VEYRON SERIES

2 Years Warranty | +43°C Cooling | -15°C Heating | 22dB Sound Level

CE ROHS INVERTER

FUNCTION

[Sleep Mode]

[ECO-FRESH]

[Self-clean]

[Locking Remote]

[24h Timer]

[LED Display]

[Turbo Mode]

[Multi-speed Fan]

[SWING Mode]

[Dry Mode]

[Wi-Fi Ready]

[I FEEL]

[ECO Mode]

Intelligent Control

[Anti Freeze Protection]

[Auto Restart]

[Self Diagnostics]

[Display Backlight]

R32 Refrigerant

[Silent Mode]

[Auto Protection]

+8°C

[I-Action Technology]

[Anti-corrosion Flash]

Energy Efficiency

A+++

Generation VI

SPECIFICATIONS

MODEL	CH-S09FTXA	CH-S12FTXA	CH-S18FTXA	CH-S24FTXA
Capacity Cooling	kW 2,6 (1,00-3,00)	kW 3,4 (1,00-4,00)	kW 5,1 (1,60-6,25)	kW 7,1 (1,80-7,30)
Capacity Heating	kW 3,8 (1,00-4,20)	kW 4,2 (1,00-4,50)	kW 5,6 (1,60-6,25)	kW 7,2 (1,80-7,30)
Power consumption Cooling	kW 0,684 (0,19-1,50)	kW 0,935 (0,19-1,60)	kW 1,232 (0,26-2,30)	kW 1,648 (0,420-2,76)
Power consumption Heating	kW 0,590 (0,19-1,50)	kW 0,863 (0,19-1,60)	kW 1,205 (0,35-2,30)	kW 1,784 (0,395-2,70)
Energy efficiency Cooling (SEER*)	kW/kW 6,1/A++	kW/kW 6,1/A++	kW/kW 6,2/A++	kW/kW 6,2/A++
Energy efficiency Heating (SCOP**)	kW/kW 5,1/A+++	kW/kW 5,1/A+++	kW/kW 5,1/A+++	kW/kW 5,1/A+++

INDOOR UNIT

	CH-S09FTXA	CH-S12FTXA	CH-S18FTXA	CH-S24FTXA
Power supply	~220-240V/50Hz/1 Ph
Air productivity	m³/h 550	m³/h 550	m³/h 880	m³/h 1100
Sound pressure level	dB (A) 39/37/34/32/27/22	dB (A) 39/37/34/32/28/22	dB (A) 44/42/40/37/34/27	dB (A) 45/42/40/38/34/30
Drainage	l/h 0,9	l/h 1,2	l/h 2,0	l/h 2,2
Dimensions (WxHxD)	mm 790×255×200	mm 790×255×200	mm 890×300×220	mm 998×325×225
Weight	kg 7.1	kg 7.1	kg 10	kg 11.0

OUTDOOR UNIT

	CH-S09FTXA	CH-S12FTXA	CH-S18FTXA	CH-S24FTXA
Sound pressure level	dB (A) 51	dB (A) 52	dB (A) 55	dB (A) 56
Compressor type	Rotary
Refrigerant type	R32
Temperature range for cooling	°C -15/+43
Temperature range for heating	°C -15/+24
Dimensions (WxHxD)	mm 660×483×240	mm 660×483×240	mm 810×585×280	mm 860×667×310
Weight	kg 21.7	kg 22	kg 34	kg 41
Gas filling volume	g 460	g 580	g 1150	g 1300
Liquid line diameter	inch 6.38/1/4"	inch 6.38/1/4"	inch 6.38/1/4"	inch 9.53/3/8"
Gas pipeline diameter	mm/inch 9.53/3/8"	mm/inch 9.53/3/8"	mm/inch 12.7/1/2"	mm/inch 15.88/5/8"
Maximum height difference	m 5	m 5	m 5	m 5
Maximum track length	m 20	m 20	m 20	m 20
