TECWARE VX90M MATX Dual Tempered Glass PC Case
Quick Start Guide
Introduction
This guide provides instructions for installing components into the TECWARE VX90M MATX Dual Tempered Glass PC Case.
Specifications
| Type | Specification |
|---|---|
| Motherboard Support | mATX, ITX |
| Dimensions | 440(L) x 220(W) x 455(H) mm |
| 3.5" HDD Drive Bay | 1 |
| 2.5" SSD Drive Bay | 2 |
| Expansion Slots | 5 |
| Maximum GPU Length | 400mm |
| Maximum CPU Cooler Height | 165mm |
| Maximum PSU Length | 280mm |
Panel Removal
Follow these steps to remove the side and front tempered glass panels:
Pull the tab with controlled force, and the side tempered glass panel should pop out as shown.
[Diagram: Side view of PC case with an arrow indicating pulling a tab to release the side panel.]Push the top of the front tempered glass panel from the inside of the casing with controlled force, and it should pop out as shown.
[Diagram: Front view of PC case with an arrow indicating pushing the top edge of the front panel inwards to release it.]
Front Panel I/O Connections
Connect the front panel cables to the appropriate headers on your motherboard.
Buttons and Activity Lights
These cables connect to the motherboard for the power button (power sw), reset button, HDD LED, and power LED (P+/P-).
[Diagram: A block of small connectors labeled H.D.D LED, PLED, POWER SW, RESET SW.]HD Audio
This connector attaches to your sound card or motherboard and is used to provide the front panel mic input and headphone output.
[Diagram: A block connector labeled HD AUDIO with pins.]USB 3.0 Connector
This cable connects to the USB 3.0 header on the motherboard to enable the front USB 3.0 ports.
[Diagram: A blue USB 3.0 header connector.]Component List
The following accessories are included with the TECWARE VX90M case:
| Visual Description | Item | QTY | Application |
|---|---|---|---|
| [Image: Screw with a wide, flat head and a cross slot.] | Motherboard & SSD screw | 16 | Motherboard and 2.5 hard drive installation |
| [Image: Screw with a slightly smaller head than Type A, designed for drives.] | HDD mount screw | 4 | 3.5 hard drive installation |
| [Image: A longer screw with a hexagonal head, suitable for PSU and expansion slots.] | PSU & Rear expansion slot screw | 4 | Power supply installation, Mounting of GPU and other expansion cards |
| [Image: Two interlocking plastic or metal pieces, one shaped like a U.] | Snap Buckle | 2 | TG tablock replacement |
| [Image: A small metal cylinder with a threaded end, used to raise the motherboard.] | Standoff Adaptor | 1 | Installing motherboard standoff |
| [Image: A thin, flexible plastic strip with a locking mechanism.] | Cable tie (100mm) | 8 | Cable management |
| [Image: A thin, flexible plastic strip with a locking mechanism, longer than the 100mm version.] | Cable tie (150mm) | 8 | Cable management |
| [Image: A small black box with a red speaker symbol, attached to a wire with a connector.] | Mini Buzzer | 1 | PC Computer Motherboard Case Internal Speaker Connector |
Motherboard Installation
Install the motherboard onto the standoffs inside the case. Use Screw Type A.
[Diagram: Interior of the PC case showing the motherboard mounting area highlighted. A screw labeled 'Screw Type A' is shown.]SSD / HDD Installation
Install 2.5" SSDs or 3.5" HDDs into the designated drive bays.
SSD Drive Installation
Install 2.5" SSDs using Screw Type A.
[Diagram: Interior of the PC case showing locations for two 2.5" SSDs. A screw labeled 'Screw (Type A)' is shown.]HDD Drive Installation
Install 3.5" HDDs using Screw Type B.
[Diagram: Interior of the PC case showing locations for 3.5" HDDs. A screw labeled 'Screw (Type B)' is shown.]GPU & PSU Installation
Install the Graphics Processing Unit (GPU) and Power Supply Unit (PSU).
Graphics Processing Unit (GPU) and other expansion cards
Install expansion cards into the available slots. The maximum GPU length supported is 400mm.
[Diagram: Interior of the PC case showing expansion slots and a highlighted area indicating the maximum GPU length of 400mm.]Power Supply Unit (PSU) Installation
Install the PSU into its designated bay. The maximum PSU length supported is 280mm.
[Diagram: Interior of the PC case showing the PSU mounting area. A highlighted area indicates the maximum PSU length of 280mm.]Use Screw Type C for PSU and Rear expansion slot installation.
[Diagram: A screw labeled 'Screw (Type C)' is shown.]CPU Cooler / Fan Installation
Install CPU coolers and case fans according to the following specifications:
- Rear: Supports 1x 120mm Fan.
- Top: Supports 3x 120mm or 2x 140mm Fans. Supports radiators up to 240/280/360mm.
- Motherboard Side: Supports 3x 120mm Fans.
- Bottom: Supports 120mm Fan.
- CPU Cooler Height: Maximum height supported is 165mm.
Package Contents & Warranty
Package Contents
- 1 x TECWARE VX90M Case
- 1 x Bag of Accessories
Warranty
1 Year. Please contact your local distributor for support.
