module
Description
The DSPL-2440DS Graphical Main Display Module provides the FleX-Net Series with a 24-line x 40-character backlit LCD display, common controls buttons and four status queues with selector switches and LEDs for Alarm, Supervisory, Trouble and Monitor. The DSPL-2440DS occupies one display position in the inner door of the FleX-Net Series.
The DSPL-2440DS may be used for service; this display will show all messages.
Features
- For service, display shows all messages
- Backlit display
- User-friendly Menu
- Common Control buttons with selector switches and LEDs
- Four Status Queues: Alarm, Supervisory, Trouble and Monitor
- Mounted in backboxes, UB-1024DS, BBX-1024XT(B)R BBX-1072ADS(ARDS), BB5008, BB-5014 and the BBXFXMNS(R) Backbox
| Voltage | 24 VDC |
Current Consumption
| Stand by | 29 mA |
| Alarm | 75 mA |
Ordering Information
| Mode | Description |
| DSPL-2440DS | FLEX-NET 24-Line x 40-Character Graphical Main Display Module |
Canada
25 Interchange Way Vaughan, ON L4K 5W3
Telephone: 905-660-4655 | Fax: 905-660-4113
U.S.A.
4575 Witmer Industrial Estates Niagara Falls, NY 14305 Toll Free: 888-660-4655 | Fax Toll Free: 888-660-4113 www.mircom.com
THIS INFORMATION IS FOR MARKETING PURPOSES ONLY AND
NOT INTENDED TO DESCRIBE THE PRODUCTS TECHNICALLY.
For complete and accurate technical information relating to performance, installation, testing and certification, refer to technical literature. This document contains intellectual property of Morcom. The information is subject to change by Morcom without notice. Morcom does not represent or warrant correctness or completeness
