Whirlpool Tumble Dryer Quick Guide
Thank you for purchasing a Whirlpool product. For more complete assistance, please register your product on www.whirlpool.eu/register.
Before using the appliance, carefully read the Safety Instructions.
Please scan the QR code on your appliance for more information.
Control Panel
The control panel features the following:
- 1 ON/OFF button: Hold for Reset ⏻ (hold for ?)
- 2 Programme selection Knob
- 3 Start/Pause button: ▶️ / ⏸️
- Options buttons*
- 4 Dryness level: ?
- 5 Start delay: ⏳
- 6 Timed drying: ⏱️
- 7 Cycle end: ✅
- 8 Rapid: Hold for Key lock ⚡ (hold for ?)
- 9 FreshCare+: Hold for Mute ?️ (hold for ?)
*Note: some models may have the wording in full instead of the icons.
Indicators
Dryness level indicators: Iron dry, Hanger dry, Cupboard dry, Extra dry.
Cycle phase indicators: Drying, Cool down, End of cycle.
Alert indicators:
- Empty water tank ?
- Clean door filter ?
- Clean bottom filter ?
- Failure: Call after sales service ? (Refer to troubleshooting section)
First Time Use
Ensure the water tank is correctly inserted. Make sure the drain hose on the back of the dryer is fixed correctly, either to the dryer's water tank or to your domestic drainage system. The dryer must be installed in a room with a temperature ranging between 5°C and 35°C for proper operation. Before using your dryer, ensure it has been in an upright position for at least 6 hours.
Opening the door during the cycle
The tumble dryer door can be opened at any time during the cycle to check progress and remove already dry garments. However, opening the door can extend the drying time. It is recommended to keep the door closed throughout the cycle to save time and energy. After closing the door, press the "Start/Pause" button within 15 minutes to resume machine operation.
Daily Use
To keep your machine working at its best:
- Empty your water tank after each drying cycle.
- Clean your filters after each drying cycle. Refer to the Care & Maintenance section.
- Plug the dryer into the power supply socket.
- Open the door and load garments; always refer to clothing labels and max loads indicated in the programme section. Empty pockets. Ensure garments do not get caught between the door and/or the door filter. Do not load items that are dripping wet. Do not tumble dry large, very bulky items. For optimal drying, load garments one by one.
- Close the door.
- Press the "On/Off" button ⏻.
- Select the most suitable programme for the fabric type.
- Select options, if necessary.
- Press the "Start/Pause" button ▶️ / ⏸️ to begin drying.
- At the end of the cycle, a buzzer will sound, and an indicator will signal the end. Turn the machine off by pressing the "On/Off" button ⏻, open the door, and remove clothing immediately to prevent creases. If not switched off manually, the appliance turns off automatically after about 15 minutes to save energy. Note that some models perform a final cool tumble phase, so fabrics may not feel hot.
In case of power failure, press the "Start/Pause" button ▶️ / ⏸️ to restart the cycle.
Care Label Symbols
Always check care labels, especially when placing garments in the tumble dryer for the first time. The most commonly used symbols are:
- ? May be tumble dried.
- ?? Do not tumble dry.
- ? Tumble dry – high heat.
- ?️ Tumble dry – low heat.
Programs
The duration of these programs depends on load size, textile types, washer spin speed, and selected options. On models with a display, duration is shown on the control panel and remaining time is adjusted during the cycle.
Option to use: If loads are consistently less dry or more dry than desired on Automatic Cycles, you can adjust the dryness level using the specific option.
Eco
Max Load: 8 Kg*
Most efficient programme in terms of energy consumption, suitable for drying normal wet cotton laundry. The values on the Energy Label are based on this programme. For optimal energy efficiency, this cycle defaults to "Cupboard Dry". For a higher dryness level, use the Cotton cycle.
Cotton
Max Load: 8 Kg*
Suitable for drying all types of cotton, ready to be placed in the cupboard.
Mixed
Max Load: 4 Kg
Ideal for drying cotton and synthetic fabrics together.
Bed linen
Max Load: 8 Kg*
Intended for drying cotton sheets.
