PAL PCR-1Z Lighting Controller Instructions

DIMENSIONS

Diagrams show the dimensions and knockout locations for the PCR-1Z lighting controller enclosure.

• Two 13/16" / 21.0mm knockouts are fitted on both sides of the enclosure for cable entry.
• Three conduit holes are present on the bottom of the enclosure.

Knockout Instructions: It is recommended to fit the cover and ensure screws are tight before removing knockouts. To remove knockouts, use a flat blade screwdriver (3/16" / 4mm blade) and a light hammer tap on the screwdriver handle. Alternatively, drill location points are provided in the center of each knockout for using a hole saw.

INSTALLATION & MAINTENANCE INSTRUCTIONS

PCR-1Z Class 2 Outdoor Driver/Receiver for 12V D/C PAL 4 Wire LED Lights

FEATURES

• Easy to Install
• UL Listed Class 2 Power Supply / Swimming Pool and Spa Transformer (WDGV)
• Remote Control Operation from PCZ-2 hand-held remote
• Optional Wi-Fi Control from Apple iOS Devices
• IP65 Wet Location Construction
• Constant 24V DC Output Voltage

IMPORTANT INFORMATION

The PCR-1Z is specifically designed to supply 24V DC to power PAL 4 Wire UL Listed LED Pool lights. Installation must comply with the National Electrical Code (NEC) and be performed by a Certified Electrician or Qualified Pool Technician.

NOTE: No bonding is required from this Class 2 power supply to the UL Listed PAL Pool Light fixtures due to their all-plastic construction, complying with NEC article 680 requirements.

INSTALLATION INSTRUCTIONS FOR PCR-1Z RGB OUTDOOR DRIVER

1. Mounting: Mount the weatherproof (IP65) PCR-1Z Class 2 Power Supply on a flat surface using the provided mounting legs and appropriate fixtures. Position it suitably for the PAL 4 Wire LED Pool Lights and ensure compliance with NEC and local codes.
• NOTE: The Driver Enclosure must be at least 5 feet horizontally from the pool's inside wall and at least 1 foot above the maximum pool water level.
• NOTE: For mounting on concrete or block walls, mark hole locations, drill 3/16" holes using a masonry drill, insert supplied Star Plugs, and secure with stainless steel screws.
2. Power Supply Connection: Use the conduit entry on the bottom right side of the PCR-1Z to connect the 100-120V power supply, adhering to NEC code requirements.
3. LED Light Connection: Use the remaining conduit entries at the bottom of the PCR-1Z to connect the 4-core wire from the PAL 4 WIRE LED LIGHTS. Ensure correct terminal connections. The enclosure supports up to 2 x PAL-LED 4 Wire Pool Lights via two output conduit entries.
4. Transmitter Setup: The PCR-1Z is factory set for the PCZ-2 Transmitter. Install the 2 supplied batteries into the PCZ-2. Refer to the PCZ-2 transmitter manual for full operating instructions.

WIRING DIAGRAM

Diagram shows the internal components and wiring connections for the PCR-1Z RGB Outdoor Driver.

• Components: Manual Operation Button, Code Setting Button, LED Indicator, Module Configuration DIP Switches (S1, S2, S3, MODE), Wi-Fi Connector, Terminal block (EARTH, ACTIVE, NEUTRAL), and output terminals (A, N, EARTH, BLUE, GREY, RED, WHITE).
• Connections: Wi-Fi module connects to the PCB inside the enclosure lid. All PCR-1Z drivers are supplied with one PCZ-2 Hand Held Transmitter & Wall Holder.
• Notes:
• The PCR-1Z is suitable for PAL 4-wire lights.
• Knockouts allow connection of up to 2 x PAL 4-wire UL Listed Pool Lights.
• An unlimited number of drivers can be controlled by one transmitter.
• A maximum of 4 transmitters can be coded to an individual PCR-1Z.

Wiring Diagram Description: Shows connections from a 110-240V Power Supply to the PCR-1Z via a 1/2" PVC Conduit. Two PAL 4 Wire LED Lights are connected to the output terminals of the PCR-1Z.

CLONING SETTINGS

Code Setting Switches: Four DIP switches (Switch 1, Switch 2, Switch 3, Switch 4) are used to set the operating mode (JANDY, PENTAIR, HAYWARD, PAL, ASTRAL).

Notes:

• Turn off power before changing DIP switch settings.
• When syncing PAL lights with other OEM lights, static colors will match, but color change mode timing may vary.
• For Automation use, do not use the handheld remote and disconnect the Wi-Fi module if equipped.
• If Automation fails to control the lights, press the Z1 button once on the PAL Driver to turn it on.
• PAL features like infinite color selection and dimmability are not available in Cloned mode.

PAL TOUCH PCZ-2 TRANSMITTER HAND HELD REMOTE

Controls:

• ON/OFF: Powers the unit on or off.
• COLOR WHEEL: Selects any color and brightness (B).
• OPERATIONAL RED LED: Flashes during remote operations.
• BRIGHTNESS (UP/DOWN): 5 brightness settings (100%, 80%, 60%, 40%, 20%).
• ZONE (UP/DOWN): Zone selection (not applicable to single zone controllers).
• MODE SELECTION (UP/DOWN): Selects various lighting modes: White, Color Change, Disco, White Gradual Change, Blue Gradual Change, Green Gradual Change, Red Gradual Change. Modes can have adjustable speed (S) and delay settings.

FEATURES

1. Matching Code: Apply power to the receiver, then press Z₁ within 5 seconds. A white flash (3 times) indicates success.
2. Clearing Code: Apply power to the receiver, then hold Z₁ for 3 seconds. A flash (6 times) indicates success. A new code must then be applied.
3. One transmitter (PCZ-2) can operate an unlimited number of receivers (PCR-1Z).
4. One receiver (PCR-1Z) can be controlled by a maximum of 4 transmitters (PCZ-2).
5. Touching the color wheel resets any mode selection.
6. Memory Feature: Remembers the last color selection after power off.
7. Once coded, the receiver remembers the code even after power loss.

AUTOMATION DEDICATED LIGHT OUTPUT RELAY FOR CLONE MODE

Diagram illustrates wiring for clone mode, connecting the PCR-1Z to PAL 4 Wire LED Lights from a power supply.

• Note: Wi-Fi is not needed for clone mode and should be disconnected if not in use.
• Wiring connections should be made as per NEC code requirements.
• The diagram shows the PCR-1Z connected to two PAL 4 Wire LED Lights, with the power supply connected via conduit.
