Freestanding Dishwasher, Sanitise

Fisher & Paykel DW60FC4X2 | Series 7 Contemporary | Stainless Steel

Product Overview

Offering superior wash performance and advanced drying, this dishwasher features adjustable storage for easy loading. It includes seven wash programs from Heavy to Light, such as Auto, 60min, and Eco. Additional modifiers like Dry+, Sanitise, Half Load, and Intensive provide extra wash options. The unit is designed for flexible freestanding installation anywhere in your kitchen and is Wi-Fi enabled, working with the SmartHQ™ app for remote control and notifications.

A front view of the Fisher & Paykel Freestanding Dishwasher, featuring a sleek stainless steel finish and a front-of-door control panel.

Dimensions

Diagram illustrating dishwasher dimensions: 'H' for Height (848-893mm), 'W' for Width (597mm), and 'D' for Depth (600mm).

DimensionMeasurement
Height848 - 893mm
Width597mm
Depth600mm

Features & Benefits

Considered Design

Designed to complement Fisher & Paykel's Contemporary style family of products, this freestanding dishwasher boasts a sleek stainless steel finish with an intuitive front-of-door control panel.

Advanced Drying

Achieve beautifully dry dishes every time with an advanced drying system. This system combines fan-assisted drying with automatic door opening at the end of the cycle. By opening to release excess steam, Auto Door Open Dry ensures dishes come out dry and ready for use or storage.

A Reliable Clean

This dishwasher offers seven wash programs, including an Auto program that automatically senses the optimal wash settings for your dishes. A three-stage filtration system delivers a superior clean, and the rinse aid indicator reminds you to top up for consistently clean dishes.

Customise Your Wash

Create the perfect wash with a range of modifiers. Options include Intensive for a thorough clean, Half Load for partial loads, Sanitise for extra protection (killing 99.9% of bacteria* in the final rinse), and Dry+ for plastic dishes. (*Certified to NSF/ANSI Standard 184)

Quiet Performer

Operating at a very low decibel rating, this dishwasher performs its tasks quietly. The combination of clever technology and simple mechanics ensures greater reliability and superior wash performance with minimal noise.

Efficient Performance

With a 4.5 star energy rating and a 5.5 star water rating, this dishwasher delivers a powerful wash. Use the Eco wash program for optimal water and energy consumption, or choose when the cycle begins with the Delay Start option.

Flexible Loading

Designed to accommodate 15 place settings, this spacious model allows for easy stacking of large items. Adjustable rack options provide flexibility for any load, featuring a full-width cutlery tray, a height-adjustable middle rack, cup holders, and wine glass supports.

Specifications

CategoryDetailSpecification
Capacity and loadingPlace settings15
Accommodates round plates320mm
Adjustable height, foldable200mm (with cutlery tray)
Motor typeBLDC
FiltrationThree-stage filtration system
PerformanceNoise emissions42dBA
Power requirementsAmperage10A
Supply frequency50Hz
Supply voltage230V
Product dimensionsDepth600mm
Height848 - 893mm
Width597mm
WarrantyParts and labour2 years
Wash Program ModifiersDry +✔️
Half-load✔️
Intensive✔️
Sanitise✔️
Wash modifiers4
Wash Programs60 min✔️
Auto✔️
Eco✔️
Water connectionWater pressureMin 150 kPa (22 psi) Max 827 kPa
Water supply3/4 BSP (20mm) connector
SKU82432

Consumption

CategoryRating
Energy rating4.5 star
Water rating5.5 star (WELS)

Controls

  • Child lock ✔️
  • Energy saving delay start ✔️
  • Internal light ✔️
  • Intuitive capacitive touch ✔️
  • Rinse aid indicator light ✔️
  • Time remaining LED display ✔️
  • Wi-Fi connectivity ✔️

Additional Features

  • Easy lift adjustable upper ✔️
  • Fold down tines ✔️
  • Full width cutlery/utensil tray ✔️
  • Large crockery insert in lower ✔️
  • Telescopic slides ✔️
  • Wine glass supports ✔️
  • Air curtain for bench ✔️
  • Aquastop ✔️
  • Auto Door Open Dry ✔️
  • Fan assisted drying ✔️
  • Flood protection ✔️
  • Fully independent spray arms ✔️
  • Half load option ✔️
  • Internal tub material: Stainless Steel

Support & Downloads

For more information, service, or warranty details, please visit the Fisher & Paykel website.

Customer Support: 24 Hours 7 Days a Week

Phone: 1300 650 590

Website: www.fisherpaykel.com

Other product downloads available at fisherpaykel.com:

Please note: The product dimensions and specifications provided are for this specific product and model. Under Fisher & Paykel's policy of continuous improvement, these details may change at any time. It is recommended to confirm current specifications with Fisher & Paykel's Customer Care Centre. © Fisher & Paykel Appliances Ltd 2020.

Models: DW60FC4X2, Freestanding Dishwasher, DW60FC4X2 Freestanding Dishwasher, DW60FC4X2 Dishwasher, Dishwasher

File Info : application/pdf, 3 Pages, 300.31KB

PDF preview unavailable. Download the PDF instead.

QRG AU 82432

References

iText 7.1.12 ©2000-2020 iText Group NV (AGPL-version)

Related Documents

Preview Fisher & Paykel Series 7 Contemporary Dishwasher DW60FC4X2 Quick Reference Guide