Duvet
Max Load: 8 Kg*
Programme for drying bulky items, such as a single duvet.
Shirts
Max Load: 3 Kg
For Shirts made from cotton or cotton blend/synthetics.
Jeans
Max Load: 3 Kg
For drying sturdy cotton including denim trousers and jackets.
Easy ironing
Max Load: 8 Kg*
Relaxes fibres, making ironing and folding easier. Suitable for small loads of damp or dry cotton and cotton blend fabrics. Not for wet items.
Refresh
Max Load: Any load size (more effective with small loads)
A short programme suitable for refreshing fibres and garments through fresh air emission. Lasts about 20 minutes. Do not use on wet items.
Rapid 30'
Max Load: 0.5 Kg
Ideal for drying cotton garments spun at high speed.
Sport
Max Load: 4 Kg
For drying synthetics or cotton sports garments.
Silk
Max Load: 0.5 Kg
Gentle drying of silk garments.
Wool
Max Load: 1 Kg
Programme for drying wool clothes. Turn items inside out before drying. If heavy edges remain damp, leave them to dry naturally.
Delicates
Max Load: 2 Kg
For drying delicate laundry requiring gentle treatment.
Synthetics
Max Load: 4 Kg
For drying synthetic fabrics.
*MAX LOAD 8 Kg (Dry load)
Options
These buttons allow you to personalize the selected programme. Not all options are available for all programmes. Some options may be incompatible; you will be alerted by the buzzer and/or blinking indicators. If an option is available, its indicator will stay on.
- Dryness level: Press several times to obtain different residual moisture levels (Iron dry, Hanger dry, Cupboard dry, Extra dry).
- Timed drying: Manually set the drying time.
- Start delay: Delay the start of the cycle.
- Rapid: Enables quicker drying.
- FreshCare+: Prevents bacterial proliferation and creasing by controlling temperature and gently rotating the drum for up to 6 hours after the cycle ends.
- Key lock: Makes all machine controls inaccessible, except the "On/Off" button.
- Cycle end: Activates a prolonged buzzer at the end of the cycle.
- Mute: Turns off all control panel sounds. Only warnings remain active.
Cleaning and Maintenance
WARNING: Unplug the dryer during cleaning and maintenance procedures.
Emptying the water tank (see Figure A illustration): Pull the container out, empty it into a sink or drain, then place it back properly. Do not use the dryer without the container inserted.
Cleaning the filters: Remove filters and clean lint with your hand, a cloth, or a vacuum cleaner. Throw lint in the garbage bin, not down the drain, to avoid spreading microplastics. Do not use the dryer without filters reinserted.
Cleaning the door filter (see Figure B illustration): Open the door and pull the filter upwards. Open the filter and remove lint from all parts. Replace correctly, ensuring it is fully seated.
Cleaning the bottom filter (see Figure C illustration): Clean when the relevant indicator turns on; recommended after each cycle for optimal performance. Open the bottom cover, pull the filter out. Open the rear side of the filter and remove lint from the mesh. Check the chamber monthly. If lint accumulates on metal fins, clean with a vacuum cleaner nozzle with a brush, using vertical movements to avoid damage. Avoid direct hand contact with fins (risk of cuts). Close the rear side, place filter back, lower handle. Close bottom cover. Ensure air intake is free.
Filters are essential for collecting lint. Clogged filters affect airflow, increasing drying times, energy consumption, and potentially damaging the dryer. If filters are not cleaned properly, the dryer may not start.
Note: After cleaning filters, the indicator may remain on; it will disappear when a new drying cycle starts.
Cleaning the tumble dryer exterior: Use a damp cloth for metal, plastic, and rubber parts. Clean the front air intake grille regularly (every 6 months) with a vacuum cleaner to remove lint and dust. Use a vacuum cleaner for filter areas periodically. Do not use solvents or abrasives.
Transport and Handling
Never lift the dryer by holding it at the worktop.
- Unplug the dryer.
- Remove all water from the water tank.
- Ensure the door and water tank are properly closed.
- If the drain hose is connected to your drainage system, re-connect it to the back of the dryer (refer to Installation section in Safety Instruction guide).
Power Consumption
| Mode | Watts |
|---|---|
| Off-mode (Po) | 0.42 |
| Left-on mode (Pl) | 2.00 |
| Programs | Kg | kWh | Minutes |
|---|---|---|---|
| Eco* | 8 | 1.95 | 194 |
| Eco | 4 | 1.06 | 135 |
| Synthetics | 4 | 0.73 | 95 |
*Reference programme for the energy label, suitable for drying normal wet cotton laundry and most energy-efficient for drying wet cotton laundry (Standard/Default starting configuration).
Product Description
The product features the following components:
- 1. Water Tank
- 2. Air Intake grille
- 3. Bottom filter
- 4. Door filter
(Diagrams illustrating these components are present in the original document).
Troubleshooting
Before contacting After-sales Service, refer to the table below. Many malfunctions are minor and can be solved quickly.
| Malfunction | Possible Cause | Solution |
|---|---|---|
| The drying times are very long. | Inadequate maintenance was carried out. | Refer to the Cleaning & Maintenance section and perform the described operations. |
| The garments are too wet. | Carry out a washing cycle with a higher spin speed to remove as much water as possible. | |
| Room temperature outside the 14°C - 30°C range. | Drying time may be longer. | |
| Programme, time, and/or drying level set are not suitable for the type and amount of load. | Refer to Programmes and Options sections to find the most suitable settings. | |
| The dryer may be overloaded. | Refer to the Programmes section to check the max load for each programme. | |
| The tumble dryer does not turn on. | The "On/Off" button was not pressed. | Press the "On/Off" button ⏻. |
| The plug is not inserted into the socket. | Insert the plug into the socket. | |
| The socket is faulty. | Try plugging another appliance into the same socket. Do not use connecting electrical devices like adapters or extensions. | |
| A power failure occurred. | Wait for power restoration and switch the fuse on again if necessary. | |
| The tumble dryer does not start. | The door has not been closed properly. | Close the door. |
| A time delay was set for the start of the cycle. | Wait for the set delay to end, or switch the machine off to reset it. Refer to the Options section. | |
| The "Start/Pause" button was not pressed. | Press the "Start/Pause" button ▶️ / ⏸️. | |
| The Key Lock function was enabled. | Disable Key Lock. Switching the machine off does not disable this option. Refer to the Options section. | |
| Garments are wet at cycle completion. | Small load. | The automatic programme may not have sensed the required final moisture. Select an additional short drying period or the "Extra Dry" option if available. |
| Large loads or heavier fabrics. | Dryness levels can be modified. "Extra Dry" is recommended for ready-to-wear items. | |
| The drying cycle was paused and not reactivated within 15 minutes. | The drying cycle must be set up once more and restarted. | |
| A power failure might have occurred. | The drying cycle must be set up once more and restarted. | |
| Lights on or flashing | Water tank ? | The water tank is full. Empty the water tank. Refer to Cleaning & Maintenance. |
| Door filter ? | Failure of air flow. Clean the door filter and check air intake is free. Improper cleaning may cause damage. Refer to Cleaning & Maintenance. | |
| Bottom filter ?* | The bottom filter requires cleaning. Clean the bottom filter. Refer to Cleaning & Maintenance. | |
| The presence of a wrench symbol ? signals a malfunction. | The machine sensors detected a failure. | Switch the dryer off and unplug it. Open the door immediately and pull laundry out to allow heat to dissipate. Wait for about 15 minutes. Reconnect the dryer, load laundry, and restart the cycle. If the problem persists, contact the After-Sales Service and communicate the letters and digits flashing on the display (e.g., F3 and E2). |
*Note: some models are auto-cleaning and not equipped with a bottom filter. Refer to the Cleaning & Maintenance section.
Support and Further Information
Policies, standard documentation, ordering spare parts, and additional product information can be found by:
- Using the QR code on your appliance.
- Visiting our websites: docs.whirlpool.eu/docs and parts-selfservice.europeanappliances.com.
- Alternatively, contact our After-sales Service (see phone number in the warranty booklet). When contacting After-sales Service, please state the codes provided on your product's identification plate.
